Section 5: Device Installation

Mounting a Keyboard and Mouse

1. Remove the backing on 3 (or half of given) dual locking pads and adhere to bottom of keyboard, spaced evenly
apart (Figure 1).
2. Remove the backing on the remaining dual locking coins and attach them to those on the bottom of the keyboard
(Figure 2).
3. Carefully position the keyboard on the keyboard tray and firmly press down while supporting the keyboard tray
from the bottom (Figure 3).
4. Place the mouse into the mouse holder (Figure 4).
5. Secure the mouse and keyboard cords to the back of the keyboard tray (Figure 5).
6. Route the cords through the bottom of the main bin (Figure 6). Ensure that there is enough slack in the cords for
full adjustability of the keyboard tray into the progessor port (outer most position).
WARNING: DO NOT OVERLOAD OR LEAN ON THE KEYBOARD TRAY (MAX LOAD = 10 LBS).
Dual Locking Coins
Figure 1
Figure 4
15 Amico Accessories Inc.
Figure 2
Figure 5
Figure 3
Figure 6
(View underneath bin)
