Video Door Entry System
1 Way
Installation & Operation Manual
This manual applies to the following: –
BSD1 1 Way Door Controller –
Version 2 Build 5 & 6
BS Colour Videophone –
Version 2 Builds 1 & 2
BSA Audio Phone –
Version 1 Build 1
PD-097 Issue 3B
March 2009
Advertisement
Table of Contents
Related Manuals for Bell System bellissimo
Summary of Contents for Bell System bellissimo
- Page 1 Bell System (Telephones) Ltd. issimo bell Video Door Entry System 1 Way Installation & Operation Manual This manual applies to the following: – BSD1 1 Way Door Controller – Version 2 Build 5 & 6 BS Colour Videophone – Version 2 Builds 1 & 2 BSA Audio Phone –...
-
Page 2: Table Of Contents
DIAGRAM F – VIDEOPHONE LOCAL POWER WIRING..........30 DIAGRAM G – OPTION DETAILS ..................31 DIAGRAM H – 1 WAY COMPLETE DDA PANEL WIRING ..........32 DIAGRAM I – BELLISSIMO COMBINED SYSTEM CONNECTIONS ......33 DIAGRAM J – ACT PROXIMITY TO BELLISSIMO CONNECTIONS.......34 SAFETY INFORMATION AND DECLARATIONS ............35... -
Page 3: Introduction
Introduction Description A bellissimo video door entry system consists of a door panel, positioned at the entrance of a building, video telephones (videophone), placed inside of the building for the convenience of the occupants and a power supply and controller which are usually located inside an electrical cupboard. -
Page 4: Bellissimo Colour Videophone
1 Way Video Entry System bellissimo Colour Videophone Display Angle View Mute Lock Ringer Contrast Volume Button Lamp Steady Flashing View / camera select Amber Call in progress Ringing Mute on/off Videophone is muted Videophone is off-hook Lock... -
Page 5: Basic System Operation
issimo bell 1 Way Video Entry System Basic System Operation Call sequence When the call button is pressed at the entrance panel it causes the videophone to ring and the amber view lamp to flash. The videophone will continue to ring for up to 30 seconds or until the resident responds by picking up the handset. - Page 6 issimo bell 1 Way Video Entry System Door Status Indication The green lock lamp on the videophone will illuminate to warn the resident that a door has been left open following a call. This feature requires a door monitor contact to be fitted. Call Privacy Once a call has been answered by one videophone no other videophones may join in, view or listen to the call.
- Page 7 1 Way Video Entry System DDA Functionality The bellissimo video system has a range of options for entrance panels to help meet the requirements of the Disability Discrimination Act (DDA), including Illuminated Tactile buttons, reassurance tones and LED indicators for “Speak Now” and “Door Open”.
-
Page 8: Design Considerations
1 Way Video Entry System Design Considerations Equipment List A BS1 one-way bellissimo Video Kit comprises the following: - Model No Description 1 x BS Colour Videophone 1 x BSP1 Standard panel with a model 61 speech unit and camera. -
Page 9: Power Supply Requirements
Note 2. The PS4 power supply has been specifically designed to operate with the high- surge requirements of the system. Bell System is unable to guarantee functionality or provide support for systems which use third party power supplies. -
Page 10: Cable Specification
(or greater) power cable as tabulated below. Cat5 cable has a known performance for the transmission of video signals, whilst telephone or alarm cables are not suitable. Bell System will be unable to offer any warranty or support for systems installed using incorrect cables. -
Page 11: Cable Distances - Version 2 Colour Videophones
issimo bell 1 Way Video Entry System Cable Distances – Version 2 Colour Videophones Door Controller to Videophone System Distance Cable Comments Single videophone per < 150m 1 x Cat5 output or first videophone > 300m 1 x Cat5 2 x 1mm Single videophone + 3 <... -
Page 12: Installation & Commissioning
issimo bell 1 Way Video Entry System Installation & Commissioning Checklist The following checklist is a summary of what is required. Refer to the relevant pages for further details. ● Review the section headed ‘Safety Information’ on page 35. ● Ensure that ‘Design Considerations’ on page 8 have been understood. ●... - Page 13 The BSA audio phone can be used as a lower cost alternative to an extension videophone. It is styled like the bellissimo videophone. The phone is manufactured in white and grey high-impact ABS plastic that imparts high durability and compliments most wall furnishings.
