Entrances
Connections
Camera, Speech unit and
Push button common
Push Buttons
Lock Release (up to 0.5 A)
Trades button (optional)
Exit button or Fire switch (optional)
Door monitor switch (optional)
Bell View Video System
1 - 10 Way 2 Door Systems
No. of Cores
8 + 75 Ohm Co-ax
1 per phone
2
2
2
2
Page 3 of 6
Max
Solid Core
Length
Diameter
50 m
0.5 mm
50 m
0.5 mm
25 m
0.5 mm
100 m
1.0 mm
50 m
0.5 mm
100 m
0.5 mm
100 m
0.5 mm
