Original operating instructions
i
BCL 358
Bar code readers
We reserve the right to make technical changes
EN • 2021-05-26 • 50120726

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCL 358 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leuze BCL 358

Summary of Contents for Leuze BCL 358

  • Page 1 Original operating instructions BCL 358 Bar code readers We reserve the right to make technical changes EN • 2021-05-26 • 50120726...
  • Page 2 © 2021 Leuze electronic GmbH & Co. KG In der Braike 1 D-73277 Owen / Germany Phone: +49 7021 573-0 Fax: +49 7021 573-199 http://www.leuze.com info@leuze.com Leuze electronic GmbH + Co. KG BCL 358...

  • Page 3: Table Of Contents

    Dimensioned drawings ............34 5.3.1 Dimensioned drawing of complete overview of the BCL 358 with MS 3xx / MK 3xx ..34 Leuze electronic GmbH + Co.
  • Page 4 5.5.9 Ultra Low Density (L) - optics: BCL 358 S L 102 (H) ....... 46 5.5.10...
  • Page 5 Leuze webConfig tool........
  • Page 6 Module 0.5 ............. . . 135 Leuze electronic GmbH + Co. KG...
  • Page 7 Table 5.6: Technical data of the BCL 358 deflecting mirror scanners with heating ........34 Figure 5.1: Dimensioned drawing of complete overview of the BCL 358 with MS 3xx / MK 3xx ....34 Figure 5.2: Dimensioned drawing of BCL 358 S…102 line scanner ...............
  • Page 8 Switching output connection diagram SWIO_1 / SWIO_2 ............. 62 Table 7.2: SERVICE pin assignment – Mini-B type USB interface..............63 Table 7.3: Pin assignment HOST / BUS IN for BCL 358 ................64 Figure 7.7: HOST / BUS IN cable assignments on RJ-45 ................64 Table 7.4:...
  • Page 9 Figure 15.1: Bar code sample labels (module 0.3) ..................134 Figure 15.2: Bar code sample labels (module 0.5) ..................135 Leuze electronic GmbH + Co. KG BCL 358...

  • Page 10: General Information

    European standards and directives. The manufacturer of the product, Leuze electronic GmbH & Co. KG in D-73277 Owen, possesses a certi- fied quality assurance system in accordance with ISO 9001.

  • Page 11: Safety

    Leuze electronic GmbH + Co. KG is not liable for damages caused by improper use.  Read the technical description before commissioning the device. Knowledge of this technical description is an element of proper use.

  • Page 12: Competent Persons

    V3 (e.g. electrician foreman). In other countries, there are respective regulations that must be observed. Exemption of liability Leuze electronic GmbH + Co. KG is not liable in the following cases: • The device is not being used properly. • Reasonably foreseeable misuse is not taken into account.
  • Page 13 BCL 3xx S/R1 … 102 (H) BCL 3xx S/R1 … 100 (H) BCL 3xx O … 100 (H) A Laser aperture B Laser warning sign Figure 2.1: Laser apertures, laser warning signs Leuze electronic GmbH + Co. KG BCL 358...

  • Page 14: Fast Commissioning / Operating Principle

    Fast commissioning / operating principle Fast commissioning / operating principle Below you will find a short description for the initial commissioning of the BCL 358 . Detailed explanations for all listed points can be found throughout this technical description. Mounting the BCL 358...
  • Page 15 The shielding connection is done via the M12 connector housing. NOTE The integrated parameter memory for the simple replacement of the BCL 358 is located in the MS 358. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device.

  • Page 16: Preparatory Settings - Ethernet/Ip

    MK 358. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device. NOTE In the case of Ethernet linear topology, the network is interrupted when the BCL 358 is removed from the MK 358.

  • Page 17: Manual Configuration Of The Ip Address

    • Have the network administrator specify the data for IP address, net mask and gateway address of the BCL 358 • Connect the BCL 358 to your computer using the service cable. • Set these values on the BCL 358 . Via webConfig: Configuration > Communication > Ethernet interface NOTE If the IP address is set via the webConfig tool, then it becomes active after transfer to the device.

  • Page 18: Configuration Of The Participant

    Generic Ethernet module The input mask for the generic module describes the following parameters to be set: • The name of the participant (can be selected freely; e.g. BCL 358 • The format of I/O data (data - SINT = 8 bits) •...

  • Page 19: Transferring The Data To The Control (Rslogix 5000 Specific)

    • First, load the EDS file for the device via EDS wizard into the PLC database. NOTE You can find the EDS file at: www.leuze.com. • After it has downloaded, select the device from the device list. • Open the input dialog for setting the address and additional parameters by double-clicking on the device symbol and make the desired entries here.

