维修手册
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
本手册主要讲授方法，具体的作业技能需要工程师通过日常工作积累。
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
Service Manual
市场型号
Applicable Models
HS-109FN
HS-109FN
HS-109FN
本手册中图片均为参考示意图，具体外观和配置以实物为准。
编制
毕岗
评价工程师 QA:吴信兵
审核
SVC:刘记成
会签
陈龙
经营长:张华伟
批准
SVC:光陶帅
COMPACT SERIES
工厂型号
Model Code
Applicable Models
UR-BD84CM-ST
22031010000072
UR-BD84CM-ST
92031010Z01165
UR-BD84CM-ST
92031010Z01162
1
Service Manual_2018-V2.0
基准编码
Advertisement
Table of Contents
Related Manuals for Midea COMPACT Series
Summary of Contents for Midea COMPACT Series
- Page 1 Service Manual_2018-V2.0 维修手册 Service Manual COMPACT SERIES 市场型号 工厂型号 基准编码 Applicable Models Model Code Applicable Models HS-109FN UR-BD84CM-ST 22031010000072 HS-109FN UR-BD84CM-ST 92031010Z01165 HS-109FN UR-BD84CM-ST 92031010Z01162 本手册中图片均为参考示意图，具体外观和配置以实物为准。 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product.
- Page 2 Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof. Midea Refrigerators Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Refrigerators.
-
Page 3: Table Of Contents
Service Manual_2018-V2.0 Contents 1. 重要更新说明 SIGNIFICANT UPDATE NOTES(NONE) ..................5 2. 安全警示规范 SAFETY WARNING CODE ......................6 2.1 作业安全警告 W ....................6 ARNING FOR OPERATION SAFETY 2.2 冷媒安全须知 S ..................8 AFETY INSTRUCTION FOR REFRIGERANT 3. 运输 TRANSPORT ..............................9 3.1 搬运 H ................................. - Page 4 Service Manual_2018-V2.0 10.2 档位设定 T ........................26 EMPERATURE SETTING 10.3 门开提示和门开报警 O ) ....................26 PEN DOOR ALARM 10.4 除霜功能 D ........................26 EFROSTING FUNCTION 11. 压缩机 COMPRESSOR ............................. 27 11.1 压缩机的开停控制规则 C ..........27 OMPRESSOR ON AND OFF ONTROL SPECIFICATIONS 12.
-
Page 5: 重要更新说明 Significant Update Notes(None)
Service Manual_2018-V2.0 重要更新说明 Significant update notes(None) 涉及 C、D 类重要设计变更时，需要在本章节添加相应的内容或文件，且以下情况的变更必须 体现:1)电控件结构、原理发生变更时；... -
Page 6: 安全警示规范 Safety Warning Code
Service Manual_2018-V2.0 安全警示规范 Safety Warning Code 作业安全警告 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. - Page 7 Service Manual_2018-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
-
Page 8: 冷媒安全须知 Safety Instruction For Refrigerant
Service Manual_2018-V2.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: 运输 Transport
Service Manual_2018-V2.0 运输 Transport 搬运 Handling 搬运 Handling 1) 在移动中保护冰箱，如图所示，使用加垫的手推车。 2) 拆除冰箱所有包装材料和底垫再搬运到室内安放。 3) 放置 2 小时再通电运行。 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: 安装和调试 Installation And Commissioning
Service Manual_2018-V2.0 安装和调试 Installation and commissioning 门体拆装 Door Disassembly and Assembly(None) 当整机无法进入室内时，需要对门体拆除。The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 安装位置 Installation location 安装位置 Installation location 需要选择通风的位置，有利于散热提升性能、降低能耗。 Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: 左、右开门更换 Left Or Right Open Door Reversal
Service Manual_2018-V2.0 左、右开门更换 Left or right open door reversal 左右换门 Door reversal 断开冰箱电源，移除门搁架上面的所有食物； Unplug your refrigerator and remove all food from the door shelves. 用一字螺丝刀拆下左边的孔盖和右上铰链罩， 然后用十 字螺丝刀拆下固定上铰链的 3 个螺栓，拆下上铰链。 Remove the left cover plate and the right top hinge cover, then unscrew and remove the right top hinge. -
Page 12: 门锁安装 Installation Of Door Lock（None
