DRUM SOUND PANEL INSERT R5
INSTALLATION INSTRUCTIONS
IMPORTANT NOTES: Read First
(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B) Refer to Installation Manual for R5-1601 Panel Type 1 installation instructions.
(C) Sound Box requires (3) C-Cell batteries included. Installation is required.
®
) with all threaded hardware. Important: Liquid thread lock (prior to
www.playcraftsystems.com
For Customer Service Call
800.333.8519 (U.S.A.) or 541.955.9199 (International)
R5-16043
Page 1 of 4
See Installation Manual
Section R5-1601 Panel Type 1
NOTE: Drum Sound
Panel Insert shown
other configurations
will vary slightly but
does not affect
assembly.
Rev B
3/29/2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the Drum Sound Panel Insert R5 and is the answer not in the manual?

Questions and answers

Related Manuals for Playcraft Drum Sound Panel Insert R5

Summary of Contents for Playcraft Drum Sound Panel Insert R5

  • Page 1 DRUM SOUND PANEL INSERT R5 R5-16043 INSTALLATION INSTRUCTIONS Page 1 of 4 IMPORTANT NOTES: Read First ® (A) Use liquid thread lock (such as Loctite ) with all threaded hardware. Important: Liquid thread lock (prior to curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a lubricant during assembly.
  • Page 2 DRUM SOUND PANEL INSERT R5 R5-16043 INSTALLATION INSTRUCTIONS Page 2 of 4 Step 1 (Factory Assembled) Insert Square nuts provided into Electronic Drum ELECTRONIC DRUM Sound Panel Insert as shown in Figure 1. SOUND PANEL R5 INSERT NOTE: Use hardware included with Sound Box. Do not ®...
  • Page 3 DRUM SOUND PANEL INSERT R5 R5-16043 INSTALLATION INSTRUCTIONS Page 3 of 4 Step 4 (Factory Assembled) Attach Drum Sound Panel Insert to Roto Panel Square as shown in Figure 4. (See Note A) ROTO PANEL SQUARE ELECTRONIC DRUM SOUND PANEL R5 INSERT 3/8"...
  • Page 4 DRUM SOUND PANEL INSERT R5 R5-16043 INSTALLATION INSTRUCTIONS Page 4 of 4 Assembled Parts List Specifications SOUND PANEL BACKING, COVER & INSERT: DRUM SOUND PANEL S-16043-R5 Shall be made from high density 3/4" sheet plastic Part # DESCRIPTION QTY. specially formulated for optimum UV stability and color retention.