  • Page 20: Starting The Device

    ACT0 / LINK0 LED (on the MS 358/MK 358) Green, continuous light Ethernet connected (LINK) Yellow, flashing Data communication (ACT) ACT1 / LINK1 LED (on the MS 358/MK 358) Green, continuous light Ethernet connected (LINK) Yellow, flashing Data communication (ACT) Leuze electronic GmbH + Co. KG BCL 358...
  • Page 21 2/5 Interleaved code type is limited to 10 digits of code content. If a code is moved through the reading field, the code content is decoded and forwarded to the superior system (PLC/PC) via Ethernet. Leuze electronic GmbH + Co. KG BCL 358...

  • Page 22: Bar Code Reading

    (PLC/PC) via the Ethernet. Please check the incoming data of the bar code information there. Alternatively, you can use a switching input for read activation (switching signal of a photoelectric sensor or 24VDC switching signal). Leuze electronic GmbH + Co. KG BCL 358...

  • Page 23: Device Description

    • Numerous interface variants facilitate connection to the superior systems • RS 232, RS 422 • RS 485 and multiNet plus slave Alternatively, various fieldbus systems, such as • PROFIBUS DP • PROFINET-IO • Ethernet TCP/IP UDP • EtherNet/IP • EtherCAT Leuze electronic GmbH + Co. KG BCL 358...
  • Page 24 The BCL 358 needs a suitable activation to start a read process as soon as an object is in the reading field. This opens a time window ("reading gate") in the BCL 358 for the read process during which the bar code reader has time to detect and decode a bar code.

  • Page 25: Device Construction

    Device description An optional, multi-language display with buttons is used to operate the BCL 358 as well as for visualization purposes. Two LEDs provide additional optical information on the current operating state of the device. The two freely configurable switching inputs/outputs SWIO1 and SWIO2 can be assigned various func- tions and control e.g.

  • Page 26: Reading Techniques

    • when the bars of the bar code are printed in the conveying direction ('ladder arrangement'). • with bar codes having very short bar lengths. • when the ladder code is turned out of the vertical position (tilt angle). • when the reading distance is large. Leuze electronic GmbH + Co. KG BCL 358...

  • Page 27: Line Scanner With Oscillating Mirror

    Line scanner with oscillating mirror The oscillating mirror deflects the scan line additionally to both sides across the scan direction at a randomly adjustable oscillation frequency. In this way, the BCL 358 can also scan larger areas or spaces for bar codes. The reading field height (and the scan line length useful for evaluation) depends on the reading distance due to the optical opening angle of the oscillating mirror.

  • Page 28: Raster Scanner (Raster Line)

    The functionality of the device is defined via parameter sets which are clustered in objects, classes and instances. These are contained in an EDS file which, depending on the version of the control software, can be used to configure and integrate the BCL 358 into the system. A fixed MAC ID is assigned to each BCL 358 by the manufacturer;...

  • Page 29: Ethernet - Star Topology

    The innovative further development of the BCL 358 with integrated switch functionality offers the option of connecting multiple bar code readers of type BCL 358 to one another without direct connection to a switch. In addition to the classic "star topology", a "linear topology" is thus also possible.

  • Page 30: Heating

    ODVA. Heating For low-temperature applications to min. -35°C (e.g. in cold storage), the bar code readers of the BCL 358 series can optionally be permanently fitted with a built-in heating and these bar code readers purchased as separate device models.

  • Page 31: Reference Codes

    4.10 autoConfig With the autoConfig function, the BCL 358 offers an extremely simple and convenient configuration option to users who only want to read one code type (symbology) with one number of digits at a time.

  • Page 32: Technical Data

    270 g (without connection hood) Dimensions (H x W x D) 44 x 95 x 68 mm (without connection hood) Housing Diecast aluminum Table 5.1: Technical data of the BCL 358 line/raster scanners without heating Leuze electronic GmbH + Co. KG BCL 358...

  • Page 33: Oscillating-Mirror Scanner

    IEC 61000-6-2 (contains IEC 61000-4-2, -3, -4, -5 and -6) Table 5.1: Technical data of the BCL 358 line/raster scanners without heating 1) Only with the MS 358 or MK 358 connection hood and screwed-on M12 connectors or cable bushings and mounted caps.

  • Page 34: Heating Models Of The Bar Code Readers

    (front cover heater and housing heater). During the heating phase (around 30 min), when the inside temperature rises above 15 °C, the temperature switch connects the BCL 358 to the supply voltage. This is followed by the self test and the changeover to read operation. The PWR LED lights up, showing overall readiness for operation.

  • Page 35: Line Scanner / Raster Scanner With Heating

    Storage temperature -20°C … +70°C range Table 5.4: Technical data of the BCL 358 line / raster scanners with heating 5.2.2 Oscillating-mirror scanner with heating Technical data same as for line scanner without heating, however with the following differences:...

  • Page 36: Line Scanner / Raster Scanner With Deflecting Mirror And Heating

    Technical data of the BCL 358 deflecting mirror scanners with heating Dimensioned drawings 5.3.1 Dimensioned drawing of complete overview of the BCL 358 with MS 3xx / MK 3xx Figure 5.1: Dimensioned drawing of complete overview of the BCL 358 with MS 3xx / MK 3xx Leuze electronic GmbH + Co.

