Original operating instructions
i
BCL 308
Bar code readers
We reserve the right to make technical changes
EN • 2021-05-26 • 50117117

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCL 308i and is the answer not in the manual?

Questions and answers

Related Manuals for Leuze BCL 308i

Summary of Contents for Leuze BCL 308i

  • Page 1 Original operating instructions BCL 308 Bar code readers We reserve the right to make technical changes EN • 2021-05-26 • 50117117...
  • Page 2 © 2021 Leuze electronic GmbH & Co. KG In der Braike 1 D-73277 Owen / Germany Phone: +49 7021 573-0 Fax: +49 7021 573-199 http://www.leuze.com info@leuze.com Leuze electronic GmbH + Co. KG BCL 308...
  • Page 3 ME 3xx..............36 Leuze electronic GmbH + Co. KG...
  • Page 4 Display elements and display......... . . 73 Leuze electronic GmbH + Co. KG...
  • Page 5 Leuze webConfig tool........
  • Page 6 Module 0.5 ............. . . 114 Leuze electronic GmbH + Co. KG...
  • Page 7 Figure 5.23: "Ink Jet" reading field curve for line scanner with deflecting mirror ..........50 Figure 6.1: Device name plate BCL 308 ......................51 Figure 6.2: Fastening options using M4x5 threaded holes ................52 Leuze electronic GmbH + Co. KG BCL 308...
  • Page 8 Mounting devices for the BCL 308 ....................106 Table 13.7: Reflector for autoReflAct operation....................107 Figure 15.1: Bar code sample labels (module 0.3) ..................113 Figure 15.2: Bar code sample labels (module 0.5) ..................114 Leuze electronic GmbH + Co. KG BCL 308...

  • Page 9: Declaration Of Conformity

    European standards and directives. The manufacturer of the product, Leuze electronic GmbH & Co. KG in D-73277 Owen, possesses a certi- fied quality assurance system in accordance with ISO 9001.

  • Page 10: Intended Use

    Leuze electronic GmbH + Co. KG is not liable for damages caused by improper use.  Read the technical description before commissioning the device. Knowledge of this technical description is an element of proper use.

  • Page 11: Competent Persons

    V3 (e.g. electrician foreman). In other countries, there are respective regulations that must be observed. Exemption of liability Leuze electronic GmbH + Co. KG is not liable in the following cases: • The device is not being used properly. • Reasonably foreseeable misuse is not taken into account.
  • Page 12 BCL 3xx S/R1 … 102 (H) BCL 3xx S/R1 … 100 (H) BCL 3xx O … 100 (H) A Laser aperture B Laser warning sign Figure 2.1: Laser apertures, laser warning signs Leuze electronic GmbH + Co. KG BCL 308...

  • Page 13: Fast Commissioning / Operating Principle

    The voltage supply (18 … 30 V DC) is connected acc. to the connection type selected. 2 freely programmable switching inputs/outputs for individual adaptation to the respective application are also available here. Detailed information on this topic can be found in Chapter 7. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 14 MS 308. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device. NOTE In the case of Ethernet linear topology, the network is interrupted when the BCL 308 is removed from the MS 308. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 15 ME 308 103. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device. NOTE In the case of Ethernet line topology, the network is interrupted when the BCL 308 is removed from the ME 308 103. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 16 ME 308 104. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device. NOTE In the case of Ethernet line topology, the network is interrupted when the BCL 308 is removed from the ME 308 104. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 17 ME308 214. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device. NOTE In the case of Ethernet line topology, the network is interrupted when the BCL 308 is removed from the ME 308 214. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 18  Have the network administrator specify the data for IP address, net mask and gateway address of the BCL 308  Set these values on the BCL 308 Leuze electronic GmbH + Co. KG BCL 308...
  • Page 19 If your system includes a DHCP server that is to be used to assign the IP addresses, proceed as follows:  Activate the DHCP client mode in the BCL 308 Via webConfig: Configuration > Communication > Ethernet interface Activate the DHCP = ON setting there. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 20: Further Settings