Service Manual_2018-V2.0 1)安装门把手之前，请注意安全，以防把手脱落造成人身 ④ 伤害。Precautions shall be taken to prevent fall of the handle from causing any personal injury. 2)安装步骤 Assembly steps a、用自备工具内六角扳手将螺钉安进门体螺丝孔并拧紧。 Use allen wrench to fix screws into the screw hole tightly. b、把手拆卸请参照安装逆方向。The reverse operation is for disassembly. 门锁安装... -
Page 13: 产品配置和尺寸 Product Configuration And Dimension
Service Manual_2018-V2.0 产品配置和尺寸 Product configuration and dimension 主要部件及名称 Main parts and their names （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) 冷冻室 冷藏室 Freezer chamber Refrigerator chamber 冷冻上抽屉 F upper drawer None 冷冻下抽屉... -
Page 14: 外观尺寸 External Dimension
Service Manual_2018-V2.0 外观尺寸 External dimension 描述Description 代码Code 尺寸 Size (mm) 高度Height to Top of Case 宽度Width 深度/箱体Depth w/Cabinet 深度/含门体Depth w/Door 深度/含门把手Depth w/Handle 深度/开门90° Depth (Door open 90 deg. w) 1078 深度/开门135° Depth (Door open 135 deg. w) 宽度/开门135° Width (Door open 135 deg. w) （本图片为参考示意图）(The picture is only for reference) -
Page 15: 序列号的位置 Location Of S/N
Service Manual_2018-V2.0 序列号的位置 Location of S/N 有些产品在箱体的右侧的下部也有 S/N. Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 16: 产品规格 Product Specification
Service Manual_2018-V2.0 产品规格 Product specification 电气参数 Electrical parameters 市场型号 Applicable Models HS-109FN 产品名称 Product Name UR-BD84CM-ST 产品编码 Product Code 22031010000072 项目 规格 规格 Item Specification Specification 制冷剂 Refrigerant R600a 压缩机 Compressor FZ40E1J 启动器 Starter(PTC) QP2-4R7 过载保护器 Overload protector(OLP) DRB17N61A1 整体式启动器+保护器 Integrate PTC+OLP None 变频驱动板... -
Page 17: 电路图 Circuit Diagram
Service Manual_2018-V2.0 电路图 Circuit diagram... -
Page 18: 制冷管路系统和冷气循环路线 Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_2018-V2.0 制冷管路系统和冷气循环路线 Refrigerating piping system and circulating route of cooling air 制冷管路系统 Refrigerating piping system 压缩机 Compressor---右冷凝器 Right condenser----防凝露管 Right condenser---左冷凝器 Left condenser---干燥过滤器 filter---毛细管 Capillary tube---冷冻蒸发器 evaporator---回气管 Suction tube---压缩机 Compressor 特殊焊点位置 Special soldering position （None）... -
Page 19: 部件拆装 Dismantling Of Parts
Service Manual_2018-V2.0 部件拆装 Dismantling of parts 门上部件 Parts on the door 门封条 Door seal 从拐角拉出更加方便 It's more convenient to pull out from the corner. 重新装入时，必须装到门胆槽内，仔细压平，并检查门封 条是否与箱体间有缝隙。 When reloading, the door must be installed into the tank, carefully pressed flat, and check whether there is a gap between the door seal and the box body. -
Page 20: 灯系统 Light System
Service Manual_2018-V2.0 灯系统 Light system 灯 Light 冷藏室顶灯 Light of the refrigerating None 冷冻室灯 Light of the freezing None 灯开关 Light switch None 蒸发器及化霜系统 Evaporator and Defrost system 冷冻室蒸发器 Evaporator in freezing chamber 不可拆 不可拆 not replaceable not replaceable 压缩机仓 Compressor case 后盖板... - Page 21 Service Manual_2018-V2.0 3）截断压缩机管路 Cut off the compressor pipeline. -❶截断工艺管 Cut off the process pipeline. -❷截断低压回气管 Cut off the low-pressure muffler. -❸截断高压排气管 Cut off the high-pressure exhaust pipe. 4-1）拆卸螺钉 Remove the screws(for some models) -外侧 2 个螺钉 Two screws outside -内侧 1 个螺钉 One screw inside 4-2）拆卸卡簧...
- Page 22 Service Manual_2018-V2.0 7）拆卸启动器和保护器 Remove the starter and protector 依次拔下启动器与保护器（可以使用螺丝刀慢慢撬下） Unplug the starter and protector (you can use a screwdriver to pry it slowly) 8）松开压缩机底板的固定螺钉，将压缩机连同底板一起从 箱体上拆除。Loosen the screw of the compressor bottom plate, remove the floor together with the compressor from the box.
