INSTALLATION GUIDE
Switch System
Small Round Meeting Table
Size: 700mm
Tools Required: Power screwdriver.
Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your
particular table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame
is su ciently rigid. Failure to do this may a ect stability once the tops are attached.
