IST-47CPG424
GAS CONTROL UNIT
47CPG424
Max 24 Inputs 4÷20mA
USER INSTRUCTIONS
Comelit Group S.p.A.
Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy
Tel. +39 0346 750 011 - Fax +39 0346 71436
info@comelit.it
www.comelitgroup.com
email:
-

Advertisement

loading
Need help?

Need help?

Do you have a question about the 47CPG424 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comelit 47CPG424

Summary of Contents for Comelit 47CPG424

  • Page 1 IST-47CPG424 GAS CONTROL UNIT 47CPG424 Max 24 Inputs 4÷20mA USER INSTRUCTIONS Comelit Group S.p.A. Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436 info@comelit.it www.comelitgroup.com email:...
  • Page 2 INFORMATION AND WARNINGS OF USE The 47CPG424 is a control unit for gas alarm systems up to 24 independent detection points. The simple installation and easy configuration via the buttons make the unit suitable for use in many areas, both civil and industrial.

  • Page 3: Table Of Contents

    CoNNECTION WITH GAS DETECTORS Fig 4 – 47CPG424 Wiring diagram for Inputs Sensor 4 to 20mA and relay Outputs Fig 5 – 47CPG424 Remote units Connection with 4 to 20mA detectors input and output relays. 12 UNIT’S OPERATION Fig 5 – 47CPG424 Keyboard...
  • Page 4 TABLE 4 – USED ONLY IN ITALY - Values to be set to use with PARKING-ITA (DM 1.02.1986)44 TABLE 5 - Relays operation's PRECONFIGURED parameters. SETUP MEMORANDUM TABLES Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 5: Description

     The 47CPG424 is wall mount “GIUGIARO DESIGN” housing 379x241x133 mm:  The 47CPG424 can be connected to all of our Gas Detectors (Sensors): The 47CPG424 can control up to 4, 8, 16 or 24 remote gas detectors. Three-Wire, 4÷20mA linear output models with “Replaceable Cartridge Sensor” for: Flammable gases with Catalytic sensor (20% LEL range) TS282K(IP65) or TS293K(Ex”d”) series.
  • Page 6 NC contact outputs (gas sensors with a relay contact, smoke sensors, buttons, etc.).  The 47CPG424 can manage up to 5, 9, 17 or 25 Alarm relays: Each sensor has three alarm levels (Threshold 1, Threshold 2 and Threshold 3) and a FAULT, freely addressable to any relay output.
  • Page 7 LEVEL 1: for the User LEVEL 2: for the Installer or Maintenance technician. LEVEL 3: only for Manufacturer. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 8: 47Cpg424 Installation

    POSITION: The 47CPG424 should be mounted on the wall using 4 screws and wall plugs (Ø 6 mm) or 4 M4 screws and nuts, if the wall is not in masonry. The housing's base must be fixed through the 3 holes, one in the center and the other in the bottom corners (Fig.2).

  • Page 9: Electrical Connections

    If required, to increase the autonomy (6 hour), it can be used two 7Ah batteries connected in series, but causes the greatest dimension, shall be installed in a case outside the 47CPG424. Cable glands: the lower side of the housing has 13 inputs designed for metric cable glands (ISO pitch 1.5 mm).

  • Page 10: Power Connection

    Battery Battery n. 1 n. 2 90÷ 264 Vac / 47÷63Hz Mains power supply terminal Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 11: Connection With Gas Detectors

    Detectors and the Remote Units. Please note, that the 47CPG424 has a board with 4 inputs and a board with 4 outputs. In Central can be installed, a board 47ESP040 and 47REL040 to have a total of 8 inputs and 9 outputs.

  • Page 12: Fig 5 - 47Cpg424 Remote Units Connection With 4 To 20Ma Detectors Input And Output Relays

    Dip-Switch - Address Dip-Switch - Address of Remote Unit 2 of Remote Unit 1 UNUSED UNUSED Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 13: Unit's Operation

    Then, by pressing a number key, the number already present is deleted and replaced with the new one. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 14 Alarm 3 is active (Detector or Zone) or Firmware updating is in progress Internal Buzzer Indications The 47CPG424 has an internal buzzer that emits a beep when a key is pressed. It can also be configured to sound in the event of a fault and / or an alarm.
  • Page 15 ZONE:0 sensor, (of course only if it is configured). ---------------------------------------  OUTPUT: ¯¯¯¯¯¯ ¯¯¯¯¯¯¯ ¯¯¯¯¯ Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 16: Main Menu

    To enable them, with the ACCESS DENIED Access password, see the menu Press Esc Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 17: Reset

    RU (first line) or on a group of RU (second line). ----------------------------------------------------------------------------  Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 18: Configure (Level 2)

    Please note that if the number of RU or the port is not correct, the RU will result out of line. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 19: Delete (Level 2)

    Present or Out of Line or Disabled. In case you want to go back, press Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 20: Sensors

