BAD-031
Product:
Floor Fixed Competition Badminton
1. 1 x Floor Fixed Badminton Post
2. 2 x Floor Fixed Ali Badminton Base
(Items listed below are packed within FPK030)
3. 4 x M12x30mm Button Head Socket Screw
4. 4 x Large Washer
5. 1 x Velcro Net Ties
6. 1 x 8mm Allen Key
Optional Extras
7. 4 x Standard SH2 Ground Sockets For Solid Floors
7. 4 x Long SH2 Ground Sockets For Sprung Floors
Please read instructions before you begin to assemble your badminton posts.
1
3
2
4
7
Pack Contents:
Pack Contents
(not shown)
6020mm Between Posts
Socket Installation Dimensions
(PEQ117)
(PEQ119)
(BOL142)
(BOL702)
(BAD-060)
(BOL790)
(ASY001+BOL855)
(ASY002+BOL855)
Net Not Included
INS031
04/04/11
Revision 1
©
Harrod UK Limited
5
1
Fig 1
Fig 2
