Bell System (Telephones) Ltd. issimo bell Video Door Entry System Digital Panel Installation & Operation Manual This manual applies to the following: – BSD-DIG Digital Door controller – Version 2 Builds 3 & 4 BS Colour Videophone – Version 2 Builds 1 & 2 BSA Audio Phone –...
Page 2
issimo bell Digital Video Entry System PD-105 Issue 3C Installation and Operating Manual Page 2 of 40...
DIAGRAM F – VIDEOPHONE LOCAL POWER WIRING..........34 DIAGRAM G – OPTION DETAILS ..................35 DIAGRAM H – BELLISSIMO COMBINED SYSTEM CONNECTIONS......36 DIAGRAM I – ACT PROXIMITY TO BELLISSIMO CONNECTIONS........37 SAFETY INFORMATION AND DECLARATIONS ............39 PD-105 Issue 3C Installation and Operating Manual...
Introduction Description A bellissimo video door entry system consists of a door panel, positioned at the entrance of a building, video telephones (videophone), placed inside of the building for the convenience of the occupants and a power supply and controller which are usually located inside an electrical cupboard.
issimo bell Digital Video Entry System Basic System Operation Panel Controls Call Button Cancel Button Reception or Porter Button >A <Z Door Button (Trades) Number and Letter Buttons The numbers 0 to 9 are used to enter numbers. The letter button >A enters letters beginning with A and each press advances through the alphabet, while the letter button <Z does the reverse starting with Z.
Page 7
(including extensions of the active videophone). User Activation (CCTV Mode) User activation is a feature of the bellissimo 1 way system and is not available on digital systems. User activation is generally not recommended on larger systems as the conflicting demands of residents and callers can result in confusion and erroneous fault reports.
Page 8
Contact your sales representative for further details. Multiple Entrances The bellissimo system allows multiple entrances to be catered for by the addition of a door controller and entrance panel for each entrance and additional power supplies. Gate and Block Systems Sites with two or more blocks sharing one or more site entrances are catered for with our BSSW Gate controller.
Digital Video Entry System Design Considerations Equipment List A bellissimo digital video system comprises the following: - Model No Description N x BS Videophone (N is the no of phones) 1 x BSP-DIG/LCP Vandal resistant panel with a model 61 speech unit, camera, VR -OR- buttons and LED display.
The gate switch controller BSSW is wired between the block door controllers and the video controllers, so would normally be wall mounted next to a door controller. For further details see the “bellissimo and Bellcall Manual Gate and Block (PD-120)”. Separately Powered Videophones...
Page 11
issimo bell Digital Video Entry System Exact power supply requirements depend upon many factors. The number of power supplies included within a standard ‘kit’ or quotation assumes that all controllers are installed in one location and that there are no extensions. The following table gives examples of the minimum number of controllers and power supplies for a given number of entrance doors and flats.
(or greater) power cable as tabulated below. Cat5 cable has a known performance for the transmission of video signals, whilst telephone or alarm cables are not suitable. Bell System will be unable to offer any warranty or support for systems installed using incorrect cables.
issimo bell Digital Video Entry System Cable Distances – Version 2 Colour Videophones Video Controller to Videophone System Distance Cable Comments Single videophone per < 150m 1 x Cat5 output or first videophone > 300m 1 x Cat5 2 x 1mm Single videophone + 3 <...
issimo bell Digital Video Entry System Installation & Commissioning Checklist The following checklist is a summary of what is required. Refer to the relevant pages for further details. ● Review the section headed ‘Safety Information’ on page 39. ● Ensure that ‘Design Considerations’ on page 9 have been understood. ●...
Page 15
The BSA audio phone can be used as a lower cost alternative to an extension videophone. It is styled like the bellissimo videophone. The phone is manufactured in white and grey high-impact ABS plastic that imparts high durability and compliments most wall furnishings.
“Time clock common”. See the detailed diagram on page 35. Commissioning The major components of the bellissimo Digital system are fitted with high quality pluggable screw terminal blocks. This enables all the connections to the system to be fully completed, whilst easily isolating individual pieces of equipment during testing and commissioning.
issimo bell Digital Video Entry System BSD-DIG Door Controller Settings The BSD-DIG is programmed from the panel for all settings. Security It is strongly recommended that the Panel Security Code (PSEC) be changed from its factory setting to prevent unauthorised access. Record the new number carefully as it cannot be easily changed if lost.
Page 18
issimo bell Digital Video Entry System ACOD – Primary Access Code Main code to open the door. Applies whenever the display indicates [Code]. The Trades mode (TRAD) needs to be set to ‘Code’ or ‘Trade’ as per the table below. The code must be 4 digits and no letters, leading 0 is OK (e.g.
Page 19
This code can contain letters and numbers for added security. This function is for when the BSD-DIG is used in Bellcall systems and is not relevant to bellissimo video systems. RING – Ringing Time/Call Time and Ring Effect Enter from 0 to 15 as per the table Setting Ring Time Ring Cadence or Sound Effect 1 in 3 –...
The ‘Video Gain’ jumper on door controllers should always be set to ‘0’ unless directed by ‘Bell System Technical Support’. This jumper is only required on some systems with very long camera to videophone cable runs well in excess of 150m. Inappropriate use of this jumper with short runs will cause picture problems.
The “Video Gain” jumper on video controllers should always be set to “0” unless directed by Bell System Technical. This jumper is only required on some systems with very long camera to videophone cable runs well in excess of 150m. Inappropriate use of this jumper with short runs will cause picture problems.
