- Page 1 ASSEMBLY INSTRUCTION Shrike Drafting Chair x5PCS x1PC x1PC x1PCS x1PC x1PC x1PC 1/4*35mm M8*20mm www.jasonl.com.au Need help! 1 of 6 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTION Shrike Drafting Chair STEP 1 Insert castors into base. Base with STEP 2 gas inserted. Insert gas cylinder into base. STEP 3 Insert drafting ring over gas as shown. Base assembly complete ! www.jasonl.com.au Need help! 2 of 6 1300 527 665 Call us on...
- Page 3 ASSEMBLY INSTRUCTION Shrike Drafting Chair STEP 4 STEP 5 Insert this bolt first and tighten slightly before inserting other two bolts Bottom view www.jasonl.com.au Need help! 3 of 6 1300 527 665 Call us on...
- Page 4 ASSEMBLY INSTRUCTION Shrike Drafting Chair STEP 6 Now you can insert the other two bolts STEP 7 Assembly done ! www.jasonl.com.au Need help! 4 of 6 1300 527 665 Call us on...
- Page 5 ADJUSTMENTS Shrike Drafting Chair Seat height adjustability • Enables the user to adjust the chair height so that their feet are placed firmly on the floor. • Seat too high? The user is forced to lean forward and therefore forfeits the back support. •...
-
Page 6: Backrest Angle Adjustment
ADJUSTMENTS Shrike Drafting Chair Backrest angle adjustment • 3-lever back and seat tilt mechanism with ratchet back height adjustment. • Independent seat angle and back height adjustment. • Ratchet back height adjustment facilitates the lumber support required, relative to the stature of the individual.