-
Page 14: Commissioning
“Time clock common”. See the detailed diagram on page 31. Commissioning The major components of the bellissimo Video system are fitted with high quality pluggable screw terminal blocks. This enables all the connections to the system to be fully completed, whilst easily isolating individual pieces of equipment during testing and commissioning. -
Page 15: Bsd1 Door Controller Switch Settings
issimo bell 1 Way Video Entry System BSD1 Door Controller Switch Settings Talking Time/Videophone Active DIP SW1 (1-4) Talk Time On On On On 15s On On On Off 20s On On Off On 30s SW1 SW2 SW3 On On Off Off 45s On Off On On 60s On Off On Off 75s On Off Off On 90s... - Page 16 issimo bell 1 Way Video Entry System Lock Operate Time Dip SW2 (1-3) Lock Time On On On 3s* SW1 SW2 SW3 On On Off 4s On Off On 5s On Off Off 6s Off On On 8s Off On Off 10s Off Off On 15s Off Off Off 20s OFF ↔...
- Page 17 issimo bell 1 Way Video Entry System Camera Numbering DIP SW3 (1-8) Camera 1 at this door Last Camera Number Number SW1 SW2 SW3 On On On On *1 On On On On *1 On On On Off 2 On On On Off 2 On On Off On 3 agama On On Off On 3...
-
Page 18: Bsd1 Door Controller Jumper Settings
The “Video Gain” jumper on door controllers should always be set to “0” unless directed by ‘Bell System Technical Support’. This jumper is only required on some systems with very long camera to videophone cable runs well in excess of 150m. Inappropriate use of this jumper with short runs will cause picture problems. -
Page 19: Bs Videophone Switch Settings
issimo bell 1 Way Video Entry System BS Videophone Switch Settings Mute Time Setting SW2 (1-4) Mute Time On On On On Disabled¹ On On On Off 2 minutes On On Off On 5 minutes On On Off Off 10 minutes On Off On On 15 minutes On Off On Off 20 minutes OFF ↔... -
Page 20: Troubleshooting
issimo bell 1 Way Video Entry System Troubleshooting Common Faults A very high percentage of calls to our technical support number, regarding new installations, are resolved to faulty wiring. The reasons for these are various: - Broken cores, especially short links, sometimes broken inside the insulation! Connectors clamped onto the insulation instead of copper. - Page 21 issimo bell 1 Way Video Entry System Lock Release Problems Connections to Lock Release are open or shorted. Lock release does not operate Voltage drop due to cable too thin. or clicks but does not open. Lock current is too high; Power supply is resetting. ...
- Page 22 issimo bell 1 Way Video Entry System Speech Problems Volume controls set too high. Loud tone at the entrance Broken Audio 1 or 2 wire in the cabling. speaker. (Acoustic Intermittent or broken wire in Data A or B. feedback).
-
Page 23: Specifications
issimo bell 1 Way Video Entry System Specifications BSD1 Door controller Size 185mm x 230mm x 42mm Supply Voltage 10.8V min, 13.8V typical, 15V max Current Consumption 80mA idle @13.8V, 250mA active includes speech not cameras Model C-CAMBS Colour Camera Size 60mm x 57mm x 31mm Supply Voltage... - Page 24 issimo bell 1 Way Video Entry System PS4 Power Supply Size 236mm x 105mm x 81mm Output Voltage (regulated) 13.5V d.c. min, 13.8V d.c. nom, 14.1V d.c. max Output Current 3A continuous, 4A peak (5 minutes max) Mains Supply Internal Fuse Not user replaceable Supply Voltage 230V 50Hz nominal...