  • Page 37: Dimensioned Drawing Of Line Scanner With / Without Heating

    Technical data 5.3.2 Dimensioned drawing of line scanner with / without heating Optical axis Figure 5.2: Dimensioned drawing of BCL 358 S…102 line scanner Leuze electronic GmbH + Co. KG BCL 358...

  • Page 38: Dimensioned Drawing Of Deflecting Mirror Scanner With / Without Heating

    Technical data 5.3.3 Dimensioned drawing of deflecting mirror scanner with / without heating Optical axis Deflection angle of the laser beam: ±30° Figure 5.3: Dimensioned drawing of BCL 358 S…100 with deflecting mirror Leuze electronic GmbH + Co. KG BCL 358...

  • Page 39: Dimensioned Drawing Of Oscillating-Mirror Scanner With / Without Heating

    Dimensioned drawing of oscillating-mirror scanner with / without heating Optical axis Swivel angle of the laser beam: ±20° Deflection angle of the laser beam: ±30° Figure 5.4: Dimensioned drawing of BCL 358 O…100 oscillating-mirror scanner Leuze electronic GmbH + Co. KG BCL 358...

  • Page 40: Dimensioned Drawings Of Ms 3Xx / Mk 3Xx Connection Hoods

    To ensure degree of protection IP 65 is fulfilled, the screws of the connection hood are tightened with a tightening torque of 1.4 Nm for connecting to the BCL. Figure 5.5: Dimensioned drawing of MS 3xx connector hood Leuze electronic GmbH + Co. KG BCL 358...

  • Page 41: Reading Field Curves / Optical Data

    Figure 5.7: The most important characteristics of a bar code The range in which the bar code can be read by the BCL 358 (the so-called reading field) depends on the quality of the printed bar code and its dimensions.

  • Page 42: Raster Scanner

    Deflecting mirror scanner Table 5.7: Raster line cover dependent on the distance NOTE With the raster scanner, there may not be two or more bar codes in the raster area at the same time. Leuze electronic GmbH + Co. KG BCL 358...

  • Page 43: Reading Field Curves

    The reading field curves also apply for the device models with heating. The zero position of the reading distance always refers to the front edge of the housing of the beam exit and is shown for the three housing types of the BCL 358 in Figure 5.8.

  • Page 44: High Density (N) - Optics: Bcl 358 I S/R1 N 102 (H)

    Technical data 5.5.1 High Density (N) - optics: BCL 358 S/R1 N 102 (H) 3xxi S/R1 N 102 m = 0,127 m = 0,15 m = 0,2 -100 Reading distance [mm] Figure 5.9: "High Density" reading field curve for line scanner without deflecting mirror 5.5.2...

  • Page 45: Medium Density (M) - Optics: Bcl 358 I S/R1 M 102 (H)

    Technical data 5.5.3 Medium Density (M) - optics: BCL 358 S/R1 M 102 (H) 3xxi S/R1 M 102 m = 0,2 m = 0,3 m = 0,5 -100 -150 Reading distance [mm] Figure 5.11: "Medium Density" reading field curve for line scanner without deflecting mirror 5.5.4...

  • Page 46: Medium Density (M) - Optics: Bcl 358 I O M 100 (H)

    Technical data 5.5.5 Medium Density (M) - optics: BCL 358 O M 100 (H) 3xxi O M 100 m = 0,2 m = 0,3 m = 0,5 -100 -150 Reading distance [mm] Figure 5.13: "Medium Density" reading field curve for oscillating-mirror scanners...

  • Page 47: Low Density (F) - Optics: Bcl 358 I S/R1 F 100 (H)

    Technical data 5.5.7 Low Density (F) - optics: BCL 358 S/R1 F 100 (H) 3xxi S/R1 F 100 m = 0,3 m = 0,35 m = 0,5 -100 -150 -200 Reading distance [mm] Figure 5.16: "Low Density" reading field curve for line scanner with deflecting mirror The reading field curves apply for the reading conditions stated in Table 5.8.

  • Page 48: Ultra Low Density (L) - Optics: Bcl 358 I S L 102 (H)

    -200 -250 -300 Reading distance [mm] Figure 5.19: "Ultra Low Density" reading field curve for line scanner without deflecting mirror 5.5.10 Ultra Low Density (L) - optics: BCL 358 S L 100 (H) 3xxi S/R1 L 100 m = 0,35...

  • Page 49: Ultra Low Density (L) - Optics: Bcl 358 I O L 100 (H)

    Technical data 5.5.11 Ultra Low Density (L) - optics: BCL 358 O L 100 (H) 3xxi O L 100 m = 0,35 m = 0,5 m = 0,8 -100 -150 -200 -250 -300 Reading distance [mm] Figure 5.21: "Ultra Low Density" reading field curve for oscillating-mirror scanners...

