Quectel LTE Standard Module Series Hardware Design page 13

AT Commands
Physical Characteristics
Temperature Range
Firmware Upgrade
RoHS
NOTES
1)
1. Within operation temperature range, the module is 3GPP compliant.
2)
2. Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, emergency call*, etc. There is no unrecoverable malfunction. There
are also no effects on radio spectrum and no harm to radio network. Only one or more parameters
like P might reduce in their value and exceed the specified tolerances. When the temperature
out
returns to normal operation temperature levels, the module will meet 3GPP specifications again.
"*" means under development.
3.
EG21-G_Mini_PCIe_Hardware_Design
Data update rate: 1Hz by default
Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT
commands
Size: (51.0± 0.15)mm × (30.0± 0.15)mm × (4.9± 0.2)mm
Weight: approx. 9.8g
Operation temperature range: -35° C ~ +75° C
Extended temperature range: -40° C ~ +80° C
Storage temperature range: -40° C ~ +90° C
Upgrade via USB interface or DFOTA
All hardware components are fully compliant with EU RoHS directive
LTE Standard Module Series
EG21-G Mini PCIe Hardware Design
1)
2)
12 / 54
