Features & Specifi cations
WARNING
AVERTISSEMENT
IMPACT HAZARD!
MOVING PARTS CAN CRUSH AND CUT.
Failure to heed this warning may result in serious personal
injury or property damage!
Minimize Lift Tension BEFORE:
Removing Mounted Equipment, Shipping Cart, Storing Cart.
DANGER D'IMPACT !
LES PARTIES EN MOUVEMENT PEUVENT ÉCRASER ET COUPER.
Il existe un risque de blessure corporelle ou d'endommagement
matériel en cas de non respect de cet avertissement.
Minimisez la tension d' é lévation AVANT :
de retirer l' é quipement fixé, d' e xpédier le chariot, de stocker le chariot
www.ergotron.com
29 °C
86 °F
10 °C
-20 °C
50 °F
- 4 °F
Relative
Relative
Humidity 5-95% rH
Humidity
Range
Range
Operational Storage
5"
(127 mm)
20"
(508 mm)
24˚
888-24-257-G-00 rev. D • 06/19
14mm (9/16")
2
4
3/7
10
8
826-501 1.
Height Adjustable LCD Mount attaches LCDs or tablet PC's with 75x75 or 100x100mm mounting
interface
2.
Worksurface 2a. Worksurface Lock and Release
3.
Secure Storage for Laptop, Thin Client or CPU
50 °C
122 °F
4.
Front Handle
5.
Height Adjustment Brake Handle
6.
Keyboard tray slides out, tilts and allows for right or left mousing with attached mouse holder
7.
Cable Management and Storage for excess cables and power supplies
5-95% rH
8.
Front Locking Casters
9.
Scanner Holder
10.
Wrist rest
20˚
5˚
180˚
1
6
2a
Weight Capacity
With Independent LCD Lift:
<14 lbs (6.4 kg)
12˚
0 lbs (0 kg)
<5 lbs (2.3 kg)
<13 lbs (5.9 kg)
<3 lbs (1.4 kg)
*Combined LCD and CPU Compartment weight:
CAUTION:
If the combined LCD and CPU weight is greater than 27 lbs (12.2 kg) then the CPU must be
mounted to the rear of the cart using the Universal CPU Holder accessory (ordered separately).
5
Without Independent LCD Lift:
20 lbs (9 kg)*
* See "How To Eliminate Independent LCD
Lift" section
Open Worksurface
Closed Worksurface
CPU Compartment
<27 lbs (12.2 kg).
9
3 of 13
