Service Manual_2019-V2.0
Service Manual
COMPACT SERIES
Applicable Models
Model Code
Applicable Models
HS-125LN
UR-BC96CM-ST
22031010003802
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
1
Advertisement
Table of Contents
Related Manuals for Midea UR-BC96CM-ST
Summary of Contents for Midea UR-BC96CM-ST
- Page 1 Applicable Models Model Code Applicable Models HS-125LN UR-BC96CM-ST 22031010003802 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to...
- Page 2 Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof. Midea Refrigerators Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Refrigerators.
-
Page 3: Table Of Contents
Service Manual_2019-V2.0 Contents 1. SIGNIFICANT UPDATE NOTES (NONE) ......................5 2. SAFETY WARNING CODE ........................... 6 2.1 W ........................... 6 ARNING FOR OPERATION SAFETY ......................... 8 2.2 S AFETY INSTRUCTION FOR REFRIGERANT 3. TRANSPORT ................................. 9 ................................... 9 3.1 H ANDLING 4. - Page 4 Service Manual_2019-V2.0 12. TROUBLESHOOTING METHOD ........................27 12.1 N ................................. 27 OT COOLING ..........................28 12.2 N O WORKING OF COMPRESSOR ...................... 28 12.3 T HERMOSTAT MALFUNCTION NDERCOOLING 12.4 I ........................29 NSIDE FROSTING NO DEFROSTING ................29 12.5 I NSIDE FROSTING NO DEFROSTING AINTENANCE GUIDELINES...
-
Page 5: Significant Update Notes (None)
Service Manual_2019-V2.0 1. Significant update notes (None) -
Page 6: Safety Warning Code
Service Manual_2019-V2.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. - Page 7 Service Manual_2019-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
-
Page 8: Safety Instruction For Refrigerant
Service Manual_2019-V2.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: Transport
Service Manual_2019-V2.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: Installation And Commissioning
Service Manual_2019-V2.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: Left Or Right Open Door Reversal
Service Manual_2019-V2.0 4.4 Left or right open door reversal Door reversal Dismantle the upper hinge cover，screws and upper hinge，and remove the plastic screw hole caps from the other side. Dismantle the door and the bottom hinge assembly and adjustable foot, then assemble the bottom hinge assembly and adjustable foot on other side. -
Page 12: Product Configuration And Dimension
Service Manual_2019-V2.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber None 1.Temperature control mdodule 2.Glass shelf 3. -
Page 13: External Dimension
Service Manual_2019-V2.0 5.2 External dimension Description Code Size (mm) Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. w) Width (Door open 180 deg. w) Depth (Door open 180 deg. w) (The picture is only for reference) -
Page 14: Location Of S/N
Service Manual_2019-V2.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 15: Product Specification
Service Manual_2019-V2.0 6. Product specification 6.1 Electrical parameters Applicable Models HS-125LN Product Name UR-BC96CM-ST Product Code 22031010003802 Item Specification Specification Refrigerant R600a Compressor FZ35C1M Starter(PTC) QP2-4R7 Overload protector(OLP) DRB18T61A1 Integrate PTC+OLP Variable frequency driver board None Capacitor None Power filter None Rmc: 13.7±7%Ω... -
Page 16: Circuit Diagram
Service Manual_2019-V2.0 6.3 Circuit diagram... -
Page 17: Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_2019-V2.0 7. Refrigerating piping system and circulating route of cooling air 7.1 Refrigerating piping system ❶Compressor❷Condenser❸Dry filter❹Capillary tube❺Evaporator❻Suction tube❶Compressor... -
Page 18: Dismantling Of Parts
Service Manual_2019-V2.0 8. Dismantling of parts 8.1 Parts on the door Door seal It's more convenient to pull out from the corner. Take the door seal ①out of door liner; When reloading, the door must be installed into the tank, carefully pressed flat, and check whether there is a gap between the door seal and the box body. -
Page 19: Light System
Service Manual_2019-V2.0 8.3 Light system Light Light of the refrigerating The light at the right of refrigerator chamber. 1、Remove the light cover 2、Loosen the thermostat knob and fastening screw, and remove the thermostat box assembly 3、Remove the connector 4、Remove the light Light switch There is a light switch on the side wall of the refrigerating... - Page 20 Service Manual_2019-V2.0 1） Cut off the power, remove the goods in the refrigerator, with the tape to make the door fixed firmly and prevent the door dropping when the refrigerator dumping. 2） Slowly tilt the refrigerator forward, relying on the wall or a solid enough object, leaving space to facilitate the operation.
