Service Manual_2023-V1.0
Service Manual
COMPACT SERIES
Applicable Models
Model Code
Applicable Models
HS-108FN
CE-BD83CM-JQ
22031010004122
The picture in this service manual is only for reference, and specific
appearance and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer
to accumulate through the daily work.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea CE-BD83CM-JQ
Summary of Contents for Midea CE-BD83CM-JQ
- Page 1 Applicable Models Model Code Applicable Models HS-108FN CE-BD83CM-JQ 22031010004122 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer...
- Page 2 Service Manual_2023-V1.0 WARNING Important Safety Notice There are special components used in this equipment which are important for safety. These parts are marked in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.
-
Page 3: Table Of Contents
Service Manual_2023-V1.0 Contents 1. SIGNIFICANT UPDATE NOTES (NONE) ......................5 2. SAFETY WARNING CODE ..........................6 2.1 W ........................ 6 ARNING FOR OPERATION SAFETY 2.2 S .......................8 AFETY INSTRUCTION FOR REFRIGERANT 3. TRANSPORT ..............................9 3.1 H ..............................9 ANDLING 4. INSTALLATION AND COMMISSIONING ......................10 4.1 D ...................... - Page 4 Service Manual_2023-V1.0...
-
Page 5: Significant Update Notes (None)
Service Manual_2023-V1.0 1. Significant update notes (None) -
Page 6: Safety Warning Code
Service Manual_2023-V1.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. -
Page 7: Connecting Electricity
Service Manual_2023-V1.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. -
Page 8: Grounding Requirement
Service Manual_2023-V1.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: Transport
Service Manual_2023-V1.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: Installation And Commissioning
Service Manual_2023-V1.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: Left Or Right Open Door Reversal
Service Manual_2023-V1.0 4.4 Left or right open door reversal Door reversal Unscrew the top cover screws 2) Remove the top cover 3) Remove the hinge cover. Unscrew screws. Remove the upper hinge. 4) Remove the door. Unscrew screws and levelling feet. Remove the lower hinge adjust feet assembly. -
Page 12: Installation Of Handle（None
Service Manual_2023-V1.0 6) Place the door stopper and axle sleeve in the opposite side. 7) Place the F door. Place and fix the upper hinge. Fix the hinge cover. 8) Place the top cover. 4.5 Installation of handle（None） 4.6 Installation of door lock（None）... -
Page 13: Product Configuration And Dimension
Service Manual_2023-V1.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber 1.Screen printing knob2.Temperature control None panel 3.F upper drawer4.F bottom drawer5.Freezer door assembly... -
Page 14: External Dimension
Service Manual_2023-V1.0 5.2 External dimension Description Code Size (mm) Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. w) 1078 Depth (Door open 135 deg. w) Width (Door open 135 deg. w) (The picture is only for reference) -
Page 15: Location Of S/N
Service Manual_2023-V1.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 16: Product Specification
Service Manual_2023-V1.0 6. Product specification 6.1 Electrical parameters CE-BD83CM-JQ Product Name Applicable Models HS-108FN Item Specification Refrigerant R600a Compressor SZ45Y1J Starter(PTC) QPS2-B15MG1 Overload protector(OLP) DRB12N61A1 Integrate PTC+OLP ZHB31-120P15 Variable frequency driver board None Capacitor Power filter None Rmc：51.5±7%Ω Winding resistance of compressor Rsc：14.0±7%Ω... -
Page 17: Circuit Diagram
Service Manual_2023-V1.0 6.3 Circuit diagram Thermostat Overload Protector Power Plug Compressor... -
Page 18: Dismantling Of Parts
Service Manual_2023-V1.0 8. Dismantling of parts 8.1 Parts on the door Door seal Door seal is installed into door liner groove. 1） Open the refrigerator door; Take the door seal ①out of door liner; Door tray None 8.2 Parts inside the refrigerator Drawer flip None Shelves...
