Summary of Contents for Classic Exhibits Sacagawea VK-1210
- Page 1 Step 1 Order #XXXXX - Sacagawea - VK-1210 - General Layout 866.652.2100 10’ Plan View 10’ WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING © 2012 w w w . c l a s s i c e x h i b i t s . c o m Page 1 of 3...
- Page 2 Step 2 Order #XXXXX - Sacagawea - General Information 866.652.2100 Using You Set-up Instructions: The Visionary Designs Set-up Instructions for Sacagawea displays are created Hex Key Tool Typical Connection Typical Connection specifically for your configuration. They are laid out sequentially, including an exploded view of the entire display and a logical series of detailed steps for assembly.
- Page 3 Step 1 Order #XXXXX - Sacagawea - Backwall Assembly 866.652.2100 Item Qty. Description Steps: Base Plate 1) Attach base plates [1] to lower verticals [2a,3a] with bolts. 2a/2b 42” Vertical Extrusion 2) Connect upper verticals [2b,3b] to lower verticals [2a,3a] with connection bars [b]. 3a/3b 42”...
- Page 4 Step 2 Order #XXXXX - Sacagawea - Wing and Counter Attachment 866.652.2100 Steps: 1) Attach lights as indicated. 2) Attach assembled counter support [10/11] to vertical where indicated. 3) Attach support leg [10a] to counter support [10/11]. 4) Attach flange plate [11a] to top of curved extrusion [10] as shown. 5) Attach counter top to support, see counter top attachment detail.
- Page 5 Step 3 Order #XXXXX - Sacagawea - LTK-1001 - Pedestal Assembly 866.652.2100 Setup Instructions: A) Use standoff screws to secure the front panel with door and back panel of the pedestal to the side panels. B) After assembling front, back, and side panels, slide floor into the bottom of the pedestal.
- Page 6 Order #XXXXX - Case Packing Instruction - Case 1 of 2 866.652.2100 Top View of Each Level Backwall Components Backwall Halogen Lights Counter Wing Panels Support Graphics Base Plates Literature Pockets Counter Setup Hardware Level 1 Level 2 Level 3 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...
- Page 7 Case Packing Instruction - Case 2 of 2 Order #XXXXX - 866.652.2100 Top View of each Level Top View Counter Top Floor and Internal Shelf (2) Side Panels Back Panel Front Panel w/ Door Level 1 Level 2 Level 3 Level 4 Level 5 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL...