  • Page 50: Ink Jet (J) - Optics: Bcl 358 I R1 J 100

    Due to the shape of the optical laser spot, the CRT function may exhibit limitations (max. permis- sible tilt angle of ± 15°). Low-contrast bar codes that are printed with inkjet should be sent to Leuze for examination. Leuze electronic GmbH + Co. KG...

  • Page 51: Installation And Mounting

    If you have any questions concerning your shipment, please contact your supplier or your local Leuze sales office.  Observe the applicable local regulations when disposing of the packaging materials.

  • Page 52: Mounting Via M4 X 5 Screws

    Installation and mounting 6.2.1 Mounting via M4 x 5 screws 4 x M4x5 6 x M4x5 (oscillating-mirror scanner) Figure 6.2: Fastening options using M4x5 threaded holes Leuze electronic GmbH + Co. KG BCL 358...

  • Page 53: Mounting Devices Bt 56 And Bt 56-1

    6.2.2 Mounting devices BT 56 and BT 56-1 The BT 56 or BT 56-1 mounting device is available for mounting the BCL 358 using the fastening grooves. It is designed for rod mounting (Ø16 mm to 20 mm), the BT 56-1 for rods from Ø12 mm to 16 mm. For order guide, please refer to chapter "Type overview and accessories"...

  • Page 54: Bt 59 Mounting Device

    Installation and mounting Figure 6.4: Mounting example of BCL 358 with BT 56 6.2.3 BT 59 mounting device The BT 59 mounting device offers you an additional fastening option. For order guide, please refer to chapter "Type overview and accessories" on page 126.

  • Page 55: Bt 300 - 1, Bt 300 W Mounting Devices

    For further information, see the notices in Chapter 6.3! Please refer to Chapter 5.4 for the permissible minimum and maximum distances between the BCL 358 and the labels to be read. Leuze electronic GmbH + Co. KG BCL 358...

  • Page 56: Device Arrangement

    • The correct time for data output. The BCL 358 should be positioned in such a way that, taking into consideration the time required for data processing and the conveyor belt speed, there is sufficient time to e.g.

  • Page 57: Avoiding Total Reflection - Deflecting Mirror Scanner

    ±20° (±12° for devices with heating) is to be taken into account. This means that in order to be on the safe side and to avoid total reflection, the BCL 358 with oscillating mirror must be inclined upward or downward 20°...

  • Page 58: Devices With Integrated Heating

    In order to avoid total reflection, the angle of rotation should be greater than 10° Cleaning  Clean the glass window of the BCL 358 with a soft cloth after mounting. Remove all packaging remains, e.g. carton fibers or styrofoam balls. In doing so, avoid leaving fingerprints on the front screen of the...

  • Page 59: Electrical Connection

    ATTENTION! Do not open the device yourself under any circumstances! There is otherwise a risk of uncon- trolled emission of laser radiation from the device. The housing of the BCL 358 contains no parts that need to be adjusted or maintained by the user.
  • Page 60 ATTENTION! To ensure degree of protection IP 65 is fulfilled, the screws of the connection hood are tightened with a tightening torque of 1.4 Nm for connecting to the BCL. Leuze electronic GmbH + Co. KG BCL 358...

  • Page 61: Bcl 358 I Electrical Connection

    7.2.2 MK 358 terminal hood with spring-cage terminals The MK 358 terminal hood makes it possible to connect the BCL 358 directly and without additional connectors. The MK 358 features three cable lead-throughs in which the shielding connection for the inter- face cable is also located.
  • Page 62 - MK 358 terminal hood with spring-cage terminals NOTE The integrated parameter memory for the simple replacement of the BCL 358 is located in the MK 358. In the integrated parameter memory, both the settings and the network address are saved and transmitted to a new device.

  • Page 63: Detailed Description Of The Connections

     Ensure that the functional earth (FE) is connected correctly. Unimpaired operation is only guaranteed when the functional earth is connected properly. All electrical disturbances (EMC couplings) are dis- charged via the functional earth connection. Leuze electronic GmbH + Co. KG BCL 358...
  • Page 64 The switching inputs can be used to activate various internal functions of the BCL 358 (decoding, auto- Config, …). The switching outputs can be used to signal the state of the BCL 358 and to implement external functions independent of the superior control.

  • Page 65: Service - Usb Interface (Mini-B Type)

    The entire interconnection cable must absolutely be shielded acc. to the USB specifications. Cable length must not exceed 3 m.  Use the Leuze specific USB service cable (see chapter 13 "Type overview and accessories") for the connection and use a service PC to configure.

  • Page 66: Host / Bus In For Bcl 358

    Functional earth (housing) FE via FE via screw fit- thread ting Spring-cage terminals Table 7.3: Pin assignment HOST / BUS IN for BCL 358 Ethernet cable assignment BCL 358 BCL338 HOST / BUS IN RJ 45 Twisted pair RD0+ TD+ (1)

  • Page 67: Bus Out For The Bcl 358 I

    Electrical connection 7.3.4 BUS OUT for the BCL 358 To set up an Ethernet network with other participants with linear topology, the BCL 358 makes available another Ethernet interface. The use of this interface drastically reduces the cabling requirements, as only the first BCL 358 requires a direct connection to the switch, via which it can communicate with the host.

