Section 5: Device Installation

Mounting a Computer (LCD Carts Only)

1. To open the Work Surface, insert the key (provided by Amico) into the lock on the Work Surface and turn
counterclockwise (CCW) to unlock the Work Surface.
2. Lift the Work Surface upwards (as shown in Figure 1) to access the interior of the main bin.
3. Place the computer (not provided) carefully inside the main bin and plug the power cord into the supplied power
bar. See page 2 for size restrictions.
4. Plug all USB cables into the computer.
NOTE: A USB HUB (NOT PROVIDED) MAY BE REQUIRED.
5. To close, lower the Work Surface until it is resting on the main bin and turn the key clockwise (CW) to lock.
WARNING: ENSURE THAT THE KEY IS TURNED COUNTERCLOCKWISE BEFORE ATTEMPTING TO CLOSE THE WORK
SURFACE. FAILURE TO DO SO COULD LEAD TO DAMAGE TO THE WORK SURFACE AND/OR THE LOCKING
MECHANISM.
Unlock
Work Surface Lock
Main Bin
Lock
Open
Close
Figure 1
Computer
(not provided)
Power Bar
Work Surface
Figure 2
www.amico.com 16
