Camera Overview; Installation - Rexing V1 Basic Quick Start Manual

3. Camera Overview

1.
2.
3.
4.
10.
11.
12.
13.
* The Camera is recording when the LED is flashing red.
** The Camera is recording when the LED is flashing red. The device charging
or powered on when the LED is solid blue.
*** The device is charging or powered on when the LED is solid blue.
6
5. 6. 8. 9.
7.
1. Micro SD Card Slot
2. Power Button
3. Reset Button
4. Menu Button
5. Mode Button
6. REC (Record) Button *
7. OK (Confirm) Button **
8. MIC (Microphone) Button ***
9. Screen Button
10. Mini-USB Port
11. GPS Logger Port
12. Rear Camera Port (Not Support)
13. Lens Angle Adjustment

4. Installation

Step 1: Install the Dash Cam
Place the 3M adhesive on the mount and properly orient
the mount square to the roof and hood line of the
Important! Ensure the T-interlock on the Mount
vehicle.
is oriented in the correct direction (as shown below).
Firmly press the mount onto the windshield. Wait at least
20 minutes before mounting the camera.
Orientation mount as shown
Step 2: Insert the Memory Card
The Rexing V1 Basic accepts [Class 10/ UHS-1 or higher]
Micro SD memory cards up to 256 GB. You will need to insert
a memory card before you can begin recording. Before
inserting or removing a memory card, first ensure
you've powered down the device.
Gently push the memory card in until you hear a click, and allow
the spring release to push the card out.
7