  • Page 68: Ethernet Topologies

    This makes wiring the network easy and inexpensive as slaves are looped through to one another in parallel. The maximum length of a segment (connection between two switches/BCL 358 ) is limited to 100 m. PC / PLC host interface...

  • Page 69: Cable Lengths And Shielding

    Cat. 3) and 100Base-TX Twisted Pair (min. Cat. 5) BCL – power supply unit Not necessary Switching input 10 m Not necessary Switching output 10 m Not necessary Table 7.5: Cable lengths and shielding Leuze electronic GmbH + Co. KG BCL 358...

  • Page 70: Display Elements And Display

    - Configuration via the USB service interface - No data on the host interface Red, flashing Warning set - Bar code reading possible - Self test runs for 0.25s after power up - Temporary operating fault Leuze electronic GmbH + Co. KG BCL 358...

  • Page 71: Ms 358/Mk358 Led Indicators

    LED ACT0 / LINK0 (on the MS 358/MK 358) Green, continuous light Ethernet connected (LINK) Yellow, flashing Data communication (ACT) LED ACT1 / LINK1 (on the MS 358/MK 358) Green, continuous light Ethernet connected (LINK) Yellow, flashing Data communication (ACT) Leuze electronic GmbH + Co. KG BCL 358...

  • Page 72: Bcl 358 I Display

    - Display NOTE The function of the LEDs is identical for the devices with and without display. The optional display of the BCL 358 has the following features: • Monochromatic with background lighting (blue/white) • Double line, 128 x 32 pixels •...
  • Page 73 Adjust mode • 2nd line: decoding quality in percent, e.g. 73% Version • 1st line: version display function SW: xxxxx HW: xxx • 2nd line: software and hardware version of the device Leuze electronic GmbH + Co. KG BCL 358...

  • Page 74: Leuze Webconfig Tool

    (HTML, JavaScript and AJAX), which are supported by all commonly used, modern browsers (e.g. Mozilla Firefox beginning with Version 4.0 or Internet Explorer beginning with Version 8.0 or Microsoft Edge), it is possible to operate the Leuze webConfig tool on any internet-ready PC. NOTE The webConfig tool is offered in 6 languages: •...

  • Page 75: Installing The Required Software

    PC. To do this, you must have administrator privileges. Please proceed according to the following steps:  Start your PC with administrator privileges and log on.  Load the CD included in the delivery contents of your BCL 358 in the CD drive and start the setup.exe program.

  • Page 76: Short Description Of The Webconfig Tool

    Alternatively, you can start the webConfig tool by starting the browser installed on your PC and entering the following IP address: 192.168.61.100 This is the default Leuze service address for communication with bar code readers of the BCL 300 BCL 500 series.

  • Page 77: Module Overview In The Configuration Menu

    Figure 9.3: Module overview in the webConfig tool NOTE The webConfig tool is completely contained in the firmware of the BCL 358 . Depending on firm- ware version, the module overview may vary from that shown above. The individual modules and their relationships to one another are graphically displayed in the module over- view.

  • Page 78: Commissioning And Configuration

    USB connection between the BCL 358 and a PC/laptop. NOTE Notes on the use of the webConfig tool can be found in Chapter 9 "Leuze webConfig tool" on page 72. 10.1 Measures to be performed prior to the initial commissioning ...

  • Page 79: Starting The Device

    • Code GS1 Data Bar LIMITED • Code GS1 Data Bar EXPANDED Deviations from these settings must be set via the webConfig tool. See "Leuze webConfig tool" on page 72. As a first step, you need to set the communication parameters of the BCL 358 10.3...

  • Page 80: Manual Configuration Of The Ip Address

    Figure 10.1: Manual configuration of the IP address If no DHCP server is present in your system, you must permanently set the IP addresses of the BCL 358 Proceed as follows: • Have the network administrator specify the data for IP address, net mask and gateway address of the BCL 358 •...

  • Page 81: Configuration Steps For A Rockwell Control Without Eds Support

    Generic Ethernet module The input mask for the generic module describes the following parameters to be set: • The name of the participant (can be selected freely; e.g. BCL 358 • The format of I/O data (data - SINT = 8 bits) •...

  • Page 82: Configuration Steps For A Rockwell Control With Eds Support

    10.5.1 Integrating the hardware into the PLC and installing the EDS file To integrate the device and to establish a connection between the PLC and the device BCL 358 , proceed as follows: • First, load the EDS file for the device via EDS wizard into the PLC database.

  • Page 83: Detailed Eds Description

    According to ODVA, the BCL 358 is assigned number 43 = 0x2B. Product Code The product code is an ID assigned by Leuze that has no further impact on other objects. Revision Version number of the identity object. Status The device status is displayed in the status byte, the first part of the telegram.

