- Page 1 Bell System (Telephones) Ltd. issimo bell Video Door Entry System 1 Way Installation & Operation Manual PD-097 Issue 2...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ......................1 ......................1 ESCRIPTION ......................1 EATURES ................2 IAGRAM BELLISSIMO IDEOPHONE BASIC SYSTEM OPERATION................... 3 Call sequence ...................... 3 Silent viewing....................... 3 Auto Display......................3 Call Mute......................3 Door Status Indication..................3 Call Privacy......................4 User Activation (CCTV Mode)................ - Page 3 View Activated by User ..................13 ‘Global View’ at Multiple Entrances..............13 BSD1 D ............14 ONTROLLER UMPER ETTINGS BS VIDEOPHONE SWITCH SETTINGS ..............15 Mute Time Setting SW1 (1-4) ................15 Individual Functions DIP SW1 (5-8)..............15 DIAGRAM A – 1 WAY BASIC SYSTEM OVERVIEW CABLING......16 DIAGRAM B –...
-
Page 4: Introduction
Introduction Description A bellissimo video door entry system consists of a door panel, positioned at the entrance of a building, a video telephone (videophone), placed inside of the building for the convenience of the occupant and a power supply and controller which are usually located inside an electrical cupboard. -
Page 5: Diagram 1: Bellissimo Videophone
1 Way Video Entry System Diagram 1: bellissimo Videophone View Mute Lock Contrast Brightness Button Lamp Steady Flashing View / Camera select Amber Call in progress There is a call Mute on/off Videophone is muted Videophone is Off-Hook... -
Page 6: Basic System Operation
issimo bell 1 Way Video Entry System Basic System Operation Call sequence When the push button is pressed at the entrance panel it causes the videophone to ring and the amber call lamp to flash. The videophone will continue to ring for up to 30 seconds or until the resident responds by picking up the handset. -
Page 7: Call Privacy
issimo bell 1 Way Video Entry System Call Privacy Once a call has been answered by one videophone no other videophones may join in, view or listen to the call. If another videophones handset is picked up the videophone will not activate; pressing the view button on another videophone will be ignored. -
Page 8: Dda Functionality
Contact your sales representative for further details. Multiple Entrances The bellissimo One-way System allows multiple entrances to be catered for by the addition of one door controller and one entrance panel for each entrance and in some instances additional power supplies. In a multiple entrance system an optional feature allows the resident to view the cameras at all the entrances with successive presses of the ‘camera select’... -
Page 9: Design Considerations
1 Way Video Entry System Design Considerations Equipment List A BS1 one-way bellissimo Video Kit comprises the following: - Model No Description 1 x BS Videophone 1 x BSP1 Standard or panel with a model 61 speech unit and Cam BV. -
Page 10: Power Supply Requirements
issimo bell 1 Way Video Entry System Power Supply Requirements The system is powered by 12V PSU’s only: - 12V, 4A 340C 12V, 1.5A Optional for extensions Note 1. The 28V refered to on the videophone, door controller and wiring diagrams is internally generated in the controller. -
Page 11: Cat5 Cable
issimo bell 1 Way Video Entry System CAT5 cable CAT5 is our short reference for EIA standard UTP Category 5 Unshielded Twisted Pair data cable. This is a standard solid core twisted pair cable having 4 pairs (8– cores) and no shield. The cores are in pairs where Blue and ‘Blue with a White stripe’ are twisted together as the first pair. -
Page 12: Installation & Commissioning
issimo bell 1 Way Video Entry System Installation & Commissioning The following checklist is a reminder of what is required. Refer to the relevant pages for further details. ● Review the section headed ‘Important Safety Information’. ● Ensure that ‘Design Considerations’ have been studied and understood. ●... -
Page 13: Wiring
issimo bell 1 Way Video Entry System Wiring Refer to Diagram B for single entrance systems and Diagram D for multi-entrances. All wiring is carried out using a mixture of CAT5 for the signal wiring and 1mm² (or greater) cores for the power wiring; refer to Page 8 for further details. It is strongly recommended that a consistent colour code be used throughout such as that indicated on the connection diagram. -
