- Page 1 ASSEMBLY INSTRUCTIONS Open Hutch Need help! Call us on Size (mm): 800L x 350D x 1120H 1300 527 665 2 persons required for installation Page 1 of 4...
- Page 2 ASSEMBLY INSTRUCTIONS Open Hutch Need help! Call us on Size (mm): 800L x 350D x 1120H 1300 527 665 SIDE PANEL R SIDE PANEL L BACK PANEL Qty : 1 pc Qty : 1 pc Qty : 1 pc...
- Page 3 ASSEMBLY INSTRUCTIONS Open Hutch Need help! Call us on Size (mm): 800L x 350D x 1120H 1300 527 665 MINIFIX FUNCTION 1/4 Right turn for locking Make sure the arrow is pointing upwards before inserting into the panel's hole...
- Page 4 ASSEMBLY INSTRUCTIONS Open Hutch Need help! Call us on Size (mm): 800L x 350D x 1120H 1300 527 665 STEP 3 COMPLETE Panel Angle Bracket need assemble with direct screw to table top or cabinet Assemble the adjustable shelf & straight slim worktops...
