Step 1
Order #xxxxx - Sacagawea - VK-1232 - General Layout
866.652.2100
10'
Plan View
10'
WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL
SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING
© 2012
w w w . c l a s s i c e x h i b i t s . c o m
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SACAGAWEA DESIGNS VK-1232 and is the answer not in the manual?

Questions and answers

Related Manuals for Classic Exhibits SACAGAWEA DESIGNS VK-1232

Summary of Contents for Classic Exhibits SACAGAWEA DESIGNS VK-1232

  • Page 1 Step 1 Order #xxxxx - Sacagawea - VK-1232 - General Layout 866.652.2100 10’ Plan View 10’ WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING © 2012 w w w . c l a s s i c e x h i b i t s . c o m Page 1 of 5...
  • Page 2 Step 2 Order #xxxxx - Sacagawea - General Information 866.652.2100 Using You Set-up Instructions: The Visionary Designs Set-up Instructions for Sacagawea displays are created Hex Key Tool Typical Connection Typical Connection specifically for your configuration. They are laid out sequentially, including an exploded view of the entire display and a logical series of detailed steps for assembly.
  • Page 3 Step 1 Order #xxxxx - Sacagawea - Backwall Assembly 866.652.2100 Item Qty. Description Steps: Base Plate 1) Attach base plates [1] to lower verticals [2a,3a] with bolts. 2a/2b 42” Vertical Extrusion 2) Connect upper verticals [2b,3b] to lower verticals [2a,3a] with connection bars [b]. 3a/3b 42”...
  • Page 4 Step 2 Order #xxxxx - Sacagawea - Counter, Wing and Sign Attachment 866.652.2100 Steps: Item Qty. Description 1) Attach lights as indicated. 30.2” Curved Extrusion 2) Attach assembled counter support [10/11] to vertical where indicated. Leg Support 3) Attach support leg [10a] to counter support [10/11]. 12.184”w Horizontal Extrusion Monitor Mount 4) Attach flange plate [11a] to top of curved extrusion [10] as shown.
  • Page 5 Step 3 Order #xxxxx - Sacagawea - Canopy Assembly 866.652.2100 Steps: 1) Connect canopy pieces together as shown. 2) Apply pillow case graphic to assembled canopy Using Your Setup Instructions The Aero Overhead Sign Setup Instructions are created specifically for your configuration. They include an exploded view of the frame which is sequentially numbered.
  • Page 6 Step 4 Order #xxxxx - Sacagawea - LTK-1001 - Pedestal Assembly 866.652.2100 Setup Instructions: A) Use standoff screws to secure the front panel with door and back panel of the pedestal to the side panels. B) After assembling front, back, and side panels, slide floor into the bottom of the pedestal.
  • Page 7 Order #xxxxx - Case Packing Instruction - Case 1 of 2 866.652.2100 Top View Backwall Counter Canopy Pieces Wing Panels Support Graphics Base Plates Counter Level 1 Level 2 Level 3 Level 4 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING ©...
  • Page 8 Order #xxxxx - Case Packing Instruction - Case 2 of 2 866.652.2100 (2) Pedestal Components Top View Counter Top Floor and Internal Shelf (2) Side Panels Back Panel Front Panel w/ Door Level 1 Level 2 Level 3 Level 4 Level 5 WHEN DISASSEMBLING ALUMINUM EXTRUSION, TIGHTEN ALL SETSCREWS AND LOCKS TO PREVENT LOSS DURING SHIPPING...