- Page 23 Service Manual_2018-V2.0 11）更换压缩机进行管路焊接 Replace the compressor and welding the compressor pipeline. -❿焊接工艺管 Welding the process pipeline. -⓫焊接低压回气管 Welding the low-pressure muffler. -⓬焊接高压排气管 Welding the high-pressure exhaust pipe. 12）更换干燥过滤器，铜-铁管路连接⓭使用银焊条，铜- 铜管路连接 ⓮使用铜焊条。 Replace the filter, Cu-Fe tubes welding ⓭ used Ag welding rod, Cu-Cu tubes welding ⓮ used Cu welding rod.
- Page 24 Service Manual_2018-V2.0 背挂丝管冷凝器 Back hanging wire tube condensor None None 压缩机仓管路系统 Piping system in the compressor case 1.压缩机 Compressor 5.干燥过滤 Dry filter 2.排气蒸发管 Exhaust transition pipe 6.毛细管 Capillary 3.冷凝器 Condenser 7.回气换热管 Suction pipe 4.防露管 Anti-condensationg tube 8.吸气连接管 Return transition pipe 接水盘...
-
Page 25: 感温系统 Temperature Sensing System
Service Manual_2018-V2.0 感温系统 temperature sensing system 温控器 Thermostat 温控器 Thermostat 1.使用螺丝刀拧开温控盒螺丝，拧掉温控旋钮 Remove the screws on the temperature-control box, Remove the knob 2.用螺丝刀拧掉固定温控器罩的螺钉 Loosen the nut 3.从箱体中取出温控器罩 Pull out the thermostat box 4.从温控器罩中取出温控器、线束 Remove the thermostat and wire from the box... -
Page 26: 功能和操作 Function And Operation
Service Manual_2018-V2.0 功能和操作 Function and operation 操作面板 10.1 Operation panel 直冷机械冰箱，通过温控器旋钮来调节档位 Direct cooling mechanical refrigerator, through the thermostat knob to adjust the stalls. 档位设定 10.2 Temperature setting 温控器旋钮调至最大档（MAX)，冰箱内部温度越低; 温控器旋钮调至最小档(MIN)，冰箱内部温度越高。 注意：请在 MAX 档位与 MIN 档位之间使用调节。 Turn the temperature control knob to MAX, the internal temperature of the refrigerator becomes lower. Turn the temperature control knob to MIN, the internal temperature of the refrigerator becomes higher. -
Page 27: 压缩机 Compressor
Service Manual_2018-V2.0 压缩机 Compressor 压缩机的开停控制规则 11.1 Compressor on and off Control specifications 1.1 满足下列条件之一，压缩机停机： Tr ≤ Trt； 压缩机连续运行时间超过（含）3 小时（停机 5 分钟）； 1.2 下列条件全部满足时，压缩机开机： Tr ≥Trk 压缩机停机时间 ≥ 5min ★在 1.1 项、1.2 项均不满足的情况下，压缩机维持原状态不变。 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤... -
Page 28: 故障排除方法 Troubleshooting Method
Service Manual_2018-V2.0 故障排除方法 Troubleshooting Method 不制冷 12.1 Not cooling... -
Page 29: 压缩机不工作 No Working Of Compressor
Service Manual_2018-V2.0 压缩机不工作 12.2 No working of compressor 温控器故障-过冷 12.3 Thermostat malfunction-Undercooling... -
Page 30: 内部结冰霜、不化霜 Inside Frosting, No Defrosting
Service Manual_2018-V2.0 内部结冰霜、不化霜 12.4 Inside frosting, no defrosting 内 部 结 冰 霜 、 不 化 霜 - 维 修 指 引 12.5 Inside frosting, no defrosting-Maintenance guidelines... -
Page 31: 灯不亮 Light Is Not On
Service Manual_2018-V2.0 灯不亮 12.6 Light is not on... -
Page 32: 噪音 Noise
Service Manual_2018-V2.0 噪音 12.7 Noise... -
Page 33: 维修零部件图示和明细 Figures And Details Of Repair Parts
Service Manual_2018-V2.0 维修零部件图示和明细 Figures and details of repair parts 此部分内容请到 TSP 系统中查看 See this section in the TSP. - Page 34 MIDEA appliances after sales website tsp.midea.com For more information about Midea appliances after sales, please visit the tsp.midea.com For more information about the service manual, please visit the tsp.midea.com For more information about the EV and SBOM, please visit the...
