Section 4: Device Installation

Mounting a Computer (LCD Carts Only)

1. To open the Worksurface, insert the key (provided by Amico) into the lock on the Worksurface and turn
counterclockwise (ccw) to unlock the Worksurface.
2. Lift the Worksurface upwards (as shown in Figure 1) to access the interior of the main bin.
3. Place the computer (not provided) carefully inside the main bin and plug the power cord into the supplied power
bar. See page 2 for size restrictions.
4. Plug all USB cables into the computer.
NOTE: A USB HUB (NOT PROVIDED) MAY BE REQUIRED.
5. To close, lower the Worksurface until it is resting on the main bin and turn the key clockwise (cw) to lock.
WARNING: ENSURE THAT THE KEY IS TURNED COUNTERCLOCKWISE BEFORE ATTEMPTING TO CLOSE THE
WORKSURFACE. FAILURE TO DO SO COULD LEAD TO DAMAGE TO THE WORKSURFACE AND/OR THE LOCKING
MECHANISM.
Unlock
Worksurface Lock
Main Bin
Lock
Open
Close
Figure 1
Computer
(not provided)
Power Bar
Worksurface
Figure 2
www.amico.com 8