    Configuration -> Communication -> Host communication Further settings After the basic configuration of the operating mode and the communication parameters, you need to carry out further settings: • Decoding and processing the read data Leuze electronic GmbH + Co. KG BCL 308...
  • Page 21 Configure the connected switching outputs according to your requirements. To do this, first set the I/O mode to Output and then configure the switching behavior: •Via webConfig: Configuration > Device > Switching inputs/outputs Leuze electronic GmbH + Co. KG BCL 308...
  • Page 22 Data communication (ACT) If a display is available, the following information appears successively during startup: • Startup • Device designation e.g. BCL 308i SM 102 D • Reading Result If Reading Result is displayed, the device is ready. Leuze electronic GmbH + Co. KG...
  • Page 23 2/5 Interleaved code type is limited to 10 digits of code content. If a code is moved through the reading field, the code content is decoded and forwarded to the superior system (PLC/PC) via Ethernet. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 24 Please check the incoming data of the bar code information there. Alternatively, you can use a switching input for read activation (switching signal of a photoelectric sensor or 24 V DC switching signal). Leuze electronic GmbH + Co. KG BCL 308...

  • Page 25: Device Description

    • Numerous interface variants facilitate connection to the superior systems • RS 232, RS 422 • RS 485 and multiNet plus slave Alternatively, various fieldbus systems, such as • PROFIBUS DP • PROFINET-IO • Ethernet TCP/IP UDP • EtherNet/IP • EtherCAT Leuze electronic GmbH + Co. KG BCL 308...
  • Page 26 In the basic setting, triggering takes place through an external reading cycle signal. Alternative activation options include online commands via the host interface and the autoReflAct function. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 27: Device Construction

    MS 3xx connector hood ME 3xx connection hood Display, LEDs and buttons Dovetail mounting and 4 mounting threads Line scanner with deflecting mirror Figure 4.4: Device construction BCL 308 - Line scanner with deflecting mirror Leuze electronic GmbH + Co. KG BCL 308...
  • Page 28 Terminal com- partment Ethernet LEDs LINK / ACT Connection side with system plug for Mini-B type USB connection to service interface BCL 308 Figure 4.7: Device construction MK 308 hood with integrated connectors Leuze electronic GmbH + Co. KG BCL 308...

  • Page 29: Reading Techniques

    • with bar codes having very short bar lengths. • when the ladder code is turned out of the vertical position (tilt angle). • when the reading distance is large. Figure 4.9: Deflection principle for the line scanner Leuze electronic GmbH + Co. KG BCL 308...
  • Page 30 The raster scanner is used: • When the bars of the bar code are perpendicular to the conveying direction (picket fence arrangement) • With bar codes with low height displacement • With very glossy bar codes Leuze electronic GmbH + Co. KG BCL 308...

  • Page 31: Fieldbus Systems

    For low-temperature applications to min. -35°C (e.g. in cold storage), the bar code readers of the BCL 308 series can optionally be permanently fitted with a built-in heating and these bar code readers purchased as separate device models. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 32: Reference Codes

    BCL 308 Afterward, bar codes with the same code type and number of digits are recognized and decoded. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 33: Technical Data

    270 g (without connection hood) Dimensions (H x W x D) 44 x 95 x 68 mm (without connection hood) Housing Diecast aluminum Table 5.1: Technical data of the BCL 308 line/raster scanners without heating Leuze electronic GmbH + Co. KG BCL 308...
  • Page 34 580 g (without connection hood) Dimensions (H x W x D) 58 x 125 x 110 mm (without connection hood) Table 5.2: Technical data of the BCL 308 oscillating-mirror scanners with heating Leuze electronic GmbH + Co. KG BCL 308...
  • Page 35 To achieve an optimal heating effect, the BCL 308 should be mounted so that it is thermally isolated. Electrical connection The required wire cross section of the connection cable for the voltage supply must be at least 0.75 mm². Leuze electronic GmbH + Co. KG BCL 308...
  • Page 36 Standard, M12 ready-made cable not usable (insufficient cable cross-section) Environmental data Operating temperature -35 °C … +40 °C range Storage temperature -20 °C … +70 °C range Table 5.6: Specifications of the BCL 308 oscillating-mirror scanners with heating Leuze electronic GmbH + Co. KG BCL 308...
  • Page 37 Standard, M12 ready-made cable not usable (insufficient cable cross-section) Environmental data Operating temperature -35 °C … +40 °C range Storage temperature -20 °C … +70 °C range Table 5.7: Technical data of the BCL 308 deflecting mirror scanners with heating Leuze electronic GmbH + Co. KG BCL 308...