- Page 21 Service Manual_2019-V2.0 5）Remove the clipping strip Slowly pull it out 6）Remove the protective cover -Pry the protective cover slowly from the upper part, -Pull it out and remove it. 7）Remove the starter and protector Unplug the starter and protector (you can use a screwdriver to pry it slowly) 8）Loosen the screw of the compressor bottom plate, remove the floor together with the compressor from the...
- Page 22 Service Manual_2019-V2.0 10）Use Pipe cutter cut off the condenser tube❽, then Shear off capillary ❾ by the capillary tube scissors. 11）Replace the compressorand welding the compressor pipeline.-❿Welding the process pipeline.-⓫Welding the low-pressure muffler.-⓬Welding the high-pressure exhaust pipe. 12）Replace the filter, Cu-Fe tubes welding ⓭ used Ag welding rod, Cu-Cu tubes welding ⓮...
- Page 23 Service Manual_2019-V2.0 14）Perfusion refrigerant. 15）Use the vise grip pliers clamp the middle of the process pipe, then seal welding process tube⓯⓰. Piping system in the compressor case ❶Dry filter ❸ Compressor ❷ Suction transition tube ❹ Right condenser Drain tray Drain tray...
-
Page 24: Temperature Sensing System
Service Manual_2019-V2.0 9. Temperature sensing system 9.1 Thermostat Thermostat 1.Remove the nail on the thermostat box assembly. Remove the screws of the fixed temperature control box with a screwdriver. 2.Pull out the knod, remove the socket the terminal, replace the thermostat... -
Page 25: Function And Operation
Service Manual_2019-V2.0 10. Function and operation 10.1 Operation panel Direct cooling mechanical refrigerator, through the thermostat knob to adjust the stalls. 10.2 Temperature setting Turn the temperature control knob to MAX, the internal temperature of the refrigerator becomes lower. Turn the temperature control knob to MIN, the internal temperature of the refrigerator becomes higher. Recommended: "... -
Page 26: Compressor
Service Manual_2019-V2.0 11.Compressor 11.1 Compressor on and off Control specifications 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤ Trt； 1.2 When all the following conditions are met, the compressor starts up: 1) Tr ≥Trk; ★When 1.1 and 1.2 are not satisfied, the compressor maintains the original state... -
Page 27: Troubleshooting Method
Service Manual_2019-V2.0 12. Troubleshooting Method 12.1 Not cooling... -
Page 28: No Working Of Compressor
Service Manual_2019-V2.0 12.2 No working of compressor 12.3 Thermostat malfunction-Undercooling... -
Page 29: Inside Frosting, No Defrosting
Service Manual_2019-V2.0 12.4 Inside frosting, no defrosting 12.5 Inside frosting, no defrosting-Maintenance guidelines... -
Page 30: Light Is Not On
Service Manual_2019-V2.0 12.6 Light is not on... -
Page 31: Noise
Service Manual_2019-V2.0 12.7 Noise... -
Page 32: Figures And Details Of Repair Parts
Service Manual_2019-V2.0 13. Figures and details of repair parts See this section in the TSP. - Page 33 MIDEA appliances after sales website tsp.midea.com For more information about Midea appliances after sales, please visit the tsp.midea.com For more information about the service manual, please visit the tsp.midea.com For more information about the EV and SBOM, please visit the...
