Essilor Instruments Vision-C 600 User Manual page 12

Installation of VESA brackett
Unscrew and remove the part to be fixed on the wall.
1
Position the wall part in order to mark the 2 fixing pants then, drill.
2
Fit the wooden dowel provided.
3
Screw the wall part of the support.
4
Vision-C 600 - Polarized visual chart system > V1- 02-2021 (VRSQSE)
U > I
SER MANUAL NSTRUMENT
12
