Summary of Contents for PCE Instruments PCE-DC 10
- Page 1 User Manual PCE-DC 10 Clamp Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 10 March 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
DC Voltage ........................7 AC Voltage ........................7 AC Current ........................7 Resistance ........................7 Continuity ......................... 8 Frequency/Duty Cycle ...................... 8 Maintenance ..................8 Cleaning ........................... 8 Battery Replacement ......................8 Warranty ....................9 Disposal ....................9 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Safety Symbols
Overvoltage protection 600V AC / DC rms Smallest measurable voltage: 1V AC / DC Frequency range: 45 ... 65 Hz Accuracy refers to RMS sine waves If a current is detected during the voltage measurement, "Err" appears on the display © PCE Instruments... - Page 5 ±(1 % + 5 digits) 600 Hz 1 Hz 3 kHz 10 Hz Total measuring range: 40 ... 3 kHz Minimum voltage: >1 AC RMS (The measurement frequency will increase with the voltage) Overvoltage protection: 600V AC / DC rms © PCE Instruments...
- Page 6 10°C / 50°F If the current ambient temperature less than the temperature of the operating conditions (0 °C / 32 °F (operating temperature)) - (-5 °C / °F (current ambient temperature)) = 5 °C / 41 °F © PCE Instruments...
-
Page 7: Device Overview
MAX/MIN Button: Clamp Trigger: Press to show the max, then min measuring Opens the current clamp value Press again to return to measuring Backlight Button: Flashlight: Screen backlight. On the backside of the meter On during current measurement © PCE Instruments... -
Page 8: Operating Procedures
Press the A-HOLD button to pause the measurement on screen. • Press the button again to resume measurement. Auto Power-Off The meter shuts down automatically after 15min of inactivity, • Press the A-HOLD button to wake the meter up. • © PCE Instruments... -
Page 9: Dc Voltage
When the leads are disconnected or the measurement is out of range, “OL” will be shown on the display. WARNING To avoid injury or damage to the meter, make sure to turn off all power and discharge all capacitors before measuring resistance. © PCE Instruments... -
Page 10: Continuity
To replace the batteries: Shut the meter down and remove all test leads. • • Unscrew the battery cover and remove the used batteries. • Replace the batteries (AAA 1.5V, Alkaline) Reinstall the battery cover and tighten the screws. • © PCE Instruments... -
Page 11: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 12 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
