General

Select the appropriate wiring diagram from one of the following sections, and install in
accordance with the instructions given:
Initially connect all the equipment to one telephone only. With the power applied, test
the system is fully operational. Only if everything is functioning correctly should you
continue to connect further telephones. Connect one telephone at a time testing after
each is connected.

Model 440 and 540 Power Supplies

Read the section called 'Important Safety Information' before installing the power
supply.
These power supplies must be wall-mounted onto plasterboard, wood or a similar non-
conductive material, in a protected indoor environment such as an electrical cupboard.
When fitting the power supply cable (both mains and low voltage) ensure the cable
entry cut-outs in the enclosure lid are no larger than necessary for the cable diameter
used and under no circumstances must they be taken beyond the outer cut-out zones.
Bell View Video Entry System
System
1 way single door
2-10 way single door
11-60 way single door
1-10 way 2 door
11-60 way 2 door
Section
CW1
CW2
CW3
CW4
CW5
10
