convenience concepts 203282 Assembly Instructions Manual

Town square coffee table

Download this manual

TOWN SQUARE COFFEE Table

ASSEMBLY INSTRUCTIONS

We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,

step by step instructions will guide you through the project from start to finish .

Feel confident that this will be a fun and rewarding project . The final product will be a quality

piece of furniture that will go together smoothly and give years of enjoyment .

Please do not return to the store

STOP

Broken or missing parts?

Need help with assembly?

Our Illinois based customer service team is ready to help with any problems or questions you may have.

Please give us a call (Toll Free) at 1-800-468-6447, or email us at parts@convenience-concepts.com.

Normal hours of Operation: M-F* 8am-4pm CST.

*Excludes Holidays

This product's warranty is only valid through authorized dealers.

203282

version:2020.7.1

Need help?

Do you have a question about the 203282 and is the answer not in the manual?

Page 1 TOWN SQUARE COFFEE Table 203282 ASSEMBLY INSTRUCTIONS We have designed our furniture with you , the customer in mind . Our clear , easy to follow , step by step instructions will guide you through the project from start to finish .
Page 2: Hardware List
Hardware List Cam Bolt ( 12pcs ) Stickers ( 8pcs ) Wood Dowel( 12pcs ) Allen Bolt( 8pcs ) LOCK Nut( 8pcs ) Glue : For securing please apply to Cam Lock Allen Wrench (1pc) (12pc) wood dowel ﬁrst before inserting into panel .
Page 3 Assembling the unit with camlocks and wood dowels. Arrow must face hole Gently screw cambolt Lightly glue one end of Lightly glue wood dowel and Screw the camlock into the threaded anchor. the wood dowel and tap connect to second panel by ﬁrmly into locked halfway into hole.
Page 4 Step 2 *Assemble unit on carpet or ﬂat surface. 1.Insert Cam Locks (F) into Support Bars 2.Connect Support Bars to Bottom Panel by gently tightening Cam Locks (F). Step 3 1.Carefully connect Side Frame to Support Bar and Bottom Panel using Allen Bolts (B) and Lock Nuts (C).
Page 5 Step 4 1.Repeat Step 3 using second Side Frame Step 5 1.Connect assembly to Top Panel using Cam locks (F). Page 5 of 6...
Page 6 Step 5 1.If desired, place Stickers (E) over screw holes. 2.Enjoy. Page 6 of 6...
