FLUSH MOUNT USING MOUNTING SCREWS:
USING THE TEMPLATE, MARK LOCATION OF
OPENING AND MOUNTING HOLES ON W ALL.
DRILL HOLES APPROPRIATE TO MOUNTING
HARDWARE AND CUT OUT THE OPENING.

UNIVERSAL BRACKET

SURFACE MOUNTED W ITH A
UNIVERSAL MOUNTING BRACKET
"C" CLAMP FOR "I" BEAM MOUNTING
ATTACH CLAMP TO HORN
HOLDING FLEXHORN FIRMLY AGAINST A FLAT
SURFACE, DRILL THROUGH EACH MOUNTING BOSS
AS SHOW N.
PENDANT MOUNTING W ITH
OPTIONAL CHAIN AND
'EYE' SCREW
OTHER MOUNTING OPTIONS:
4
UNIVERSAL BRACKET WITH CLAMP
ATTACH FLEXHORN TO BEAM
OPTIONAL V-9805
VANDAL RESISTANT ENCLOSURE
FLUSH MOUNTING IN A STUD W ALL
INSTALLED W ITH MOUNTING SCREWS
OR CONSTRUCTION CEMENT.