  • Page 84: Class 4 - Assembly

    Data Byte 1 … … Data Byte 254 The number of data starting at byte 5 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length. NOTE The use of the assembly is illustrated with examples at the end of this chapter.
  • Page 85 Data Byte 1 … … Data Byte 254 The number of data starting at byte 9 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length. NOTE The use of the assembly is illustrated with examples at the end of this chapter.
  • Page 86 Data Byte 1 … … Data Byte 254 The number of data starting at byte 10 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length. NOTE The use of the assembly is illustrated with examples at the end of this chapter.
  • Page 87 1) To be able to use the Activation switching output function, the output function must be set to External event in webCon- fig. The number of data starting at byte 8 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length.
  • Page 88 … … Data Byte 254 The number of data starting at byte 7 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length. It is also possible to specify the length of the assembly with one byte and thereby only use the control bits.
  • Page 89 Data Byte 1 … … Data Byte 254 The number of data starting at byte 6 is defined in the control while configuring the BCL 358 . This makes it possible to use the assembly with any length. NOTE The use of the assembly is illustrated with examples at the end of this chapter.
  • Page 90 Commissioning and configuration 10.7.2.3 Configuration assembly The configuration assembly is the data from the control to the BCL 358 which is transferred as the config- uration during the establishment of communication. The following configuration assembly is supported. Configuration assembly instance 190...

  • Page 91: Class 103 - I/O Status And Control

    If SWOUT switches several times was configured as comparison mode, this bit is toggled each time the event counter is exceeded. The bit is reset to the initial value by resetting the event counter. 0  1 Event counter exceeded 1  0 Event counter exceeded again Leuze electronic GmbH + Co. KG BCL 358...

  • Page 92: Class 106 - Activation

    Without ACK With ACK Number of results This value specifies how many messages are ready to be picked up in the BCL 358 Activation signal Signal for activating the BCL 358 . This action opens or closes the reading gate of the BCL 358 .

  • Page 93: Class 107 - Result Data

    Further results in the buffer This signal indicates whether further results are in the buffer. Buffer overflow This signal indicates that all result buffers are occupied and that the BCL 358 rejects data. Leuze electronic GmbH + Co. KG BCL 358...
  • Page 94 Data Result information with a length of max. 256 bytes. Activate result fragmentation This attribute specifies whether the messages from the BCL 358 to the control should be transferred in fragments. 0 Fragmentation inactive...

  • Page 95: Class 108 - Entry Data

    NOTE The entry is the data from the control to the BCL 358 This class defines the transfer of entry data to a command interpreter in the BCL 358 . This class also defines the transfer of fragmented entry data.
  • Page 96 Figure 10.4: Connection between Data acceptance/Data rejection/Error code attributes New entry (toggle bit) The toggle bit shows whether new entry data is present. 0  1 New result 1  0 New result Leuze electronic GmbH + Co. KG BCL 358...
  • Page 97 Data length of the actual information. Data Information with a length of max. 256 bytes. Activate input fragmentation This attribute specifies whether the messages from the control to the BCL 358 should be transferred in fragments. Fragmentation inactive Fragmentation active Fragment number Current fragment number.

  • Page 98: Class 109 - Device Status And Device Control

    This control bit confirms and deletes errors or warnings that may be present in the system. It acts like a toggle bit. 0  1 Error acknowledge 1  0 Error acknowledge StandBy Activates the standby function. Standby off Standby on Leuze electronic GmbH + Co. KG BCL 358...

  • Page 99: Example Configuration

    • Example 3 - Activation & fragmented result 13 bytes Out: 1 byte Config: 3 bytes • Example 4 - Entry data & result 33 bytes Out: 10 bytes Config: 0 bytes Leuze electronic GmbH + Co. KG BCL 358...

  • Page 100: Example 1 - Activation & Result

    Since the configuration is not used, the length of the configuration assembly is specified as 0. The device then operates with the default values. In this case, the acknowledge mode is not used. Leuze electronic GmbH + Co. KG BCL 358...
  • Page 101 New result (toggle bit) Result data length = 11 Data = "TestLabel01" Result is transmitted to Input-Assembly the PLC Activation signal Deactivation signal via Output-Assembly Figure 10.7: Data exchange sequence diagram - example 1 Leuze electronic GmbH + Co. KG BCL 358...

  • Page 102: Example 2 - Activation & Result & I/Os

    The following screenshot shows the configuration of the device in the RSLogix 5000 control software. Figure 10.8: Configuration of example 2 - module definition with generic module Figure 10.9: Configuration of example 2 - module definition with the EDS file Leuze electronic GmbH + Co. KG BCL 358...
  • Page 103 Switching output 1 reflects the activation signal. Switching output 2 displays whether the result is valid (status input/output I/O 2 = 1) or whether a NoRead has taken place (status input/output I/O 2 = 0). Leuze electronic GmbH + Co. KG BCL 358...

