C - ES 3000 Controller

1 - Control and command panel
CAREFULLY READ AND UNDERSTAND THE CONTROL FUNCTIONS BEFORE
CARRYING OUT THE OPERATING TEST
1
1) Control board
2) Emergency stop button with mechanical holding and unblocking by turning
2 - Electronic board model "ES 3000"
Fig. 7
The electronic panel contains an electronic and diagnostic board. This board includes the function display as shown in figure 7.
01/2008
Page 12
2
Fig. 6
1 3
2
5
4
Chicago Pneumatic Compressors
62 305 454 65
