- Page 1 Swegon CASA Smart ® Blues | Salsa | Samba | Tango | Jazz KÄSIKIRJA HANDBOK HÅNDBOK HANDBOOK P_Hoods_l-u/2020-12-22...
-
Page 2: Important Information
Important information This document is intended for everyone involved in the installation work or use of a Swegon CASA cooker hood. Read this Instructions for Use before you use the cooker hood. Save the Instructions for Use for future use. If you mislay the Instruction for Use, you can download a new copy from our website. -
Page 3: Table Of Contents
8.3 Outputs of the components ................. 46 8.4 Control curves ..................... 47 8.4.1 Basic ventilation ..................47 8.4.2 Boosted ventilation ................... 47 8.5 Connections ....................48 8.6 Internal connections ..................48 NOTE! The manual’s original language is Finnish. Swegon reserves the right to alter specifications. 2020-12-22... -
Page 4: General
Thanks to an elegant and distinct design, all Swegon CASA cooker hoods blend in as part of the furnishings in a modern kitchen. Particular attention has been directed during the design phase to user comfort and the hoods feature smooth, easy-to-clean surfaces. -
Page 5: Commissioning
See the control curve for basic Operation with power roof ventilator ventilation in the “Technical data” section. Swegon CASA cooker hoods can be used to The air flow is obtained by measuring the control a power roof ventilator, equipped with pressure differential across the control damper an EC-fan. - Page 6 If you do not acknowledge and do not touch any of the hood’s but- tons for ten minutes, the cooker returns to normal mode, and the settings are not saved. Swegon reserves the right to alter specifications. 2020-12-22...
-
Page 7: Use
The lighting output can be regulated with a long press on the button, the brightness then changes. Pressing the button again Swegon CASA cooker hoods feature a touch changes the brightness in the other direc- panel (except Tango), from where you can tion. -
Page 8: Accessories
7.3 Twist fan unit (TTEC) The Safera cooker guard accessory can easily Swegon CASA Twist is a fan unit for cooker be connected to Smart cooker hoods – the hoods. The fan unit can also be used as a power supply comes from the hood. -
Page 9: Technical Data
The cooker hoods are tested to IEC 61591:2005 ( ) (Tango 70 tested with 30 mm rear cover plate) and EN13141-3:2017 ( ) Standards. The measurements were made at a distance of 60 cm from the cooker. Swegon reserves the right to alter specifications. 2020-12-22... -
Page 10: Acoustic Data
Hood + Safera Safety stove guard Power source 24 V, 12 W, 0,5 A 24 V, 24 W, 1 A 24 V, 20 W, 0,83 A Lighting effect Total output 12 W 24 W 20 W Swegon reserves the right to alter specifications. 2020-12-22... -
Page 11: Control Curves
0.31 0.44 0.53 0.65 0.80 0.98 1.17 1.31 9 10 11 12 13 14 15 16 17 18 19 20 21 Air flow rate (l/s) 8.4.2 Boosted ventilation Air flow rate (l/s) Swegon reserves the right to alter specifications. 2020-12-22... -
Page 12: Connections
GR = Green RD = Red YE = Yellow 1S000417a 1. Control card 2. LED lighting (4000 K) 3. Damper motor 4. Control panel with touch electronics 5. Control panel with buttons (Tango) Swegon reserves the right to alter specifications. 2020-12-22...
