Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction.
Wood Bag:
1 LC-503-01
1 LC-503-03
1 LC-503-05
1 LC-503-07
1 LC-503-09
4 Leading Edge Stringers
4 Trailing Edge
1 Hatch Support & Servo
Rails
2 Throttle and Nose Gear
Pushrod
Misc. Parts Loose in Box
1 Plan Sheet #1
1 Decal Sheet
2 Main Landing Gear
Hardware Bag
2 Control Horn
1 Elevator Joiner
4 Nylon Clevis
Nose Landing Gear Bag
1 Nose Gear Wire
1 Steering Collar
1 Steering Arm Fitting
4 Mounting Nuts
COMPLETE KIT PARTS LIST
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x3"x12" Laser Cut Balsa Sheet
3/32"x3"x12" Laser Cut Balsa Sheet
1/16"x3"x4 1/2" Laser Cut Birch Ply
3/32" sq.x24" Balsa Strip
1/16"x1"x24" Balsa Sheet
1/4" sq.x12" Spruce
1/16"x10" Wire, Threaded One End
Small Nylon Control Horn
1/8"x3" Birch Dowel
Small Nylon Clevis
3/32" Pre-Bent Wire
3/32" Collar
Molded Nylon Fitting
2-56 Nuts
1 LC-503-02
1 LC-503-04
1 LC-503-06
1 LC-503-08
6 Leading Edge and Spars
1 Wing Tips
2 Center Section Sheet
2 Control Surface Pushrod
1 Plan Sheet #2
1 Instruction Book
4 Horn Screw
5 Main Landing Gear and
Hatch Screw
2 Wing Dowels
1 Nose Gear Bearing
1 Steering Arm
4 Mounting Screws
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x4"x24" Laser Cut Balsa Sheet
3/32"x3"x12" Laser Cut Balsa Sheet
3mmx4"x24" Laser Cut Poplar Ply
1/4" sq.x24" Balsa Strip
3/4" Balsa Trianglex13"
1/16"x3"x12" Balsa Sheet
1/16"x18" Wire, Threaded One End
2-56x3/8" Machine Screw
#2 Sheet Metal Screw
3/16"x3 1/2" Dowels
Molded Nylon Bearing Block
2-56x1/2" Threaded Stud
2-56x3/8" Machine Screws
Advertisement
Table of Contents
Related Manuals for SIG STAR-CRUISER
Summary of Contents for SIG STAR-CRUISER
- Page 1 Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction. COMPLETE KIT PARTS LIST Wood Bag: 1 LC-503-01 3/32"x4"x24" Laser Cut Balsa Sheet 1 LC-503-02 3/32"x4"x24" Laser Cut Balsa Sheet 1 LC-503-03 3/32"x4"x24"...
- Page 2 The first thing that you need to do is to identify and mark the part numbers on the laser cut parts using the drawings on the following pages as a guide. It is possible that several of the laser cut parts may not be completely cut through. If this is the case you can free the part from the sheet quickly using an X-acto knife.
-
Page 3: Building The Tail Surfaces
Sig Easy Hinges #SH-710 or Du-Bro Kwik Hinge #537 1 Motor Mount Dave Brown #0506 4 Motor Mount Screws and Blind Nuts 4-40x3/4" Machine Screws and Blind Nuts Sig #SH-III or Du-Bro #129 1 Fuel Tank Sullivan loz. #SS-I or 20z. #SS-2 1 1/2-A Fuel Line... - Page 4 7. Place the right fuselage side on the building board and place formers F-6 and F-7 into position. These formers should be 90 degrees to the fuselage side. Glue the formers to the fuselage side. 8. Glue the left fuselage side into position on the formers. The formers should also be 90 degrees to this fuselage side. 9.
- Page 5 Building the Right Wing 29. Place the left wing into position on the end of the right wing plan. Place a spacer under the last W-2 rib to raise the tip 3 1/2" above the building board. The lower 1/16" plywood dihedral braces for the right wing should be flat against the plan. Pin the left wing into this position.
-
Page 6: Final Assembly
LIMIT OF LIABILITY: In use of our products, Sig Mfg. Co.'s only obligation shall be to replace such quantity of the product proven to be defective. User shall determine the suitability of the product for his or her intended use and shall assume all risk and liability in connection...
