Jarvia - Desk
Assembly Instructions -
Dimensions
Width - 98cm
Depth - 39cm
Height - 75.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
143/6202
MADE IN
BRITAIN
Issue 1 - 08/10/13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Jarvia 143/6202
Summary of Contents for Argos Jarvia 143/6202
- Page 1 Jarvia - Desk Assembly Instructions - 143/6202 Please keep for future reference Dimensions Width - 98cm Depth - 39cm MADE IN Height - 75.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 08/10/13...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 17kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Rail (D2512A) (352 x 80mm) Left Side Right Side (D2508A) (D2509A) (D2507A) (720 x 386mm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Runners must be pushed up against Fit runners to the the drawer front drawers Turn the drawer assemblies over. Fit the runner to the bottom edge of the left drawer side , as shown, making sure that it is pushed up against the back of the drawer front...
- Page 8 Assembly Instructions Step 9 screw screw screw Prepare the upright Fit 2 runners to the upright The 1st screw uses the 2nd hole in from the front of the runner. The 2nd and 3rd screws Finished use the holes that line front edge up with the other panel holes.
- Page 9 Assembly Instructions Step 11 Prepare the left side Push 2 hollow core locking nuts into the left side , making sure that they are flush against the panel’s surface. Using a hammer, tap in the pin on the hollow core locking nut Note: The pin should be Front edge tapped in flush with the...
- Page 10 Assembly Instructions Step 13 Prepare the modesty Insert 4 large locking nuts into the modesty Step 14 Fit the modesty Push the modesty onto the left side Use a screwdriver to tighten the 2 large locking nuts fitted to the modesty Step 15 Prepare the rail Plain chipboard...
- Page 11 Assembly Instructions Step 16 Prepare the right side Fit 2 runners to the right side The 1st screw uses the 2nd hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel Finished holes.
- Page 12 Side panel Drawer If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2911...
