- Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W Page 1 of 5...
- Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W Top rail Top panel Back panel COMPONENTS Minifix Housing x14 Collar Stud x5 Rubber Wood Dowel M8 x40mm x14 Minifix Connecting Bolt x14 Adjustable Leveller N2880 x10 Leveller N2880 Cap x10...
- Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W Function of Klix Cam Make sure the arrow is Turn for locking pointing upwards before inserting into the panel’s hole.
- Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W STEP 02 Adjustable Leveller N2880 Leveller N2880 Cap DECO-CAP-18X15 5-pcs Tighten leveller into boring hole and screw the cap. Page 4 of 5 Use DECO-CAP-18X15 to seal holes on base panel.
- Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W STEP 03 Boring hole Tighten Strike Plate screw Align handle with boring hole CL2 Rim Lock and screw Stripe Plate...
- Page 6 www.jasonl.com.au ASSEMBLY INSTRUCTIONS If you have purchased Need help! Call us on storage units that are 1300 527 665 1600mm or 2400mm wide Tighten Minifix Connecting into Boring Holes Assemble each module separately without top module 3 Add single top 800mm over all modules module 2...
- Page 7 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Small 2 Drawer Lateral Need help! Call us on 2 Door Cupboard 1300 527 665 Size (mm): 720H x 450D x 1600W Safety hook Large furniture provides ample storage space while making your home look great. If you have kids at Components home, you should firmly secure your large and heavy furniture to prevent it from toppling.
