Edge Fiberglass Base Placement - Inter-fab EDGE ANSI/NSPI-5 Assembly/Installation Instructions

I N S T A L L A T I O N M A N U A L
NOTE: READ THESE INSTRUCTIONS IN THEIR ENTIRETY BEFORE
ATTEMPTING THE INSTALLATION.
FIG. A – EDGE FIBERGLASS BASE PLACEMENT SPECIFICATIONS:
INTER-FAB CANNOT GUARANTEE CUSTOMER'S CONCRETE OR THICKNESS
NOTE: WHEN COPING IS USED, DO NOT SET FRONT JIG BOLTS CLOSER THAN 3" FROM THE
BACK EDGE OF THE COPING.
TABLE 3 – PLACEMENT CHART
ADDITIONALLY REFER TO: ANSI/NSPI-5 2003 American National Standard for Residential Inground Swimming
Pools and to page 5 for Inter-Fab Residential Inground Pool Minimum Specifications.
IMPORTANT:
THESE DIMENSIONS
ARE ACCURATE ONLY
FOR VERTICAL POOL
WALLS, TYPICALLY
GUNITE CONSTRUC-
TION, WITH LESS
THAN A 3' RADIUS TO
THE POOL FLOOR.
DUE TO THE VARYING
SIZES OF OTHER
POOLS, TYPICALLY
VINYL LINER CON-
STRUCTION, PLEASE
CONTACT CUSTOMER
SERVICE FOR PROPER
JIG PLACEMENT.
1-800-737-5386
* IMPORTANT: The distance for setting the front jig bolt (S) from the water's edge is valid only if the minimum water depth is maintained
at the tip of the board noted as point "A" in ANSI/NSPI-5 2003 American National Standard for Residential Inground Swimming Pools.
If minimum water depth is not maintained the distance (S) must be adjusted accordingly.
** "WA" dimension is valid only in conjunction with the minimum depth at point "A" for type pool in accordance with ANSI/NSPI-5
2003 American National Standard for Residential Inground Swimming Pools.
EDGE-IM Rev. 6/08 (BBK-EDGE INSTAL)
EDGE ANSI/
NOMINAL
DIVING NSPI-5
BOARD
SYSTEM POOL
LENGTH
PART # TYPE
EDGE-BASE 6'
EDGE-BASE 6'
EDGE-BASE 6'
EDGE-BASE 6'
EDGE-BASE 6'
EDGE-BASE 8'
EDGE-BASE 8'
EDGE-BASE 8'
EDGE-BASE 8'
EDGE-BASE 8'
E D G E ™ D I V I N G S Y S T E M
DISTANCE FROM
WATER'S EDGE TO
FORWARD JIG BOLT
(S)
I 31.5"
II 31.5"
III 25.5"
IV 19.5"
V 13.5"
Cannot put 8' jump board on type I pool
I
Cannot put 8' jump board on type II pool
II
III 44.25"
IV 38.25"
V 32.25"
6
MIN.
DISTANCE FROM OVERHANG
END OF BOARD TO PLUS OR
FORWARD JIG BOLT MINUS 3"
(WA)
49.5" 18"
49.5" 18"
49.5" 24"
49.5" 30"
49.5" 36"
68.25" 24"
68.25" 30"
68.25" 36"
MAX HEIGHT
OF BOARD
ABOVE
WATER
(HOW)
20"
20"
26"
30"
40"
26"
30"
40"
