SLIDE SIT DOWN HOOD
IMPORTANT NOTES: Read First
(A) Use liquid thread lock (such as Loctite
curing) helps to eliminate the common problem of "thread seizure" in stainless steel hardware by serving as a
lubricant during assembly.
(B) Refer to Installation Manual for R5-09 Collars and R5-11 Socket Clamps assembly instructions.
Figure 1.2
®
) with all threaded hardware. Important: Liquid thread lock (prior to
Manufactured by Krauss Craft, Inc.
www.playcraftsystems.com
Figure 1.1
See installation Manual
Sections R5-09 Collars
and R5-11 Socket Clamps
For Customer Service Call
800.333.8519 (U.S.A.) or
541.955.9199 (International)
R5-1303
Page 1 of 3
FIGURE 1
Slide Sit Down Hood
Rev A
10/10/2009