  • Page 38: Dimensioned Drawings

    Dimensioned drawing of complete overview of the BCL 308 with MS 3xx / MK 3xx / ME 3xx Figure 5.1: Dimensioned drawing of complete overview of the BCL 308 with MS 3xx / MK 3xx / ME 3xx Leuze electronic GmbH + Co. KG BCL 308...
  • Page 39 Technical data 5.3.2 Dimensioned drawing of line scanner with / without heating Optical axis Figure 5.2: Dimensioned drawing of BCL 308 S…102 line scanner Leuze electronic GmbH + Co. KG BCL 308...
  • Page 40 Technical data 5.3.3 Dimensioned drawing of deflecting mirror scanner with / without heating Optical axis Deflection angle of the laser beam: ±30° Figure 5.3: Dimensioned drawing of BCL 308 S…100 with deflecting mirror Leuze electronic GmbH + Co. KG BCL 308...
  • Page 41 Dimensioned drawing of oscillating-mirror scanner with / without heating Optical axis Swivel angle of the laser beam: ±20° Deflection angle of the laser beam: ±30° Figure 5.4: Dimensioned drawing of BCL 308 O…100 oscillating-mirror scanner Leuze electronic GmbH + Co. KG BCL 308...
  • Page 42 To ensure degree of protection IP 65 is fulfilled, the screws of the connection hood are tightened with a tightening torque of 1.4 Nm for connecting to the BCL. Figure 5.5: Dimensioned drawing of MS 3xx connector hood / ME 3xx connection hood Leuze electronic GmbH + Co. KG BCL 308...

  • Page 43: Reading Field Curves / Optical Data

    (the so-called reading field) depends on the quality of the printed bar code and its dimensions. Therefore, above all, the module of a bar code is decisive for the size of the reading field. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 44 Deflecting mirror scanner Table 5.8: Raster line cover dependent on the distance NOTE With the raster scanner, there may not be two or more bar codes in the raster area at the same time. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 45 Zero position of the reading distance Reading conditions for the reading field curves Bar code type 2/5 Interleaved Ratio 1:2.5 ANSI specification Class A Reading rate > 75% Table 5.9: Reading conditions Leuze electronic GmbH + Co. KG BCL 308...
  • Page 46 = 0,2 -100 Reading distance [mm] Figure 5.10: "High Density" reading field curve for line scanner with deflecting mirror The reading field curve applies for the reading conditions stated in Table 5.9. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 47 = 0,5 -100 -150 Reading distance [mm] Figure 5.12: "Medium Density" reading field curve for line scanner with deflecting mirror The reading field curves apply for the reading conditions stated in Table 5.9. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 48 3xxi S/R1 F 102 m = 0,3 m = 0,35 m = 0,5 -100 -150 -200 Reading distance [mm] Figure 5.15: "Low Density" reading field curve for line scanner without deflecting mirror Leuze electronic GmbH + Co. KG BCL 308...
  • Page 49 Figure 5.17: "Low Density" reading field curve for oscillating-mirror scanners 3xxi O F 100 m = 0,3 m = 0,35 m = 0,5 -100 -150 -200 Reading distance [mm] Figure 5.18: Lateral "Low Density" reading field curve for oscillating-mirror scanners Leuze electronic GmbH + Co. KG BCL 308...
  • Page 50 -250 -300 Reading distance [mm] Figure 5.20: "Ultra Low Density" reading field curve for line scanner with deflecting mirror The reading field curves apply for the reading conditions stated in Table 5.9. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 51 -150 -200 -250 -300 Reading distance [mm] Figure 5.22: Lateral "Ultra Low Density" reading field curve for oscillating-mirror scanners The reading field curves apply for the reading conditions stated in Table 5.9. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 52 Due to the shape of the optical laser spot, the CRT function may exhibit limitations (max. permis- sible tilt angle of ± 15°). Low-contrast bar codes that are printed with inkjet should be sent to Leuze for examination. Leuze electronic GmbH + Co. KG...
  • Page 53 If you have any questions concerning your shipment, please contact your supplier or your local Leuze sales office.  Observe the applicable local regulations when disposing of the packaging materials.
  • Page 54 Installation and mounting 6.2.1 Mounting via M4 x 5 screws 4 x M4x5 6 x M4x5 (oscillating-mirror scanner) Figure 6.2: Fastening options using M4x5 threaded holes Leuze electronic GmbH + Co. KG BCL 308...
  • Page 55 A Rod holder, turnable 360 ° B Rods Ø 16 … 20 mm C Rods Ø 12 … 16 mm all dimensions in mm Figure 6.3: Mounting devices BT 56 and BT 56-1 Leuze electronic GmbH + Co. KG BCL 308...
  • Page 56 For further information, see the notices in Chapter 6.3! Please refer to Chapter 5.4 for the permissible minimum and maximum distances between the BCL 308 and the labels to be read. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 57 For further information, see the notices in Chapter 6.3! Please refer to Chapter 5.4 for the permissible minimum and maximum distances between the BCL 308 and the labels to be read. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 58: Device Arrangement

