7）拆卸启动器和保护器 Remove the starter and
protector
依次拔下启动器与保护器（可以使用螺丝刀慢慢撬下）
Unplug the starter and protector (you can use a
screwdriver to pry it slowly)
8）松开压缩机底板的固定螺钉，将压缩机连同底板一起从
箱体上拆除。Loosen the screw of the compressor bottom
plate, remove the floor together with the compressor from
the box.
9）使用扳手依次拆卸❹❺❻❼螺栓，更换压缩机后逆向
操作安装。Use the wrench to remove the bolts by
steps❹❺❻❼, replace the compressor and reverse
process can complete installation.
10）用割管器割断冷凝器❽，用毛细管钳剪断毛细管❾
Use Pipe cutter cut off the condenser tube❽, then Shear
off capillary ❾ by the capillary tube scissors.
