HARDWARE PARTS LIST HG2-01 HG2-02 HG2-03 HG2-04 Front Base Frame Back Base Frame Main Fame Front Support Frame 1 pc 1 pc 1 pc 1 pc HG2-05 HG2-06 HG2-07 HG2-08 Leg Extension Frame Weight Guide Tube Selector Shaft Seat Frame 1 pc 2 pcs 1 pc...
Page 4
HARDWARE PARTS LIST HG2-25 HG2-26 HG2-27 HG2-28 Selector Shaft Bush Weight Selector Pin Rubber Cushion Press Pin 1 pc 1 pc 2 pcs 1 pc HG2-32 HG2-29 HG2-30 HG2-31 Square End Plug Big Foam Small Foam Pulley (38mm) 2 pcs 4 pcs 13 pcs 4 pcs...
Page 5
HARDWARE PARTS LIST HG2-49 Oil Bush HG2-50 HG2-51 HG2-52 (small) Cable (3750mm) Cable (2720mm) Cable (2330mm) 2 pcs 1 pc 1 pc 1 pc HG2-54 HG2-55 HG2-56 HG2-53 Hex Bolt Hex Bolt Hex Bolt Chain (M10 x 20mm) (M8 x 15mm) (M10 x 65mm) 2 pcs 6 pcs...
ASSEMBLY STEPS COMPLETE EACH STAGE IN ORDER BEFORE ADVANCING TO TO THE NEXT. ASSEMBLE WITH NUTS AND BOLTS LOOSE AT FIRST TIGHTEN ALL BOLTS AND NUTS AFTER COMPLETING ALL ASSEMBLY STEPS. STEP 1 Lay the Back Base Frame (02) flat on the floor. Put two Outside-End Caps (36) to Back Base •...
Page 7
ASSEMBLY STEPS STEP 2 Slide nine Weight Plates 6. 8 8 8 8 8 8 8 8 8 8 8 8 8 8 kg (22a) and one (22b) onto Weight Guide • Weight Plates 4.5K k g (6). Tube • Attach the Selector Shaft Bush (25) onto the top hole of the Selector Shaft (07) using Selector Shaft Pin (24).
Page 8
ASSEMBLY STEPS STEP 3 Lay the Upper Cross Beam (09) onto the Main Frame (03) and connect them using two • M10x65mm Hex Bolts (56), four M10 Washers (63) and two M10 Nylock Nuts (66). Connect the Weight Guide Tube (06) to the Upper Cross Beam (09) using two M10x20mm Hex •...
Page 10
ASSEMBLY STEPS STEP 4 Description Q’ty • Connect the Press Bar (16) to the Upper Cross Beam (09) using M12x120mm Hex Bolt (59). two M12 Washers (62), and M12 Nylock Nuts (65). HG2-59 Hex Bolt (M12x120mm) Connect the Press Arm (L) (11) and Press Arm (R) (10) •...
Page 12
ASSEMBLY STEPS STEP 5 Description Q’ty • Fit the Back Cushion (21) to the Main Frame (03) using two M8 x65mm Hex Bolts (60) and two M8 Washers (64). HG2-60 Hex Bolt (M8x65mm) Connect the Front Support Frame (04) to the Front •...
Page 14
ASSEMBLY STEPS STEP 6 Start With The Upper Cable 2330mm (52) With Upper Cable (52) in groove of Pulley (31), thread Upper Cable (52) through brackets on Upper Cross Beam (09). Install Pulley No.1 (31) to Upper Cross Beam (09) using one M10x45mm Hex Bolt (58), two M10 Washers (63) and one M10 Nylock Nut (66).
Page 16
ASSEMBLY STEPS IF YOU FIND THAT THE CABLES ARE NOT LONG ENOUGH,USE THE CHAIN AS AN EXTENSION WITH SNAP HOOK AS CONNECTORS HG2-37 HG2-17 HG2-18 HG2-31 Pulley Fastness Bush Pulley U Reverse U Pulley (big) 1 pc 1 pc 13 pcs 4 pcs HG2-38 HG2-56...
Page 17
ASSEMBLY STEPS STEP 7 Description Q’ty • Attach the Convoy Connect (70) on the middle of each Convoy ( 69) using four M6x15mm Hex Bolt (71), eight M6 Washers (72) and four M6 Nylock HG2-71 Nuts (73). Hex Bolt (M6x15mm) •...
PARTS LIST Description Q’ty Description Q’ty HG2-37 Pulley Fastness Bush (big) HG2-01 Front Base Frame HG2-02 Back Base Frame HG2-38 Pulley Fastness Bush (small) HG2-03 Main Fame HG2-39 Square End Plug (45mm) HG2-04 Front Support Frame HG2-40 Square End Plug (40mm) HG2-05 Leg Extension Frame HG2-41 End Plug (40 x 20 mm) HG2-06 Weight Guide Tube...