  • Page 104: Example 3 - Activation & Fragmented Result

    10.8.3 Example 3 - Activation & fragmented result The following screenshot shows the configuration of the device in the RSLogix 5000 control software. Figure 10.11: Configuration of example 3 - module definition with generic module Leuze electronic GmbH + Co. KG BCL 358...
  • Page 105 – – – – – 0x00 107  /  1  /  9 – – – – – – – 0x00 108  /  1  /  8 – – – – – – – 0x00 Leuze electronic GmbH + Co. KG BCL 358...

  • Page 106: Example 4 - Entry Data & Result

    10.8.4 Example 4 - Entry data & result The following screenshot shows the configuration of the device in the RSLogix 5000 control software. Figure 10.14: Configuration of example 4 - module definition with generic module Leuze electronic GmbH + Co. KG BCL 358...
  • Page 107 Since the configuration is not used, the length of the configuration assembly is specified as 0. The device then operates with the default values. In this case, the acknowledge mode is not used. Leuze electronic GmbH + Co. KG BCL 358...
  • Page 108 Command – Output-Assembly Number of results Activation status User data / command New result (toggle bit) Result data length Data = "?" Result Input-Assembly Figure 10.16: Data exchange sequence diagram - example 4 Leuze electronic GmbH + Co. KG BCL 358...

  • Page 109: Additional Settings For The Bcl 358 I

    Data processing via the webConfig tool In the Data and Output submenus of the Configuration main menu, the webConfig tool provides extensive data processing options to adapt the functionality of the BCL 358 to the specific reading task: • Data filtering and segmentation in the Data submenu: •...

  • Page 110: Control Of The Decoding

    • Start the automatic code type configuration (AutoConfig)  Connect the required control devices (photoelectric sensor, proximity switch, etc.) as described in Chapter 7 to the BCL 358  Configure the connected switching inputs according to your requirements. To do this, first set the I/O mode to Input and then configure the switching behavior: •...

  • Page 111: Control Of The Switching Outputs

    Commissioning and configuration 10.9.3 Control of the switching outputs By using the switching inputs/outputs of the BCL 358 , external event-controlled functions can be imple- mented without assistance from the superior process control. For this purpose, the respective connection at the SW IN/OUT and POWER interfaces must be configured as a switching output.

  • Page 112: Transmitting Configuration Data

    Commissioning and configuration 10.10 Transmitting configuration data Instead of going through the tedious task of configuring every parameter of the BCL 358 individually, you can also conveniently transfer configuration data. Configuration data can be transferred between two bar code readers BCL 358 as follows •...

  • Page 113: Online Commands

    'BCL 358i SM 100 V 1.1.0 2017-01-15' ment The first line contains the device type of the BCL 358 , followed by the device version number and version date. (The data which is actually displayed may vary from the val- ues given here.)
  • Page 114 GS1 DataBar OMNIDIRECTIONAL ’14’ GS1 DataBar LIMITED ’15’ GS1 DataBar EXPANDED Number of digits of the read code zzzzzz: Contents of the decoded label. A appears if the label was not correctly read. Leuze electronic GmbH + Co. KG BCL 358...
  • Page 115 Online commands autoConfig Command ’CA’ Description Activates or deactivates the ’autoConfig’ function. Certain label reading parameters are programmed automatically in the setup by the labels which the BCL 358 reads while the ’autoConfig’ function is active. ’+’ Activates ’autoConfig’ Parameter ’/’...
  • Page 116 Online commands Alignment mode Command ’JP’ Description This command simplifies mounting and alignment of the BCL 358 . After activating the function with ’JP+’, the BCL 358 continuously supplies status information to the serial interfaces. With this online command, the scanner is set to terminate the decoding after 100 successfully decoded labels and output the status information.
  • Page 117 Command ’RS’ Description This command can be used to define a new reference code in the BCL 358 by means of direct input via the serial interface. The data is saved in the parameter set according to your input under reference code 1 through 2 and stored in the working buffer for direct further processing.
  • Page 118 Reading a reference code Command ’RR’ Description The command reads out the reference code defined in the BCL 358 . If no parameters are specified, all defined codes are output. Parameter <Reference code number> ’1’ … ’2’ value range of reference codes 1 to 2...

  • Page 119: Online Commands For System Control

    (e.g., inverted logic and a state of High corresponds to a voltage of 0V at the switching output). Parameter ’OA<a>’ <a> Selected switching output [1, 2], unit (dimensionless) Acknowledg- None ment Leuze electronic GmbH + Co. KG BCL 358...
  • Page 120 (e.g., inverted logic and a state of High corresponds to a voltage of 0V at the switching output). Parameter ’OD<a>’ <a> Selected switching output [1, 2], unit (dimensionless) Acknowledg- None ment Leuze electronic GmbH + Co. KG BCL 358...
  • Page 121 Function of the switching input/ output, unit [dimensionless] ’I Switching input ’O’ Switching output ’P’ Passive Acknowledg- ’OF=<bb>’ ment <bb> Status acknowledgment ’00’ ’01’ Syntax error ’02’ Parameter error ’03’ Other error Leuze electronic GmbH + Co. KG BCL 358...

