2. [Ethernet]
Only when the [Ethernet] is selected.
> It is the name of the screen (it can take 12 characters).
3. [Configuration injection]
The settings are sent to the chart screen.
4. [Send image to Vision-C 600]
An image is sent to the chart screen in order to test the connection.
Once the adjustments are made, press on:
to confirm.
to cancel.
b. Adjusting optotypes from console
By IR
1 It is possible to generate optotypes from console by pressing on
console.
Then, click on .
2
> The following page appears.
Set the mirror mode [OFF] or [ON] regarding your configuration.
3
21
U
Vision-C 600 - Polarized visual chart system > V1- 02-2021 (VRSQSE)
> A
SER MANUAL DJUSTMENTS BEFORE THE EXAMINATION
> of the keyboard of the