    Then the screen returns to the beginning of the management for Enabled or Disable. ENABLED Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 21: Configure (Level 2)

    Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 22 (47RTS282EO / others EO) whose hysteresis is 2%. The level of fault (FAULT) has a hysteresis of 1mA, so a sensor failure comes out when his current exceeds 2mA. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 23 Fault, a warning message will appear. --------------------------------------  Then the screen returns to the configuration of the sensor. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 24: Copy (Level 2)

    FROM N. TO N. desired number, then press will appear the confirmation window. ENTER Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 25: Delete (Level 2)

    DELETED successful. -------------------------------------------------------------------------------  Then the screen returns the beginning of the management the deletion. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 26: Modify (Level 2)

    INPUT Then the screen returns the beginning of the management the Enable or Disable. ENABLED Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 27: Configure (Level 2)

    -----------------------------------------------------------------------  DELETED Then the screen returns the beginning of the Delete item management. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 28: Modify (Level 2)

    You can enable or disable all Zones, including between two, both from the smallest to the largest number, and the reverse. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 29: Configure (Level 2)

    DM 02/01/1986 (point b of paragraph 3.9.3) valid only in Italy for the car parks. Please note that the 47CPG424 has 3 outputs for each level of alarm, and a fault output, for a total of 10 outputs configurable for each zone.

  • Page 30: Delete (Level 2)

    . Then at the end of the screen, is also referred to its status, and the enabling status of the Zone. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 31: Events

     MAIN NOT: Indicates that the unit is powered by batteries (only if batteries are installed).  RESET: Indicates that has been executed, the Reset command. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 32: Settings

    ENTER The window will inform you that the operation was successful. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 33: Access Menu

    Then a window notifies you that the operation has been successful. -----  Then the screen returns to the beginning of the manage Access Menu. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 34: Modif. Password

    In case of loss of password, please contact Our customer service. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 35: Service

    If the voltage of the battery falls below 22 VDC, the control unit will automatically shut down to prevent damage to the battery (discharging). When the Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 36: Sensors Status (Level 2)

    SD Card. The file can be requested to our customer service as Firmware Update 47CPG424 and then follow the instructions. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 37: Update Firmware

    Then it will automatically restart in normal operation, but with the previous firmware version. ----------------------------------------------------  Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 38: Copy Conf. From (Livello 2)

    SD Card. The file, named “CE424_CF.txt”, can ONLY be created using the “COPY CONF. ON” (see below). This function can be used to restore a 47CPG424 configuration (with memory failure) or to transfer the same configuration on other COPY CONF.

  • Page 39: Copy Events On (Livello 2)

    Below the logic inputs and the areas it is written the state. e) If a device is not configured, it is indicated by the symbol "--------". Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 40: Appendix

    Each sensor in less, increases the autonomy of approx 5 minutes (eg, with 6 sensors, the range increases to 10 min.=70 min.). Using metric cable glands (M16 and M20 Pitch 1.5mm ISO) with appropriate protection rating. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 41: Display Message

    The 47CPG424 is not able to start, Firmware incomplete or missing UPDATE FAILED The 47CPG424 is not able to update the firmware from SD-Card Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 42: Table 1

    Refrigerant gases: SF1-H (R134a) - SF2-H (R404a) - SF3-H (R407c) SF4-H (R410a) - SF5-H (R507). Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 43: List Of Preconfigured Sensors With Display And Replaceable Cartridge Sensor

    European Department COSHH (Control Of Substances Hazardous to Health) and the U.S. Department OSHA (Occupational Safety and Health Administration). Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 44 ALARM Silenceable Number Logic Output (seconds) (seconds) (seconds) AL 1 AL ↓ AL ↑ FAULT Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...

  • Page 45: Setup Memorandum Tables

    Hysteresis OFF Time ON (from 0 to 300 Seconds) Positiv Logic (NO/YES) Latched output (NO/YES) Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 46 YES to prevent the resetting of an actuator (eg. Solenoid shut-off of the gas) without first verifying that the Central is in alarm. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 47 YES to prevent the resetting of an actuator (eg. Solenoid shut-off of the gas) without first verifying that the Central is in alarm. Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 48 Hysteresis OFF Time ON (from 0 to 300 Seconds) Positiv Logic (NO/YES) Latched output (NO/YES) Comelit Group S.p.A. - Via Don Arrigoni 5 - 24020 Rovetta S. Lorenzo BG Italy Tel. +39 0346 750 011 - Fax +39 0346 71436...
  • Page 49 Latched output (NO/YES) NOTE Only if the Expansion Board 47ESP040 with 4 inputs is installed. In each 47CPG424, can be installed one 47ESP040 to obtain a total of 8 Inputs 4-20mA (4 imputs standard + 4 with 47ESP040). NOTE Only if the Expansion Board 47REL040 with 4 relay is installed. In each 47CPG424, can be installed one 47REL040 to obtain a total of 9 relays outputs (5 outputs standard + 4 with 47REL040).