  • Page 122: Online Commands For The Parameter Set Operations

    Online commands 11.1.4 Online commands for the parameter set operations NOTE You can obtain detailed information on the parameter set of the bar code reader from Leuze on request. Copying parameter set Command ’PC’ Description This command can only be used to copy parameter sets in their entirety. This can be used to replicate the three parameter sets default, permanent and operating parameters on the basis of one another.
  • Page 123 Online commands Requesting parameter data set from BCL 358 Command ’PR’ Description The parameters of the BCL 358 are grouped together in a parameter set and perma- nently stored in memory. There is one parameter set in permanent memory and one operating parameter set in volatile memory;...
  • Page 124 ’PS=<aa>’ ment <aa> Status acknowledgment, unit [dimensionless] Negative ’0’ No difference ’1’ Syntax error ’2’ Impermissible command length ’6’ Impermissible combination, parameter set 1 and parameter set 2 ’8’ Invalid parameter set Leuze electronic GmbH + Co. KG BCL 358...
  • Page 125 Command ’PT’ Description The parameters of the BCL 358 are grouped together in a parameter set and perma- nently stored in memory. There is one parameter set in permanent memory and one operating parameter set in volatile memory; in addition, there is a default parameter set (factory parameter set) for initialization.

  • Page 126: Diagnostics And Troubleshooting

    Avoid EMC coupling caused by power  cables laid parallel to device lines. • Overall network expansion exceeded Check max. network expansion as a  function of the max. cable lengths Table 12.2: Interface error Leuze electronic GmbH + Co. KG BCL 358...

  • Page 127: Service And Support

    12.3 Service and support Service hotline You can find the contact information for the hotline in your country on our website www.leuze.com under Contact & Support. Repair service and returns Defective devices are repaired in our service centers competently and quickly. We offer you an extensive service packet to keep any system downtimes to a minimum.

  • Page 128: Type Overview And Accessories

    IoT / Industry 4.0 - connection RS232/422 interface RS485 interface PROFIBUS DP interface Interface Ethernet interface EtherCAT interface PROFINET interface Ethernet/IP interface BCL BarCodeLeser (bar code reader) Table 13.1: BCL 358 part number code Leuze electronic GmbH + Co. KG BCL 358...

  • Page 129: Bcl 358 I Type Overview

    O F 100 D H With F optics, display and heating 50120750 BCL 358 O L 100 D H With L optics, display and heating 50120753 Table 13.2: BCL 358 type overview Leuze electronic GmbH + Co. KG BCL 358...

  • Page 130: Accessories - Connection Hoods

    MS 358 Connector hood for BCL 358 50120797 MK 358 Terminal hood for BCL 358 50120796 Table 13.3: Connection hoods for the BCL 358 13.4 Accessories – Connectors Type designation Description Part no. KD 095-5A M12 axial socket for voltage supply, shielded...

  • Page 131: Maintenance

     Contact your Leuze distributor or service organization should repairs be required. The addresses can be found on the inside of the cover and on the back. NOTE When sending devices to Leuze for repair, please provide an accurate description of the error. 14.3 Disassembling, packing, disposing Repacking For later reuse, the device is to be packed so that it is protected.

  • Page 132: Appendix

    EOF TRANSM. BLOCK End of data transmission block CANCEL Invalid END OF MEDIUM End of medium SUBSTITUTE Substitution ESCAPE Escape FILE SEPARATOR File separator GROUP SEPARATOR Group separator RECORD SEPARATOR Record separator Leuze electronic GmbH + Co. KG BCL 358...
  • Page 133 Number Number Number Number Number Number Number Number COLON Colon SEMICOLON Semicolon < LESS THAN Less than EQUALS Equals > GREATER THAN Greater than QUESTION MARK Question mark COMMERCIAL AT Commercial AT Leuze electronic GmbH + Co. KG BCL 358...
  • Page 134 Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter Leuze electronic GmbH + Co. KG BCL 358...
  • Page 135 Lower case letter Lower case letter Lower case letter Lower case letter Lower case letter OPENING BRACE Opening brace VERTICAL LINE Vertical line CLOSING BRACE Closing brace TILDE Tilde DELETE (RUBOUT) Delete Leuze electronic GmbH + Co. KG BCL 358...
  • Page 136 Code type 10: EAN 13 Add-on SC 0 77889 abcde Code type 08: EAN 128 1 122334 455666 Modul 0,3 Code type 13: GS1 DataBar OMNIDIRECTIONAL leuze Figure 15.1: Bar code sample labels (module 0.3) Leuze electronic GmbH + Co. KG BCL 358...
  • Page 137 Code 128 Modul 0,5 Code type 10: EAN 13 Add-on SC 2 44332 fghij Code type 08: EAN 128 Modul 0,5 0 099887 766550 LEUZE Figure 15.2: Bar code sample labels (module 0.5) Leuze electronic GmbH + Co. KG BCL 358...

Table of Contents