    Bar code bar code at an angle of inclination greater than ±10° … 15° to vertical. Figure 6.7: Total reflection – line scanner Leuze electronic GmbH + Co. KG BCL 308...
  • Page 59 • Possible soiling of the reading window due to liquids, abrasion by boxes, or packaging material resi- dues. • Lowest possible chance of damage to the BCL 308 by mechanical collision or jammed parts. • Possible extraneous light (no direct sunlight or sunlight reflected by the bar code). Leuze electronic GmbH + Co. KG BCL 308...
  • Page 60 In doing so, avoid leaving fingerprints on the front screen of the BCL 308 ATTENTION! Do not use aggressive cleaning agents such as thinner or acetone for cleaning the device. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 61: Electrical Connection

    Ensure that the functional earth (FE) is connected correctly. Unimpaired operation is only guar- anteed when the functional earth is connected properly. If faults cannot be cleared, the device should be switched off and protected against accidental use. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 62 ATTENTION! To ensure degree of protection IP 65 is fulfilled, the screws of the connection hood are tightened with a tightening torque of 1.4 Nm for connecting to the BCL. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 63 Mini-B type USB socket as service interface. Parameter memory is integrated into the ME 308 103 which temporarily stores the settings of the BCL 308 in the case of replacement and transmits them to a new device. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 64 M8 connectors and a Mini-B type USB socket as service interface. Parameter memory is inte- grated into the ME 308 104 which temporarily stores the settings of the BCL 308 in the case of replace- ment and transmits them to a new device. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 65 RJ45 sockets, a connection cable with M8 connectors and a Mini-B type USB socket as service inter- face. Parameter memory is integrated into the ME 308 214 which temporarily stores the settings of the BCL 308 in the case of replacement and transmits them to a new device. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 66 Mini-B type USB socket functioning as the service interface. Parameter memory is integrated into the MK 308 which temporarily stores the settings of the BCL 308 in the case of replacement and transmits them to a new device. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 67 Then lead the individual wires into the terminals according to the diagram. Wire end sleeves are not necessary. NOTE Dimensioned drawing on see chapter 5.4 "Reading field curves / optical data" on Page 41. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 68  Ensure that the functional earth (FE) is connected correctly. Unimpaired operation is only guaranteed when the functional earth is connected properly. All electrical disturbances (EMC couplings) are dis- charged via the functional earth connection. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 69 SENSOR - direct connection of an external sensor (ME 308 xx4 only) Connection hoods ME 308 104 and ME 308 214 are equipped with an M8 connection cable for the direct connection of an external sensor (e.g., a trigger sensor) Leuze electronic GmbH + Co. KG BCL 308...
  • Page 70 The entire interconnection cable must absolutely be shielded acc. to the USB specifications. Cable length must not exceed 3 m.  Use the Leuze specific USB service cable (see chapter 13 "Type overview and accessories") for the connection and use a service PC to configure.
  • Page 71 Figure 7.10: HOST / BUS IN cable assignments on RJ-45 NOTE Ensure adequate shielding. The entire interconnection cable must be shielded and earthed. The RD+/RD- and TD+/TD- wires must be stranded in pairs. Use CAT 5 cable for the connection. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 72: Ethernet Topologies

