背挂丝管冷凝器
Back hanging wire tube condensor
压缩机仓管路系统
Piping system in the compressor case
1.压缩机
Compressor
2.排气蒸发管
Exhaust transition pipe
3.冷凝器
Condenser
4.防露管
Anti-condensationg tube
接水盘
Drain tray
接水盘
Drain tray
None
Service Manual_2018-V2.0
5.干燥过滤
Dry filter
6.毛细管
Capillary
7.回气换热管
Suction pipe
8.吸气连接管
Return transition pipe
24
