Bell System (Telephones) Ltd.
issimo
bell
Video Door Entry System
BSSW Gate Controller
Installation & Operation Manual
This manual applies to the following : –
bellissimo video systems
bellcall audio systems
Combined bellissimo and bellcall sites
Where a gate or gates is common to multiple blocks
PD-120 Issue 1
March 2008
Advertisement
Table of Contents
Related Manuals for Bell System bellissimo
Summary of Contents for Bell System bellissimo
- Page 1 BSSW Gate Controller Installation & Operation Manual This manual applies to the following : – bellissimo video systems bellcall audio systems Combined bellissimo and bellcall sites Where a gate or gates is common to multiple blocks PD-120 Issue 1 March 2008...
- Page 2 issimo bell BSSW Gate Controller PD-120 Issue 1 Installation and Operating Manual Page 2 of 14...
-
Page 3: Table Of Contents
UICK AULT EFERENCE SPECIFICATIONS.......................9 DIAGRAM A – BELLISSIMO GATE AND BLOCK WIRING..........10 DIAGRAM B – BELLCALL GATE AND BLOCK WIRING..........11 DIAGRAM C – BSSW GATE SWITCHER DETAIL WIRING ..........12 DIAGRAM D – BSSW GATE SWITCHER PCB LAYOUT ..........13 PD-120 Issue 1... -
Page 4: Introduction
issimo bell BSSW Gate Controller Introduction Description The BSSW gate controller is used in two level “gate and block” applications to provide block isolation where a main gate is used to access 2 or more blocks. Each block operates independently from local entrances when not being called from the gate. Up to 4 gates may be independently wired to each BSSW. -
Page 5: Installation & Commissioning
issimo bell BSSW Gate Controller Installation & Commissioning Checklist The following checklist is a summary of what is required. Refer to the relevant pages for further details. ● Ensure that ‘Design Considerations’ on page 4 have been understood. ● Confirm that Cat5 cable has been specified. ●... -
Page 6: Commissioning
BSSW Gate Controller Commissioning The major components of the bellissimo Digital system are fitted with high quality pluggable screw terminal blocks. This enables all the connections to the system to be fully completed, whilst easily isolating individual pieces of equipment during testing and commissioning. -
Page 7: Setting Up The Bssw Gate Controller / Block Isolator
There are 4 inputs for sources common to multiple blocks which can be used as termination or passthru. In a bellissimo video system the cable runs for passthru must be daisy chained, but for bellcall audio they can be star or combination wired. The terminator is for bellissimo video systems only. -
Page 8: Troubleshooting
issimo bell BSSW Gate Controller Troubleshooting Common Faults A very high percentage of calls to our technical support number, regarding new installations, are resolved to faulty wiring. The reasons for these are various:- Broken cores, especially short links, sometimes broken inside the insulation! Connectors clamped onto the insulation instead of copper. -
Page 9: Specifications
issimo bell BSSW Gate Controller Specifications BSSW Gate Controller Size 185mm x 230mm x 42mm Supply Voltage 10.8V min, 13.8V typical, 15V max Current Consumption 70mA idle @13.8V, 180mA active PS4 Power Supply Size 236mm x 105mm x 81mm Output Voltage (regulated) 13.5V d.c. -
Page 10: Diagram A - Bellissimo Gate And Block Wiring
BSSW Gate Controller Diagram A – bellissimo Gate and Block Wiring Site Overview A “Site” consist of 1 or more “Gates” and 2 or 1 x Cat5 Gate more blocks. The Cat5 from each “Gate” is daisy chained... -
Page 11: Diagram B - Bellcall Gate And Block Wiring
issimo bell BSSW Gate Controller Diagram B – bellcall Gate and Block Wiring Site Overview Block A site consist of 1 or more “Gates” and 2 or more blocks. Gate The wiring is shown logically with the Cat5 or telephone cable from each gate connecting to Block each block. -
Page 12: Diagram C - Bssw Gate Switcher Detail Wiring
issimo bell BSSW Gate Controller Diagram C – BSSW Gate Switcher Detail Wiring Commn Commn Video Audio Data Video Audio Data Input Output 12V Power Supply Video Video Video Video Term Term Term Term Gate 1 Gate 2 Gate 3 Gate 4 Commn Commn... -
Page 13: Diagram D - Bssw Gate Switcher Pcb Layout
issimo bell BSSW Gate Controller Diagram D – BSSW Gate Switcher PCB Layout Power Supply Input Output Prog Status G Test Video on Address Offset Off-On Label BSSW Status B Version No Build No 4 3 2 1 0 4 3 2 1 0 4 3 2 1 0 4 3 2 1 0 Video... - Page 14 BSSW Gate Controller Bell System(Telephones) Ltd. Presley Way, Crown Hill, Milton Keynes MK8 0ET. Tel: 01908 261106 (Sales and Technical Support) FAX: 01908 261116 Local rate numbers Tel: 0845 121 4008 (Sales and Technical Support) FAX: 0845 121 4009 E-mail: sales@bellsystem.co.uk...