    DHCP server. BCL 308 with PC / PLC host interface MS 308 connector hood 192.168.60.xxx Other network participants BCL 308 with MK 308 terminal hood 192.168.60.yyy Figure 7.11: Ethernet in a star topology Leuze electronic GmbH + Co. KG BCL 308...
  • Page 73 TDx+ on the M12 connector with RD+ on the RJ-45 connector and TDx- on the M12 connector with RD- on the RJ-45 connector, respectively, etc. NOTE Use the recommended plugs / sockets or the ready-made cables (see chapter 13 "Type over- view and accessories"). Leuze electronic GmbH + Co. KG BCL 308...
  • Page 74 Twisted Pair (min. Cat. 5) BCL – power supply unit 30 m Not necessary Switching input 10 m Not necessary Switching output 10 m Not necessary Table 7.6: Cable lengths and shielding Leuze electronic GmbH + Co. KG BCL 308...

  • Page 75: Display Elements And Display

    - Configuration via the USB service interface - No data on the host interface Red, flashing Warning set - Bar code reading possible - Self test runs for 0.25 s after power up - Temporary operating fault Leuze electronic GmbH + Co. KG BCL 308...
  • Page 76 - Network operation ok - Connection and communication to host established Flashes red Communication error - Temporary connection error - If DHCP is active, no address could be obtained Red continuous light Network error Leuze electronic GmbH + Co. KG BCL 308...
  • Page 77 Green, continuous light Ethernet connected (LINK) Yellow, flickering light Data communication (ACT) LED ACT1 / LINK1 (on the MS 308/ME 308/MK 308) Green, continuous light Ethernet connected (LINK) Yellow, flickering light Data communication (ACT) Leuze electronic GmbH + Co. KG BCL 308...
  • Page 78 : Display changes from decoding quality to device status Press button : Display changes from device status to BUS status Press button : Bus status displayed, display stops flashing. Description of the display functions Leuze electronic GmbH + Co. KG BCL 308...
  • Page 79 Adjust mode • 2nd line: decoding quality in percent, e.g. 73% Version • 1st line: version display function SW: xxxxx HW: xxx • 2nd line: software and hardware version of the device Leuze electronic GmbH + Co. KG BCL 308...

  • Page 80: Leuze Webconfig Tool

    (HTML, JavaScript and AJAX), which are supported by all commonly used, modern browsers (e.g. Mozilla Firefox beginning with Version 4.0 or Internet Explorer beginning with Version 8.0 or Microsoft Edge), it is possible to operate the Leuze webConfig tool on any internet-ready PC. NOTE The webConfig tool is offered in 6 languages: •...
  • Page 81 CD drive and start the setup.exe program.  Alternatively, you can also download the setup program from the internet at www.leuze.com.  Follow the instructions provided by the setup program. Upon successful installation of the USB driver, an icon with the name Leuze Web Config automatically appears on the desktop.
  • Page 82 Alternatively, you can start the webConfig tool by starting the browser installed on your PC and entering the following IP address: 192.168.61.100 This is the default Leuze service address for communication with bar code readers of the BCL 300 BCL 500 series.
  • Page 83 On the right side of the user interface of the webConfig tool, you will find a description of the indi- vidual modules and functions as a help text in the Information area. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 84: Commissioning And Configuration

    USB connection between the BCL 308 and a PC/laptop. NOTE Notes on the use of the webConfig tool can be found in Chapter 9 "Leuze webConfig tool" on page 78. 10.1 Measures to be performed prior to the initial commissioning ...

  • Page 85: Setting The Communication Parameters

    • Code GS1 Data Bar LIMITED • Code GS1 Data Bar EXPANDED Deviations from these settings must be set via the webConfig tool. See "Leuze webConfig tool" on page 78. As a first step, you need to set the communication parameters of the BCL 308 10.3...
  • Page 86  Also set the following values: • IP address of the communication partner • Port number of the communication partner The corresponding adjustment options can be found: • Via webConfig: Configuration -> Communication -> Host communication Leuze electronic GmbH + Co. KG BCL 308...
  • Page 87 • Configuration of up to 3 different sorting criteria. Sorting by physical data and content of the read bar codes. • Formatting of the data output for the HOST. • Formatting of the data output for the display. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 88 • Stop decoding after a maximum reading gate time • Stop decoding via the completeness mode, if: • The maximum number of bar codes to be decoded has been decoded • A positive reference code comparison has taken place. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 89  Configure the connected switching outputs according to your requirements. To do this, first set the I/O mode to Output and then configure the switching behavior: • Via webConfig: Configuration > Device > Switching inputs/outputs Leuze electronic GmbH + Co. KG BCL 308...

