Jason.L Sapphire Boardroom Installation Manual

Table of Contents

Download this manual

INSTALLATION GUIDE

Sapphire

Boardroom

Size: 2400mm x 1200mm

Tools Required: Power screwdriver.

Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your particular

table/desk base and woods screws will be required to be screwed directly into the underside of the top.

Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame is su ciently rigid.

Failure to do this may a ect stability once the tops are attached.
