I N S T A L L A T I O N M A N U A L
MINIMUM DIVING WATER ENVELOPE:
NOTE: DRAWINGS ARE NOT TO SCALE.
DIVING EQUIPMENT
TIP OF BOARD
ABOVE POINT A
DIVING EQUIPMENT
TABLE 1 - MINIMUM WATER ENVELOPE (ANSI/NSPI-5 2003)
MINIMUM DEPTHS
AT POINT
POOL
TYPE
A B C D
D I V I N G
0
I 6'-0" 7'-6" 5'-0" 2'-9" 10'-0" 12'-0" 10'-0" 8'-0"
II 6'-0" 7'-6" 5'-0" 2'-9" 12'-0" 15'-0" 12'-0" 8'-0"
III 6'-10" 8'-0" 5'-0" 2'-9" 12'-0" 15'-0" 12'-0" 8'-0"
IV 7'-8" 8'-6" 5'-0" 2'-9" 15'-0" 18'-0" 15'-0" 9'-0"
V 8'-6" 9'-0" 5'-0" 2'-9" 15'-0" 18'-0" 15'-0" 9'-0"
TABLE 2 - INTER-FAB RESIDENTIAL POOL MINIMUM SPECIFICATIONS
MAX. DIVING
MAX. HEIGHT
BOARD
OVER WATER
LENGTH AT POINT A
POOL
TYPE
DBL** HOW**
D I V I N G
0
I 6' DB/6' JB 20"
II 8' DB/6' JB 20"
III 10' DB/8' JB 26"
IV 10' DB/8' JB 30"
V 12' DB/8' JB 40"
*Min. length between points CD may vary based upon water depth at point D and the slope between points C & D
ABBREVIATIONS: **DBL=Diving Board Length; DB=Diving Board; JB=Jump Board; **HOW=Height Over Water
EDGE-IM Rev. 6/08 (BBK-EDGE INSTAL)
MINIMUM WIDTHS
AT POINT
A B C D WA+/-3"
E Q U I P M E N T
1'-6"
1'-6"
2'-0"
2'-6"
3'-0"
CROSS SECTIONAL
DIMENSIONS AT
CROSS SECTIONAL DIMENSIONS AT POINT B
POINT A
F G H J
E Q U I P M E N T
2'-9" 5'-0" 4'-0" 7'-2.5"
2'-9" 3'-10" 4'-2" 7'-2.5"
2'-9" 4'-4.75" 4'-4.5" 7'-5.5"
2'-9" 5'-10.5" 3'-10" 7'-8"
2'-9" 6'-2" 3'-11.5" 7'-9.5"
E D G E ™ D I V I N G S Y S T E M
MINIMUM LENGTHS
BETWEEN POINTS
AB BC CD* DE WE
P R O H I B I T E D
7'-0" 7'-6" VARIES 6'-0" 28'-9"
7'-0" 7'-6" VARIES 6'-0" 28'-9"
7'-6" 9'-0" VARIES 6'-0" 31'-3"
8'-0" 10'-6" VARIES 6'-0" 33'-9"
9'-0" 12'-0" VARIES 6'-0" 36'-9"
K L M N
P R O H I B I T E D
7'-6" 6'-0" 3'-9" 2'-1.5"
7'-6" 6'-8" 3'-9" 2'-1.5"
8'-0" 6'-7" 3'-11.5" 1'-7.5"
8'-6" 8'-3" 5'-7" 2'-7"
9'-0" 8'-2.5" 5'-9" 2'-7"
5
F
G
H
NOTES:
MIN. HEAD
ROOM
ABOVE
DIVING
SURFACES
12'
12'
13'
13'
14'
J
K
N
M
L
