- Page 1 User Manual PCE-DC 50 AC / DC Clamp Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 17 January 2022 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Hold peak value ......................10 Set measurement range ....................10 Display backlight ......................10 Measuring spot illumination .....................10 Bluetooth connection .......................10 Automatic power off......................11 Maintenance and cleaning ..............11 Cleaning ..........................11 Battery replacement ......................11 Fuse replacement ......................11 Warranty ....................12 Disposal ....................12 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
0.000 ... 50.000 V 0.001 V 0.00 ... 500.00 V 0.01 V 0.0 ... 600.0 V 0.1 V For AC voltage measurement, the accuracies refer to 50 ... 1000 Hz and 5 ... 100 % of the measurement range. © PCE Instruments... - Page 5 0.10 % ±(1 % + 2 digits) Pulse width: 100 µs ... 100 ms Frequency: 10 Hz ... 10 kHz Temperature Measurement range Resolution Accuracy (of rdg.) -100 °C ... 1000 °C ±(1 % + 2.5 °C) © PCE Instruments...
-
Page 6: Delivery Scope
Pollution degree 2 Delivery scope 1 x PCE-DC 50 clamp meter, 1 x test lead set, 1 x carrying case, 1 x PC software, 1 x Bluetooth adaptor, 2 x K-type thermocouple, 1 x 9 V block battery © PCE Instruments... -
Page 7: System Description
MODE / Bluetooth key Function rotary switch ⑤ ⑬ Display MAX / MIN key ⑥ ⑭ Sockets for K-type thermocouple RANGE / PEAK key ⑦ ⑮ Sockets for test lead Shutter for input sockets ⑧ Sensor non-contact voltage detection © PCE Instruments... -
Page 8: Operation
Continuity test ZERO Zeroing DC and capacitance Diode test mV or V milli-volts or volts Operation Preparation • Unpack the meter completely. • Remove the protective foils if necessary. • Insert a battery as described in chapter 7.2.2. © PCE Instruments... -
Page 9: Shutter For Input Sockets
As described in chapter 5.4, select current measurement DC. • Press the "ZERO" key on the right side of the meter. • The display should now show 0000. A slight jump of the last digit is normal. © PCE Instruments... -
Page 10: Voltage Measurement Ac / Dc
If "OL" is displayed in one measurement and typical values of e. g. 0.400 V ... 1.800 V are displayed in the second measurement, the diode is working. If voltage values are displayed in both measurements, the diode is defective. In this case, the diode generates a short circuit. © PCE Instruments... -
Page 11: Capacitance Measurement
"OL". During the T1-T2 measurement, a missing sensor is signalled by ----- in the main display. With the RANGE key, you can choose between different types of displaying the measured values: Display RANGE Middle Bottom T1-T2 T1- T2 © PCE Instruments... -
Page 12: Function Setting
Bluetooth connection Press and hold the MODE key to switch the Bluetooth connection on or off. For use on the PC, download the PCE-DC 50 software from our download area: https://www.pce-instruments.com/english/download-win_4.htm Use the dongle from the delivery scope as the Bluetooth interface. -
Page 13: Automatic Power Off
Fuse replacement • Loosen the screw of the battery compartment cover. • Open the battery compartment and replace the defective fuse. (500 mA, 660 V, fast- acting) • Close the battery compartment and fasten the locking screw. © PCE Instruments... -
Page 14: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 15 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 26 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
