- Page 1 EN.IO.SGE.25.MODBUS Revision 01.A.001 SEPTEMBER 2021 USER’S MANUAL SMART LEVEL PROBES SGE-25.Modbus and SGE-25S.Modbus APLISENS S.A., 03-192 Warsaw, Morelowa 7 St tel. +48 22 814 07 77; fax +48 22 814 07 78 www.aplisens.com, e-mail: export@aplisens.com...
- Page 2 User’s Manual, Explosion Proof Device Manual, Modbus Manual, declarations of con- formity and copies of certificates. SGE-25.Modbus ID: 0044 0001 0001 0000 0000 0000 0001 77 https://www.aplisens.pl/ID/004400010001000000000000000177/ SGE-25.Modbus (Exi) ID: 0044 0002 0001 0000 0000 0001 0001 94 https://www.aplisens.pl/ID/004400020001000000000001000194/ SGE-25S.Modbus ID: 0045 0001 0001 0000 0000 0000 0001 74 https://www.aplisens.pl/ID/004500010001000000000000000174/...
- Page 3 Changes made to the manufacturing of products may be introduced before the paper version of the manual is updated. The up-to-date manuals are available on the manufacturer’s website: www.aplisens.com.
-
Page 4: Table Of Contents
EN.IO.SGE.25.MODBUS TABLE OF CONTENTS 1. INTRODUCTION ..................6 1.1. Purpose of the document ....................... 6 2. SAFETY ....................... 6 3. TRANSPORT AND STORAGE ..............7 3.1. Delivery check ........................7 3.2. Transport ..........................7 3.3. Storage and use ........................7 4. - Page 5 EN.IO.SGE.25.MODBUS LIST OF DRAWINGS Figure 1. Mounting brackets for probes................... 9 Figure 2. Diaphragm cover for SGE-25S.Modbus probe............9 Figure 3. Connection in Modbus network................12 LIST OF TABLES Table 1. Symbols appearing on the probe’s nameplate............8 Table 2.
-
Page 6: Introduction
EN.IO.SGE.25.MODBUS INTRODUCTION 1.1. Purpose of the document The subject of manual are smart level probes: SGE-25.Modbus and SGE-25S.Modbus hereinafter referred to as probes in the manual. The manual applies to the following versions: standard and intrin- sically safe Exi. The manual contains data, guidelines and general recommendations for the safe installation and oper- ation of the probes, as well as procedures in the event of a possible failure. -
Page 7: Transport And Storage
3.1. Delivery check After receiving the delivery, please refer to the general terms and conditions of contracts available on the manufacturer website: https://aplisens.com/ogolne_warunki_umow.html. 3.2. Transport Transport of probes shall be carried out with the use of covered means of transport, in original packages with diaphragm provided with protection. -
Page 8: Identification
EN.IO.SGE.25.MODBUS IDENTIFICATION 5.1. Manufacturer address APLISENS S.A. 03-192 Warsaw Morelowa 7 St. Poland 5.2. Probe identification Depending on the version of the probe, the nameplates may differ in the amount of information and parameters. Table 1. Symbols appearing on the probe’s nameplate. -
Page 9: Installation
6.1. General recommendation The probe can be hung on the power cable, e.g. by using from the Aplisens SG cable hanger (item 1 in fig. 1). In the event of frequent removal of the probe or when there is a risk of catching on protruding elements during pulling up, it is recommended to hang the probe on a steel cord using the carrying eye (item 2 in Fig. -
Page 10: Electrical Connection
The electrical connection should be made according to Table. 2. It is recommended to install the PP-Modbus connection box manufactured by Aplisens S.A. to connect the probe cable with the rest of the transmission line. The PP-Modbus junction box is non-hermetic (pressure inside is equal to atmospheric pressure) due to the use of an air filter, which is required for the probe to operate correctly. -
Page 11: Operation Mode In Modbus Network
14 and electronics version at least 48, the current loop is also activated, allowing operation with current output 4...20 mA. The SGE-25.Modbus and SGE-25S.Modbus probes in Exi version have a Modbus RTU interface without current regulator 4...20 mA. - Page 12 EN.IO.SGE.25.MODBUS Figure 3. Connection in Modbus network. Revision 01.A.001/2021.09...
-
Page 13: Overvoltage Protection
EN.IO.SGE.25.MODBUS 7.4. Overvoltage protection Probes can be exposed to switching surges, or other surges, such as those resulting from lightning. Protection against surges between the wires of the transmission line is provided by surge diodes. For protection against surges between the transmission line and earth or housing (which are not protected by diodes connected between the line conductors), the probes are equipped with additional protection in the form of surge arrestors. -
Page 14: Operation
EN.IO.SGE.25.MODBUS OPERATION 9.1. MODBUS register layout in the address space Read-only data Address Number of bytes (2 bytes Register Purpose Comments Format (hex) per register) 0x0000 User value % of the set range IEEE754 4 bytes (2 registers) Pressure or level process 0x0002 Pressure of sensor 1 IEEE754... -
Page 15: Pressure Unit Codes
EN.IO.SGE.25.MODBUS 9.2. Pressure unit codes Table 4. A binary value assigned to the corresponding pressure unit. Unit Value (decimal) Unit Value (decimal) mbar O (w 4°C) mmH2O g/cm² O (w 4°C) O (w 4°C) mmHg InHg kg/cm² mbar torr 9.3. Modbus status register description SV,TV,FV out of PV out of limit... -
Page 16: Maintenance
EN.IO.SGE.25.MODBUS 10. MAINTENANCE 10.1. Periodic inspections Periodic inspections should be carried out in accordance with the standards applicable to the user. Check the processing characteristics by following the steps appropriate to the calibration and configuration procedure described in the EN.IM.PCE.PRE.SGE.MODBUS document available on the manufacturer's website. -
Page 17: Scrapping, Disposal
EN.IO.SGE.25.MODBUS 11. SCRAPPING, DISPOSAL Worn or damaged devices shall be scrapped in accordance with WEEE Directive (2012/19/EU) on waste electrical and electronic equipment or returned to the manufacturer. 12. HISTORY OF REVISIONS Revision Document revision Description of changes D1/2018.12 The electrical parameters in point 2.3 of Part 1 have been completed. D2/2019.05 The content of the comment in point 1 of Part 1 has been changed. -
Page 18: Explosion-Proof Device Manual En.ix.sge.25.Modbus
INTRINSICALLY SAFE acc. to ATEX 1. Introduction Explosion-proof Device Manual EN.IX.SGE.25.MODBUS only applies to probes SGE-25.Modbus, SGE–25S.Modbus, SGE–25C.Modbus in intrinsically safe version acc. to ATEX marked as in point 2 and the Ex information in the Product Certificate. During installation and use of Ex probes it is necessary „Explosion-proof... - Page 19 EN.IO.SGE.25.MODBUS EN.IX.SGE.25.MODBUS Table Z1. Temperature class dependence on ambient temperature Ta and total amount of input power Pi. Pi [W] Pi [W] Pi [W] Total input power of Total input power of Total input power of Class Class Class 485 power and 485 power and 485 power and [ºC]...
- Page 20 EN.IO.SGE.25.MODBUS EN.IX.SGE.25.MODBUS Fig. I.2 5. Special conditions for safe use 1. The probes do not meet the insulation test (500 V rms) required by EN 60079 11:2012. This must be taken into account during installation of the device. 2. For the ambient temperature range – see Table Z1 as well as the information on the probe's rating plate.
