Rear View With Screw Terminal Connectors; Rear View With Rj-45 Connector - Valcom InformaCast VIP-480L-IC Manual

Note: The screw terminals are removable.
Gently lift away from the circuit board to
remove. Make the necessary wire connections,
then replace the screw terminals over the pins
Paging Horn
on circuit board.
Front View
Status
Link
Act
802.3af Compliant PoE Network Port
W/BL W/O W/GN W/BR

Rear View with Screw Terminal Connectors

900' MAX DISTANCE
CAT 3/5/6
AUDIO OUTPUT
V
ALCOM
VIP-LLE
WHITE/ORANGE
NOT USED
Figure 1

Rear View with RJ-45 Connector

Figure 2
3
RJ45
BROWN
WHITE/BROWN
GREEN
WHITE/GREEN
BLUE
WHITE/BLUE
VM-186
Note: The Brown and White/brown pair should
be twisted together and inserted into the
connector noted on the drawing and the Green
and White/Green pair should also be twisted
together and inserted into the connector that is
noted on the drawing.
IP Paging Horn
BROWN
BROWN
WHITE/BROWN
GREEN
WHITE/GREEN
ORANGE
WHITE/ORANGE
BLUE
WHITE/BLUE
BLUE