Page 22
The use of this jumper precludes the use of Odd/Even addressing by PROG pins 1-2, if both are required contact Bell System Technical. The jumper is stored on pins 4-5. Custom Alternate Addressing Special versions of the BSC4 can be ordered to allow addressing above 6413. For instance by making the jumper add 5000 the BSC4 would be able to address from 1 to 3210 and 5001 to 8210 (Phone 1 output).
issimo bell Digital Video Entry System BS Videophone Switch Settings Mute Time Setting SW2 (1-4) Mute Time On On On On Disabled¹ On On On Off 2 minutes On On Off On 5 minutes On On Off Off 10 minutes On Off On On 15 minutes On Off On Off 20 minutes OFF ↔...
issimo bell Digital Video Entry System Troubleshooting Common Faults A very high percentage of calls to our technical support number, regarding new installations, are resolved to faulty wiring. The reasons for these are various: - Broken cores, especially short links, sometimes broken inside the insulation! Connectors clamped onto the insulation instead of copper.
Page 25
issimo bell Digital Video Entry System Call Problems Videophone off hook or muted on full mute. Videophone does not ring or No power to videophone; check that the red mute flash when called lamp flashes when the handset is picked up. ...
Page 26
issimo bell Digital Video Entry System Speech Problems Volume controls set too high Loud tone at the entrance Broken Audio 1 or 2 wire in the cabling. speaker. (Acoustic Intermittent or broken wire in Data A or B. feedback) ...
issimo bell Digital Video Entry System Specifications BSD-DIG Door Controller Size 185mm x 230mm x 42mm Supply Voltage 10.8V min, 13.8V typical, 15V max Current Consumption 80mA idle @13.8V, 500mA active Includes display, speech not cameras. Model C-CAMBS Colour Camera Size 60mm x 57mm x 31mm Supply Voltage...
Page 28
issimo bell Digital Video Entry System PS4 Power Supply Size 236mm x 105mm x 81mm Output Voltage (regulated) 13.5V d.c. min, 13.8V d.c. nom, 14.1V d.c. max Output Current 3A continuous, 4A peak (5 minutes max) Mains Supply Internal Fuse Not user replaceable Supply Voltage 230V 50Hz nominal...
issimo bell Digital Video Entry System Diagram A – Basic System Overview Cabling For maximum distance see text (For extension phones see 1 Cat5 phone diagrams) per phone BSC4 4 way BSC4 4 way Video Controller Video Controller Cat5 Further Controllers 2 x 1mm²...
issimo bell Digital Video Entry System Diagram B – Large system Overview Illustration of Power Supply Distribution Further Further Controllers Entrances 2 x 1mm² BSC4 Video Passthru Controller Cat5 Input 2 x 1mm² Cat5 Input Door Panel BSD-DIG Output Door Controller BSC4 Video Passthru Controller...
issimo bell Digital Video Entry System Diagram C – BSD_DIG PCB Detail Input Output Camera 1 Camera 2 Video Audio Data Video Audio Data Commn Commn Video Audio High High Cam1 Cam2 Prog Video Gain Test 4 3 2 1 0 Status bell issimo...
Digital Video Entry System Diagram D – Basic System Wiring Detail – VR or LCP Bellissimo Video Phone Data Audio Video For maximum distance see text (For extension phones see phone diagrams) Video Audio Data Video Audio Data...
issimo bell Digital Video Entry System Diagram E – Extension Videophone Wiring See tables in text for maximum cable runs and cable cross sections. Additional power cores can be used for longer runs. Master Extension Extension Extension 1 Cat 5 Extension videop hones MUST be "daisy chain"...
issimo bell Digital Video Entry System Diagram F – Videophone Local Power Wiring Where more than one extension phone is required to provide "auto display" then additional power supplies will be required Master Extension Extension Extension 1 Cat5 340C 340C PD-105 Issue 3C Installation and Operating Manual Page 34 of 40...
issimo bell Digital Video Entry System Diagram G – Option Details Camera Termination Options Cameras may be wired in either twisted pair or coax and shared with other equipment. Twisted Pair Through Connection Twisted Pair Termination From From To other Camera Camera equipment...
Digital Video Entry System Diagram H – bellissimo Combined System Connections Connecting a Bellcode Coded Access Controller Connect the lock release as per this manual. Leave the Bellcode controller set to fail secure, the BSD controller sets the lock type.
Digital Video Entry System Diagram I – ACT Proximity to bellissimo Connections ACT 1000/2000/3000 Proximity Controller ACT 100e Proximity Extender Notes 1. Connect the lock release or Maglock using the ACT Manuals. 2. Leave the BSD controller set to Fail Secure regardless of the type of release used.
Page 38
issimo bell Digital Video Entry System PD-105 Issue 3C Installation and Operating Manual Page 38 of 40...
issimo bell Digital Video Entry System Safety Information and Declarations Connections to the 240VAC mains supply must be carried out by a qualified electrician or similar competent person, and made in accordance with current legislative requirements. A two-pole switch (as provided by a Consumer Unit or Switch-Fuse) must be included to isolate both Live and Neutral during Installation or Maintenance.
Page 40
Digital Video Entry System Bell System (Telephones) Ltd. Presley Way, Crown Hill, Milton Keynes MK8 0ET. Tel: 01908 261106 (Sales and Technical Support) FAX: 01908 261116 Local rate numbers Tel: 0845 121 4008 (Sales and Technical Support) FAX: 0845 121 4009 E-mail: sales@bellsystem.co.uk...