Page 14: Bsd1 Door Controller Settings
issimo bell 1 Way Video Entry System BSD1 Door Controller Settings BSD1 Door Controller Switch Settings Talking Time/Videophone Active DIP SW1 (1-4) Talk Time On On On On 15s On On On Off 20s SW1 SW2 SW3 On On Off On 30s On On Off Off 45s On Off On On 60s On Off On Off 75s... -
Page 15: Lock Operate Time Dip Sw2 (1-3)
issimo bell 1 Way Video Entry System Lock Operate Time Dip SW2 (1-3) Lock Time On On On 3s* SW1 SW2 SW3 On On Off 4s On Off On 5s On Off Off 6s Off On On 8s Off On Off 10s Off Off On 15s Off Off Off 20s OFF ↔... -
Page 16: Camera Numbering Dip Sw3 (1-8)
issimo bell 1 Way Video Entry System Camera Numbering DIP SW3 (1-8) Camera 1 at this door Last Camera Number Number SW1 SW2 SW3 On On On On 1 On On On On 1 On On On Off 2 On On On Off 2 On On Off On 3 agama On On Off On 3... -
Page 17: Bsd1 Door Controller Jumper Settings
The “Video Gain” jumper on door controllers should always be set to “Low” unless directed by Bell System Technical. This jumper is only required on some systems with very long camera to videophone cable runs well in excess of 150m. Use of this jumper with short runs will cause picture problems. -
Page 18: Bs Videophone Switch Settings
issimo bell 1 Way Video Entry System BS Videophone Switch Settings Mute Time Setting SW1 (1-4) Mute Time On On On On Disabled¹ On On On Off 2 minutes On On Off On 5 minutes On On Off Off 10 minutes On Off On On 15 minutes On Off On Off 20 minutes On Off Off On 30 minutes... -
Page 19: Diagram A - 1 Way Basic System Overview Cabling
1 W ay V ideo Entry S ystem Diagram A – 1 Way Basic System Overview Cabling All cable MUST be bellissimo Cat 5 4 pair data cable. Except for power wiring where stated. 75m Max (1 phone) -
Page 20: Diagram B - 1 Way Basic System Wiring Detail
1 W a y V ideo En try S ystem Diagram B – 1 Way Basic System Wiring Detail Bellissimo Video Phone Data Audio Video Control Equipment Area Camera 1 Camera 2 Video Audio Data Video Audio... -
Page 21: Diagram C - 1 Way Multiple Entrance Overview Cabling
1 W ay V ideo E ntry S ystem Diagram C – 1 Way Multiple Entrance Overview Cabling All cable MUST be bellissimo Cat 5 4 pair data cable. Except for power wiring where stated. 75m Max... -
Page 23: Diagram E -Videophone And Extension Wiring
The 75m Cat 5 limit is only for a single phone powered by a controller For longer runs or extension phones additional power cores will normally be required Master Extension Extension Extension bellissimo bellissimo bellissimo bellissimo 1 Cat 5 Phones MUST be "daisy chain" wired. Plus Only one phone must select "auto display". -
Page 24: Diagram F - Videophone Local Power Wiring
Diagram F – Videophone Local Power Wiring Where more than one extension phone is required to provide "auto display" then additional power supplies will be required Master Extension Extension Extension bellissimo bellissimo bellissimo bellissimo 1 Cat 5 340C 340C 340C... -
Page 25: Troubleshooting
issimo bell 1 Way Video Entry System Troubleshooting Power Problems · Power supply intermittent short or overload. Videophone resetting · More than 1 extension enabled for auto display. (All three indicators lights · Lock output short-circuit; see ‘Lock Problems’ come on at once and then go off). - Page 26 issimo bell 1 Way Video Entry System Call Problems · Videophone off hook or muted on full mute. Videophone does not ring or · No power to videophone; check that red lamp flash when called flashes when handset is picked up. ·...
-
Page 27: Specifications
issimo bell 1 Way Video Entry System Specifications BS Videophone Size 210mm x 260mm x 60mm Fixing Wall Mounted Supply Voltage 13.5V minimum – local power supply only. 20V to 28V typical Current Consumption 750mA @ 13.5V active 28mA @28V idle Buzzer Mute Time Disabled, 1minute through 10 hours, indefinite PS4 Power Supply... -
Page 28: Important Safety Information
issimo bell 1 Way Video Entry System Important Safety Information Connections to the 240VAC mains supply must be carried out by a qualified electrician or similar competent person, and made in accordance with current legislative requirements. A two-pole switch (as provided by a Consumer Unit or Switch-Fuse) must be included to isolate both Live and Neutral during Installation or Maintenance.
