WISE WS a
Instructions for Use

Symbol explanation

Symbols on the machine
This product complies
with applicable EU directives
Symbols in this user manual
Warning/Caution!

Application area

The product is a weather station with communication via
Modbus intended to control solar shading within Swegon's
demand-controlled indoor climate system WISE.
The product may not be used for anything other than its
intended use.

General

Read through the entire instructions for use
before you install/use the product and save the
instructions for future reference. It's not permis-
sible to make changes or modify this product
other than those specified in this document.

The packaging contains the following items

1 x WISE WS
1 x Connection 10 m
1 x Wall mounting bracket
1 x Instructions for Use
The document was originally written in Swedish

Protective equipment

Always use appropriate personal protective
equipment for the work in question, in the
form of gloves, respirators and protective
glasses during handling, installation, cleaning
and service/maintenance.

Electrical safety

Permitted voltage, see "Electrical data".
It's not permissible to insert foreign objects
into the product's contactor connections or the
electronics's ventilation openings; risk for short-
circuiting.
Cable sizing must be carried out for cabling between the
product and the power supply source.
Disconnect the power supply when working on products
that are not required to run in production.
Always follow the local/national rules for who shall be
permitted to carry out this type of electrical installation.

Handling

• The product must be handled with care.

Installation

• Assemble the product according to applicable industry
regulations.
• Install the product for easy access during service/
maintenance.
• Check to make sure that the product doesn't have any
visible defects.
• Check that the product is properly secured after it has
been installed.
• Check that all cables are properly secured in place after
installation.
28/10/2021
