HDPE HALF WALL R5
INSTALLATION INSTRUCTIONS
IMPORTANT NOTES: Read First
(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B)
Refer to Installation Manual for R5-09 Collars and R5-11 Socket Clamps installation instructions.
Figure 1.2
®
) with all threaded hardware. Important: Liquid thread lock (prior to
Figure 1.1
Manufactured by Krauss Craft, Inc.
www.playcraftsystems.com
R5-1309-HDPE
HDPE Half Wall
See Installation Manual Sections
R5-09 Collars and R5-11 Clamps
For Customer Service Call
800.333.8519 (U.S.A.) or
541.955.9199 (International)
Page 1 of 3
FIGURE 1
Rev A
9/1/2012
Advertisement
Related Manuals for Playcraft HDPE Half Wall R5
Summary of Contents for Playcraft HDPE Half Wall R5
- Page 1 HDPE HALF WALL R5 R5-1309-HDPE INSTALLATION INSTRUCTIONS Page 1 of 3 IMPORTANT NOTES: Read First ® (A) Use liquid thread lock (such as Loctite ) with all threaded hardware. Important: Liquid thread lock (prior to curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a lubricant during assembly.
- Page 2 HDPE HALF WALL R5 R5-1309-HDPE INSTALLATION INSTRUCTIONS Page 2 of 3 Step 1 Elevation View Locate and attach collars at height shown in Elevation View. (See Note B) * Height shown from top of deck to top of collar. 39"...
- Page 3 HDPE HALF WALL R5 R5-1309-HDPE INSTALLATION INSTRUCTIONS Page 3 of 3 Parts List Specifications HALF WALL R5: Part # DESCRIPTION QTY. Shall be made from high density 3/4" sheet plastic AF-7118 Flat Panel Bracket (R5) specially formulated for optimum UV stability and...