  • Page 90: Transmitting Configuration Data

     Recommission the new BCL 308 (reconnect the voltage supply). The configuration is now imported from the external parameter memory of the connection hood and the BCL 308 is immediately operational without any further configuration. Leuze electronic GmbH + Co. KG BCL 308...

  • Page 91: Online Commands

    Description Requests device version information Parameter Acknowledg- 'BCL 308i SM 100 V 1.3.8 2008-02-15' ment The first line contains the device type of the BCL 308 , followed by the device version number and version date. (The data which is actually displayed may vary from the val- ues given here.)
  • Page 92 GS1 DataBar OMNIDIRECTIONAL ’14’ GS1 DataBar LIMITED ’15’ GS1 DataBar EXPANDED Number of digits of the read code zzzzzz: Contents of the decoded label. A appears if the label was not correctly read. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 93 ’11’ Codabar ’12’ Code 93 ’13’ GS1 DataBar OMNIDIRECTIONAL ’14’ GS1 DataBar LIMITED ’15’ GS1 DataBar EXPANDED zzzzzz: Contents of the decoded label. A appears if the label was not correctly read. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 94 Starts the alignment mode. Parameter ’-’: Ends the alignment mode. Acknowledg- ’yyy_zzzzzz’ ment yyy: Reading quality in %. A high process availability is ensured at read qualities > 75 %. zzzzzz: Bar code information. Leuze electronic GmbH + Co. KG BCL 308...
  • Page 95 Defined reference code no. ’1’ (Code 1) ’2’ (Code 2) Storage location for reference code ’0’ RAM+EEPROM, ’3’ RAM only Defined code type (see command ’CA’) Defined code information (1 … 63 characters) Leuze electronic GmbH + Co. KG BCL 308...
  • Page 96 Defined reference code no. ’1’ (Code 1) ’2’ (Code 2) Storage location for reference code ’0’ RAM+EEPROM, ’3’ RAM only Defined code type (see command ’CA’) Defined code information (1 … 63 characters) Leuze electronic GmbH + Co. KG BCL 308...
  • Page 97 (e.g., inverted logic and a state of High corresponds to a voltage of 0 V at the switching output). Parameter ’OA<a>’ <a> Selected switching output [1, 2], unit (dimensionless) Acknowledg- None ment Leuze electronic GmbH + Co. KG BCL 308...
  • Page 98 (e.g., inverted logic and a state of High corresponds to a voltage of 0 V at the switching output). Parameter ’OD<a>’ <a> Selected switching output [1, 2], unit (dimensionless) Acknowledg- None ment Leuze electronic GmbH + Co. KG BCL 308...
  • Page 99 Function of the switching input/ output, unit [dimensionless] ’I Switching input ’O’ Switching output ’P’ Passive Acknowledg- ’OF=<bb>’ ment <bb> Status acknowledgment ’00’ ’01’ Syntax error ’02’ Parameter error ’03’ Other error Leuze electronic GmbH + Co. KG BCL 308...
  • Page 100 Online commands 11.1.4 Online commands for the parameter set operations NOTE You can obtain detailed information on the parameter set of the bar code reader from Leuze on request. Copying parameter set Command ’PC’ Description This command can only be used to copy parameter sets in their entirety. This can be used to replicate the three parameter sets default, permanent and operating parameters on the basis of one another.
  • Page 101 Requested data does not (any longer) fit in the transmission buffer ’07’ Impermissible address value ’08’ Read access after end of data set ’09’ Impermissible QPF data set type Determining parameter set difference to default parameters Leuze electronic GmbH + Co. KG BCL 308...
  • Page 102 ’PS=<aa>’ ment <aa> Status acknowledgment, unit [dimensionless] negative ’0’ No difference ’1’ Syntax error ’2’ Impermissible command length ’6’ Impermissible combination, parameter set 1 and parameter set 2 ’8’ Invalid parameter set Leuze electronic GmbH + Co. KG BCL 308...
  • Page 103 Impermissible value for checksum type ’04’ Invalid check sum received ’05’ Impermissible data length ’06’ Invalid data (parameter limits violated) ’07’ Invalid start address ’08’ Invalid parameter set ’09’ Invalid parameter set type Leuze electronic GmbH + Co. KG BCL 308...

