Summary of Contents for KTM 1290 SUPER ADVENTURE S 2021
- Page 1 SETUP INSTRUCTIONS 2021 1290 SUPER ADVENTURE S Art. no. 3214445en...
- Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
-
Page 4: Means Of Representation
1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
- Page 6 2 SETUP – Remove the handbrake pump from the transport holder. – Remove the screws and handlebar clamps. – Remove the transport holder. E02428-01 – Position the handbrake pump. Tighten the screws. Guideline Anti-rotation lock engages in the right switch unit. Screw, brake assem- 5 Nm (3.7 lbf ft) E02429-10...
- Page 7 SETUP 2 – Position the cable for the right-hand controls and secure with cable ties. – Attach the clutch line to the holder. E02431-10 – Preassemble the hand guards with screws and bushings. E02432-01 – Position the right hand guard. –...
- Page 8 2 SETUP – Mount damping rubbers , rubber grommets and speed nuts on the engine guard. – Mount spacers Guideline The spacer collar is facing inward. E02434-10 – Mount rubber grommets and spacers on the lower fuel tank covers. Guideline The spacer collar is facing inward.
- Page 9 8) – Charge the 12-V battery. ( p. 10) – Remove the remaining films. – Unpack and mount the KTM PowerParts included in the deliv- ery (optional). E02438-10 Info Read the accompanying KTM PowerParts fitting instruc- tions. – Attach the stickers included in the scope of supply (optional).
- Page 10 3 WORK Installing the windshield – Position windshield – Mount and tighten screws with the rubber bushings. Guideline Screw, windshield M5x14 3.5 Nm (2.58 lbf ft) E02252-11 Removing the rear right side cover Preparatory work – Remove the passenger seat. ( p.
-
Page 11: Mounting The Passenger Seat
WORK 3 Removing the passenger seat Condition The motorcycle is stationary. The engine is off. The ignition has been switched on or off for less than 1 minute. – Press seat release button – Raise the front of the passenger seat, pull it toward the fuel tank and take off from above. -
Page 12: Charging The 12-V Battery
3 WORK Mounting the front rider's seat Main work – Attach the recesses on the front rider's seat to the fuel tank at the desired seat position , and push the front rider's seat forward while lowering it at the rear. –... - Page 13 WORK 3 Preparatory work – Remove the passenger seat. ( p. 9) – Remove the front rider's seat. ( p. 9) – Disconnect the negative cable of the 12-V battery. ( p. 13) Main work – Connect a battery charger to the 12-V battery. Adjust the bat- tery charger.
- Page 14 3 WORK Caution Danger of accidents Electronic components and safety devices will be damaged if the 12-V battery is dis- charged or missing. If the 12-V battery is discharged or defective, malfunctions in the vehicle electronics can occur, espe- cially when starting. –...
- Page 15 WORK 3 Main work – Position the 12-V battery in the battery compartment. – Position positive cable and mount and tighten the screw. Guideline Screw, battery termi- M6x12 4.5 Nm (3.32 lbf ft) – Position negative cable and mount and tighten the screw. Guideline E02232-11 Screw, battery termi-...
- Page 16 3 WORK Main work – Disconnect negative cable of the 12-V battery. E02231-13 3.13 Connecting the negative cable of the 12-V battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep 12 V batteries out of the reach of children. –...
- Page 17 WORK 3 3.14 Setting the time and date Condition The motorcycle is stationary. – Press the SET button or RIGHT button when the menu is closed. – Press the UP button or DOWN button until Settings is marked. – Press the RIGHT or SET button to open the menu. –...
-
Page 18: Checking The Headlight Setting
3 WORK Setting the date – Press the UP or DOWN button until Set Date is marked. – Press the SET button to open the menu. – Press the UP or DOWN button until Day is marked. – Press the RIGHT or LEFT button until the current day is set. –... - Page 19 WORK 3 3.16 Adjusting the headlight range Preparatory work – Check the headlight setting. ( p. 16) Main work – Turn adjusting wheel to adjust the headlight range. Info Turn counterclockwise to increase the headlight range; turn clockwise to reduce the headlight range. If you have a payload, you may have to correct the headlight range.
- Page 20 3 WORK Guideline Maximum range of the RACE 1.5 m (4.9 ft) ON key around the antenna Info The range may be reduced by decreases in RACE ON key battery voltage and by interfering radio waves. If the battery voltage of the RACE ON key is too low, one of the ignition keys must be held in the area of the antenna and must be safely stored again after start- ing.
- Page 21 WORK 3 3.18 Opening fuel tank filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –...
- Page 22 3 WORK 3.19 Closing the fuel tank filler cap Warning Fire hazard Fuel is highly flammable, toxic and a health hazard. – Check that the fuel tank filler cap is locked cor- rectly after closing. – Change your clothing if fuel spills on them. –...
- Page 23 WORK 3 – Switch off the engine. – Open the fuel tank filler cap. ( p. 19) – Only insert the fuel nozzle to the specified dimension. Guideline 2.5 cm (0.98 in) Dimension – Fill the fuel up to the maximum level at lower edge of the filler neck.
-
Page 24: Technical Data
4 TECHNICAL DATA Chassis tightening torques Clamp distributor on the tank half 3 Nm (2.2 lbf ft) Cover, brake reservoir, rear 3.5 Nm (2.58 lbf ft) Radiator hose clamp 2.4 Nm (1.77 lbf ft) Screw, ball-head headlight holder EJOT ALtracs 5151 ®... - Page 25 TECHNICAL DATA 4 Screw, sliding seat bushing, wind- M5x20 4 Nm (3 lbf ft) shield Screw, splash protection, tail end M5x12 3 Nm (2.2 lbf ft) lower part Screw, throttle M5x25 3.5 Nm (2.58 lbf ft) Screw, top mask spoiler, fuel tank M5x12 2.5 Nm (1.84 lbf ft) fairing...
- Page 26 4 TECHNICAL DATA Screw, rear brake disc 14 Nm (10.3 lbf ft) Loctite ® 243™ Screw, rear cover M6x16 6 Nm (4.4 lbf ft) Screw, rear master cylinder M6x25 10 Nm (7.4 lbf ft) Loctite ® 243™ Screw, rear wheel speed sensor M6x16 8 Nm (5.9 lbf ft) Screw, seat bushing...
- Page 27 TECHNICAL DATA 4 Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) Nut, rear sprocket screw M10x1.25 50 Nm (36.9 lbf ft) Loctite ® 243™ Nut, turn signal M10x1.25 4 Nm (3 lbf ft) Screw, front brake caliper M10x1.5x55 45 Nm (33.2 lbf ft) Loctite ®...
- Page 28 5 SUBSTANCES Super unleaded (ROZ 95) Standard/classification – DIN EN 228 (ROZ 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specified standard. – Fuel with an ethanol content of up to 10% (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.g., M15, M85, M100) or more than 10% ethanol (e.g., E15, E25, E85, E100).
- Page 29 *3214445en* 3214445en 03/2021 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM KTM.com...
