Remote Screen Indicators - Rotenso CONTROL Series User Manual

ECO ...
12. HUMIDITY
Adjust the room humidity during Dry operation in a range of 35%~85%. Press this button to increase the
humidity in 5% increments.
Note: After setting, the humidity settings will display on the screen.
13. LED
Turns indoor unit's LED display and air conditioner buzzer on and off (model dependent), which create a
comfortable and quiet environment.
14. TURBO
Enables unit to reach present temperature in shortest possible time.

5. REMOTE SCREEN INDICATORS

Information are displayed when the remote controller is power up.
All indicators shown in the figure are for the purpose of clear presentation. But during the actaul operation,
only the relative function signs are shown on the display window.
7
5
REMOTE CONTROL SUPPORT
1
4
NOTE
Remote contol - DEFO
2
3
6
User manual
EN
21