  • Page 104: Diagnostics And Troubleshooting

    Avoid EMC coupling caused by power  cables laid parallel to device lines. • Overall network expansion exceeded Check max. network expansion as a  function of the max. cable lengths Table 12.2: Interface error Leuze electronic GmbH + Co. KG BCL 308...
  • Page 105 12.3 Service and support Service hotline You can find the contact information for the hotline in your country on our website www.leuze.com under Contact & Support. Repair service and returns Defective devices are repaired in our service centers competently and quickly. We offer you an extensive service packet to keep any system downtimes to a minimum.

  • Page 106: Type Overview And Accessories

    IoT / Industry 4.0 - connection RS232/422 interface RS485 interface PROFIBUS DP interface Interface Ethernet interface EtherCAT interface PROFINET interface Ethernet/IP interface BCL BarCodeLeser (bar code reader) Table 13.1: BCL 308 part number code Leuze electronic GmbH + Co. KG BCL 308...
  • Page 107 With N optics and display 50116388 BCL 308 R1 M 100 D With M optics and display 50116384 BCL 308 R1 F 100 D With F optics and display 50116380 Table 13.2: BCL 308 type overview Leuze electronic GmbH + Co. KG BCL 308...

  • Page 108: Accessories - Connectors

    Mounting device for rod Ø 12 … 16 mm 50121435 BT 59 Mounting device for ITEM 50111224 BT 300 W Mounting bracket 50121433 BT 300 - 1 Mounting bracket for rod 50121434 Table 13.6: Mounting devices for the BCL 308 Leuze electronic GmbH + Co. KG BCL 308...
  • Page 109 Accessory - Reflector for AutoReflAct Type designation Description Part no. Reflective tape no. 4 / Reflective tape as reflector for AutoReflAct operation 50106119 100 x 100 mm Table 13.7: Reflector for autoReflAct operation Leuze electronic GmbH + Co. KG BCL 308...

  • Page 110: General Maintenance Information

     Contact your Leuze distributor or service organization should repairs be required. The addresses can be found on the inside of the cover and on the back. NOTE When sending devices to Leuze for repair, please provide an accurate description of the error. 14.3 Disassembling, packing, disposing Repacking For later reuse, the device is to be packed so that it is protected.
  • Page 111 EOF TRANSM. BLOCK End of data transmission block CANCEL Invalid END OF MEDIUM End of medium SUBSTITUTE Substitution ESCAPE Escape FILE SEPARATOR File separator GROUP SEPARATOR Group separator RECORD SEPARATOR Record separator Leuze electronic GmbH + Co. KG BCL 308...
  • Page 112 Number Number Number Number Number Number Number Number COLON Colon SEMICOLON Semicolon < LESS THAN Less than EQUALS Equals > GREATER THAN Greater than QUESTION MARK Question mark COMMERCIAL AT Commercial AT Leuze electronic GmbH + Co. KG BCL 308...
  • Page 113 Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Leuze electronic GmbH + Co. KG BCL 308...
  • Page 114 Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter OPENING BRACE Opening brace VERTICAL LINE Vertical line CLOSING BRACE Closing brace TILDE Tilde DELETE (RUBOUT) Delete Leuze electronic GmbH + Co. KG BCL 308...
  • Page 115 Code type 10: EAN 13 Add-on SC 0 77889 abcde Code type 08: EAN 128 1 122334 455666 Modul 0,3 Code type 13: GS1 DataBar OMNIDIRECTIONAL leuze Figure 15.1: Bar code sample labels (module 0.3) Leuze electronic GmbH + Co. KG BCL 308...
  • Page 116 Code 128 Modul 0,5 Code type 10: EAN 13 Add-on SC 2 44332 fghij Code type 08: EAN 128 Modul 0,5 0 099887 766550 LEUZE Figure 15.2: Bar code sample labels (module 0.5) Leuze electronic GmbH + Co. KG BCL 308...
