Work Surface - Amico Hummingbird User Manual

Section 6: Adjustments

Work Surface

1. To open the Work Surface, insert the key (provided by Amico) into the lock on the Work Surface and turn
counterclockwise (CCW) to unlock the Work Surface.
2. Lift the Work Surface upwards to access the interior of the main bin.
3. To close, lower the Work Surface until it is resting on the main bin and turn the key clockwise (CW) to lock.
NOTE: MAXIMUM RECOMMENDED LOAD IN THE MAIN BIN IS 10 LBS.
WARNING: ENSURE THE KEY IS TURNED COUNTERCLOCKWISE AND THAT THERE ARE NO OBJECTS INTERFERING
WITH THE WORK SURFACE BEFORE ATTEMPTING TO CLOSE/LOCK. FAILURE TO DO SO COULD LEAD TO DAMAGE
OF THE WORK SURFACE AND/OR LOCKING MECHANISM.
WARNING: THE WORK SURFACE IS MEANT FOR LIGHT DUTY USE ONLY, SUCH AS USE AS A WRITING SURFACE AND
FOR RESTING LIGHT OBJECTS UP TO MAXIMUM 10 LBS. IMPROPER USE CAN RESULT IN DAMAGE TO THE WORK
SURFACE.
Unlock
Work Surface Lock
Main Bin
Lock
Open
Close
Figure 1
Work Surface
Figure 2
www.amico.com 26