-
Page 25: Diagram A - 1 Way Cabling Overview
issimo bell 1 Way Video Entry System Diagram A – 1 Way Cabling Overview Cat5 For maximum distances see 'Cable Distances' (For extension phones see the videophone diagrams) Control equipment Cat5 Cat5 Further Entrances BSD1 1 way BSD1 1 way Door Controller Door Controller 2 x 1mm²... -
Page 26: Diagram B - 1 Way Pcb Detail
Audio Video High High Cam1 Cam2 Video Gain 4 3 2 1 0 Label BSD1 Version No Test Build No Status bellissimo Prog Door Controller Lock BSD1 Power Exit Door Lock Door Panel Entrance Power Supply PD-097 Issue 3B Installation and Operating Manual... -
Page 27: Diagram C - 1 Way Basic System Wiring Detail
issimo bell 1 Way Video Entry System Diagram C – 1 Way Basic System Wiring Detail PD-097 Issue 3B Installation and Operating Manual Page 27 of 36... -
Page 28: Diagram D - 1 Way Multiple Entrance Wiring Detail
issimo bell 1 Way Video Entry System Diagram D – 1 Way Multiple Entrance Wiring Detail 28V generator 28V generator PD-097 Issue 3B Installation and Operating Manual Page 28 of 36... -
Page 29: Diagram E - Extension Videophone Wiring
issimo bell 1 Way Video Entry System Diagram E – Extension Videophone Wiring See tables in text for maximum cable runs and cable cross sections. Additional power cores can be used for longer runs. Master Extension Extension Extension 1 Cat 5 Extension videop hones MUST be "daisy chain"... -
Page 30: Diagram F - Videophone Local Power Wiring
issimo bell 1 Way Video Entry System Diagram F – Videophone Local Power Wiring Where more than one extension phone is required to provide "auto display" then additional power supplies will be required Master Extension Extension Extension 1 Cat5 340C 340C PD-097 Issue 3B Installation and Operating Manual... -
Page 31: Diagram G - Option Details
issimo bell 1 Way Video Entry System Diagram G – Option Details Camera Termination Options Cameras may be wired in either twisted pair or coax and shared with other equipment. Twisted Pair Through Connection Twisted Pair Termination From From To other Camera Camera equipment... -
Page 32: Diagram H - 1 Way Complete Dda Panel Wiring
issimo bell 1 Way Video Entry System Diagram H – 1 Way Complete DDA Panel Wiring PD-097 Issue 3B Installation and Operating Manual Page 32 of 36... -
Page 33: Diagram I - Bellissimo Combined System Connections
1 Way Video Entry System Diagram I – bellissimo Combined System Connections Connecting a Bellcode Coded Access Controller Connect the lock release as per this manual. Leave the Bellcode controller set to fail secure, the BSD controller sets the lock type. -
Page 34: Diagram J - Act Proximity To Bellissimo Connections
1 Way Video Entry System Diagram J – ACT Proximity to bellissimo Connections ACT 1000/2000/3000 Proximity Controller ACT 100e Proximity Extender Notes 1. Connect the lock release or Maglock using the ACT Manuals. 2. Leave the BSD controller set to Fail Secure regardless of the type of release used. -
Page 35: Safety Information And Declarations
issimo bell 1 Way Video Entry System Safety Information and Declarations Connections to the 240VAC mains supply must be carried out by a qualified electrician or similar competent person, and made in accordance with current legislative requirements. A two-pole switch (as provided by a Consumer Unit or Switch-Fuse) must be included to isolate both Live and Neutral during Installation or Maintenance. - Page 36 1 Way Video Entry System Bell System (Telephones) Ltd. Presley Way, Crown Hill, Milton Keynes MK8 0ET. Tel: 01908 261106 (Sales and Technical Support) FAX: 01908 261116 Local rate numbers Tel: 0845 121 4008 (Sales and Technical Support) FAX: 0845 121 4009 E-mail: sales@bellsystem.co.uk...
